| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Configuration | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Power-Max | Vce(on)(Max)@VgeIc | Current-CollectorCutoff(Max) | InputCapacitance(Cies)@Vce | Input | NTCThermistor | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FS300R12OE4BOSA1IGBT MOD 1200V 460A 1650W |
3,003 | 547.36 |
RFQ |
Datasheet |
Tray | - | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 460 A | 1650 W | 2.1V @ 15V, 300A | 3 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
FF1200R12IE5PBPSA1IGBT MOD 1200V 2400A 20MW |
2,595 | 1279.76 |
RFQ |
Datasheet |
Tray | PrimePACK™2 | Active | Trench Field Stop | Half Bridge | 1200 V | 2400 A | 20 mW | 2.15V @ 15V, 1200A | 5 mA | 65.5 nF @ 25 V | Standard | Yes | -40°C ~ 175°C | Chassis Mount |
|
FZ3600R17HP4B2BOSA2IGBT MODULE 1700V 3600A |
2,558 | 2262.27 |
RFQ |
Datasheet |
Tray | - | Active | Trench Field Stop | Single Switch | 1700 V | 3600 A | 4900000 W | 2.25V @ 15V, 3.6kA | 5 mA | 295 nF @ 25 V | Standard | No | -40°C ~ 150°C (TJ) | Chassis Mount |
|
|
FZ1500R33HL3BPSA1IGBT MODULE 3300V 1500A |
3,005 | 2345.07 |
RFQ |
Datasheet |
Tray | - | Active | Trench Field Stop | Full Bridge | 3300 V | 1500 A | 17000 W | 2.85V @ 15V, 1500A | 5 mA | 6 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount |
|
F3L100R07W2E3B11BOMA1IGBT MOD 650V 117A 300W |
2,389 | 66.36 |
RFQ |
Datasheet |
Tray | - | Active | Trench Field Stop | Three Phase Inverter | 650 V | 117 A | 300 W | 1.9V @ 15V, 100A | 1 mA | 6.2 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
F3L100R12W2H3B11BPSA1IGBT MOD 1200V 100A 375W |
3,251 | 72.98 |
RFQ |
Datasheet |
Tray | EasyPACK™ | Active | - | Three Phase Inverter | 1200 V | 100 A | 375 W | 1.75V @ 15V, 50A | 1 mA | 6.15 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FS3L30R07W2H3FB11BPSA2IGBT MOD 650V 30A 20MW |
3,701 | 84.93 |
RFQ |
Datasheet |
Bulk,Tray | EasyPACK™ | Active | Trench Field Stop | Three Phase Inverter | 650 V | 30 A | 20 mW | 1.9V @ 15V, 30A | 1 mA | 1.65 nF @ 25 V | Standard | Yes | -40°C ~ 150°C (TJ) | Chassis Mount |
|
FF100R12KS4HOSA1IGBT MOD 1200V 150A 780W |
3,246 | 116.49 |
RFQ |
Datasheet |
Tray | C | Active | - | 2 Independent | 1200 V | 150 A | 780 W | 3.7V @ 15V, 100A | 5 mA | 650 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount |
|
FP50R12KT4GBOSA1IGBT MOD 1200V 50A 280W |
3,350 | 142.38 |
RFQ |
Datasheet |
Tray | EconoPIM™ 3 | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 50 A | 280 W | 2.15V @ 15V, 50A | 1 mA | 2.8 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF300R06KE3HOSA1IGBT MOD 600V 400A 940W |
2,475 | 143.32 |
RFQ |
Datasheet |
Tray | C | Active | Trench Field Stop | 2 Independent | 600 V | 400 A | 940 W | 1.9V @ 15V, 300A | 5 mA | 19 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount |
|
FF200R17KE4HOSA1IGBT MOD 1700V 310A 1250W |
2,639 | 168.04 |
RFQ |
Datasheet |
Tray | C | Active | Trench Field Stop | 2 Independent | 1700 V | 310 A | 1250 W | 2.3V @ 15V, 200A | 1 mA | 18 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount |
|
|
FF400R07KE4HOSA1IGBT MODULE 650V 1250W |
3,771 | 168.38 |
RFQ |
Datasheet |
Tray | C | Active | Trench Field Stop | 2 Independent | 650 V | - | 1250 W | 1.95V @ 15V, 400A | 5 mA | 26 nF @ 25 V | Standard | No | -40°C ~ 150°C | Chassis Mount |
|
FP100R06KE3BOSA1IGBT MOD 600V 100A 335W |
2,935 | 174.90 |
RFQ |
Datasheet |
Tray | EconoPIM™ 3 | Active | Trench Field Stop | Three Phase Inverter | 600 V | 100 A | 335 W | 1.9V @ 15V, 100A | 1 mA | 6.2 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
FF300R12ME4BOSA1IGBT MOD 1200V 450A 1600W |
3,365 | 178.57 |
RFQ |
Datasheet |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | 2 Independent | 1200 V | 450 A | 1600 W | 2.1V @ 15V, 300A | 3 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FP75R12KT4BOSA1IGBT MOD 1200V 75A 385W |
2,017 | 189.32 |
RFQ |
Datasheet |
Tray | EconoPIM™ 3 | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 75 A | 385 W | 2.25V @ 15V, 75A | 1 mA | 4.3 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF225R17ME4BOSA1IGBT MOD 1700V 340A 1500W |
3,736 | 192.68 |
RFQ |
Datasheet |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | 2 Independent | 1700 V | 340 A | 1500 W | 2.3V @ 15V, 225A | 3 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF400R12KT3HOSA1IGBT MOD 1200V 580A 2000W |
2,847 | 226.47 |
RFQ |
Datasheet |
Tray | C | Not For New Designs | Trench Field Stop | 2 Independent | 1200 V | 580 A | 2000 W | 2.15V @ 15V, 400A | 5 mA | 28 nF @ 25 V | Standard | No | -40°C ~ 125°C | Chassis Mount |
|
F3L300R07PE4BOSA1IGBT MOD 650V 300A 940W |
3,910 | 258.74 |
RFQ |
Datasheet |
Bulk,Tray | EconoPACK™ 4 | Active | Trench Field Stop | Three Level Inverter | 650 V | 300 A | 940 W | 1.95V @ 15V, 300A | 1 mA | 18.5 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
|
FF600R17ME4BOSA1IGBT MODULE VCES 1700V 600A |
2,438 | 409.73 |
RFQ |
Datasheet |
Tray | EconoDUAL™ 3 | Active | Trench Field Stop | 2 Independent | 1700 V | - | - | 2.3V @ 15V, 600A | 1 mA | 48 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount |
|
DDB2U30N08VRBOMA1307IGBT MODULE |
2,266 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | - | 3 Independent | 600 V | 25 A | 20 mW | 2.55V @ 15V, 20A | 1 mA | 880 pF @ 25 V | Standard | Yes | -40°C ~ 125°C (TJ) | Chassis Mount |
