| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | Voltage-Max | Current-Max | Current-Hold(Ih)(Max) | Current-Trip(It) | TimetoTrip | Resistance-Initial(Ri)(Min) | Resistance-PostTrip(R1)(Max) | Resistance-25°C(Typ) | OperatingTemperature | Ratings | MountingType | Size/Dimension | Height-Seated(Max) | Thickness(Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RHEF100-APPTC RESET FUSE 30V 1A RADIAL |
2,812 | 0.67 |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | PolySwitch®, RHEF | Active | Polymeric | 30V | 40 A | 1 A | 1.8 A | 5.2 s | 180 mOhms | 430 mOhms | - | -40°C ~ 125°C | - | Through Hole | 0.382 Dia x 0.118 T (9.70mm x 3.00mm) | 0.535 (13.60mm) | - |
|
RXEF160-APPTC RESET FUSE 72V 1.6A RADIAL |
3,021 | 0.63 |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | PolySwitch®, RXEF | Active | Polymeric | 72V | 40 A | 1.6 A | 3.2 A | 11.4 s | 90 mOhms | 220 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.642 Dia x 0.118 T (16.30mm x 3.00mm) | 0.819 (20.80mm) | - |
|
72R135XMRPTC RESET FUSE 72V 1.35A RADIAL |
2,750 | 0.61 |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 72R | Active | Polymeric | 72V | 40 A | 1.35 A | 2.7 A | 9.6 s | 120 mOhms | 300 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.535 Dia x 0.122 T (13.58mm x 3.10mm) | 0.780 (19.80mm) | - |
|
NANOASMDCH035F-2PTC RESET FUSE 16V 350MA 1206 |
3,315 | 0.67 |
RFQ |
Datasheet |
1206 (3216 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, nanoASMD | Active | Polymeric | 16V | 50 A | 350 mA | 950 mA | 200 ms | 200 mOhms | 1.6 Ohms | - | -40°C ~ 125°C | - | Surface Mount | 0.134 L x 0.071 W (3.40mm x 1.80mm) | - | 0.045 (1.14mm) |
|
NANOASMDCH020F-2PPTC-MINI-PSW |
2,325 | 0.72 |
RFQ |
1206 (3216 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q200 | Active | Polymeric | 24V | 100 A | 200 mA | 420 mA | 100 ms | 650 mOhms | 3.1 Ohms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | - | - | - | |
|
MINIASMDC110F/24-2PTC RESET FUSE 24V 1.1A 1812 |
3,679 | 0.68 |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, miniASMD | Active | Polymeric | 24V | 20 A | 1.1 A | 2.2 A | 500 ms | 60 mOhms | 180 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.181 L x 0.128 W (4.60mm x 3.24mm) | - | 0.057 (1.46mm) |
|
|
MINIASMDC075F/24-2PTC RESET FUSE 24V 750MA 1812 |
3,422 | 0.71 |
RFQ |
Datasheet |
1812 (4532 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, miniASMD | Active | Polymeric | 24V | 40 A | 750 mA | 1.5 A | 300 ms | 90 mOhms | 290 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.181 L x 0.128 W (4.60mm x 3.24mm) | - | 0.057 (1.46mm) |
|
|
72R160XMRPTC RESET FUSE 72V 1.6A RADIAL |
2,073 | 0.71 |
RFQ |
Datasheet |
Radial, Disc | Cut Tape (CT),Tape & Box (TB) | POLY-FUSE®, 72R | Active | Polymeric | 72V | 40 A | 1.6 A | 3.2 A | 11.4 s | 90 mOhms | 220 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.600 Dia x 0.122 T (15.24mm x 3.10mm) | 0.850 (21.60mm) | - |
|
|
AHS120F/33-2PPTC-SMD-PSW |
2,099 | 0.79 |
RFQ |
2-SMD | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® AHS | Active | Polymeric | 33V | 20 A | 1.2 A | 2.3 A | 2 s | 150 mOhms | 340 mOhms | - | -40°C ~ 125°C | AEC-Q200 | Surface Mount | 0.290 L x 0.202 W (7.36mm x 5.12mm) | 0.118 (3.00mm) | - | |
|
|
PICOASMDCH016F-2PPTC-MINI-PSW |
2,275 | 0.82 |
RFQ |
Datasheet |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, picoASMD | Active | Polymeric | 16V | 40 A | 160 mA | 680 mA | 100 ms | 800 mOhms | 6 Ohms | - | -40°C ~ 125°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.031 (0.80mm) |
|
|
AHS300F/24-2PPTC-SMD-PSW |
3,080 | 0.79 |
RFQ |
2-SMD | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® AHS | Active | Polymeric | 24V | 20 A | 3 A | 6 A | 8 s | 15 mOhms | 100 mOhms | - | -40°C ~ 125°C | AEC-Q200 | Surface Mount | 0.343 L x 0.250 W (8.70mm x 6.36mm) | 0.118 (3.00mm) | - | |
|
ASMD150F-2PTC RESET FUSE 16V 1.27A 2SMD |
2,572 | 0.75 |
RFQ |
Datasheet |
2-SMD | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, ASMD | Active | Polymeric | 16V | 40 A | 1.27 A | 2.95 A | 25 s | 49 mOhms | 250 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.343 L x 0.250 W (8.70mm x 6.36mm) | - | 0.118 (3.00mm) |
|
|
PICOASMDC075S-2PPTC-MINI-PSW |
3,622 | 0.82 |
RFQ |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® picoASMDC | Active | Polymeric | 6V | 40 A | 750 mA | 1.5 A | 200 ms | 100 mOhms | 350 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.037 (0.93mm) | |
|
|
PICOASMDC110S-2PPTC-MINI-PSW |
2,392 | 0.82 |
RFQ |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® picoASMDC | Active | Polymeric | 6V | 40 A | 1.1 A | 2.2 A | 200 ms | 50 mOhms | 170 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.047 (1.20mm) | |
|
|
PICOASMDC035S-2PPTC-MINI-PSW |
3,094 | 0.82 |
RFQ |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® picoASMDC | Active | Polymeric | 6V | 100 A | 350 mA | 750 mA | 200 ms | 350 mOhms | 1.4 Ohms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.027 (0.68mm) | |
|
|
PICOASMDC020S-2PPTC-MINI-PSW |
2,295 | 0.82 |
RFQ |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® picoASMDC | Active | Polymeric | 9V | 100 A | 200 mA | 470 mA | 100 ms | 750 mOhms | 3.2 Ohms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.027 (0.68mm) | |
|
|
PICOASMDC050S-2PPTC-MINI-PSW |
2,193 | 0.82 |
RFQ |
0805 (2012 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | PolySwitch® picoASMDC | Active | Polymeric | 6V | 100 A | 500 mA | 1 A | 100 ms | 150 mOhms | 800 mOhms | - | -40°C ~ 85°C | AEC-Q200 | Surface Mount | 0.083 L x 0.055 W (2.10mm x 1.40mm) | - | 0.037 (0.93mm) | |
|
RHEF450-2PTC RESET FUSE 16V 4.5A RADIAL |
2,551 | 0.77 |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Cut Tape (CT),Cut Tape (CT) | PolySwitch®, RHEF | Active | Polymeric | 16V | 100 A | 4.5 A | 7.8 A | 3 s | 22 mOhms | 54 mOhms | - | -40°C ~ 125°C | - | Through Hole | 0.409 L x 0.118 W (10.40mm x 3.00mm) | 0.614 (15.60mm) | - |
|
RUEF500K-2PTC RESET FUSE 30V 5A RADIAL |
3,824 | 0.83 |
RFQ |
Datasheet |
Radial, Disc | Tape & Reel (TR),Cut Tape (CT) | PolySwitch®, RUEF | Active | Polymeric | 30V | 100 A | 5 A | 10 A | 14.5 s | 10 mOhms | 50 mOhms | - | -40°C ~ 85°C | - | Through Hole | 0.551 L x 0.118 W (14.00mm x 3.00mm) | 1.008 (25.60mm) | - |
|
2920L075/72MR2920L |
2,879 | 0.82 |
RFQ |
Datasheet |
2920 (7351 Metric), Concave | Tape & Reel (TR),Cut Tape (CT) | POLY-FUSE®, 2920L | Active | - | 72V | 10 A | 750 mA | 1.5 A | 300 ms | 240 mOhms | 950 mOhms | - | -40°C ~ 85°C | - | Surface Mount | 0.290 L x 0.202 W (7.36mm x 5.12mm) | - | 0.071 (1.80mm) |
