| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SS307(TE85L,F)DIODE GEN PURP 30V 100MA SMINI |
3,369 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 6pF @ 0V, 1MHz | - | 10 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 1.3 V @ 100 mA | |
|
1SS397TE85LFDIODE GEN PURP 400V 100MA SC70 |
3,408 | 0.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 5pF @ 0V, 1MHz | 500 ns | 1 µA @ 400 V | 400 V | 100mA | 125°C (Max) | 1.3 V @ 100 mA | |
|
CUS05F40,H3FDIODE SCHOTTKY 40V 500MA USC |
2,806 | 0.06 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 28pF @ 0V, 1MHz | - | 15 µA @ 40 V | 40 V | 500mA | 150°C (Max) | 810 mV @ 500 mA | |
|
CRG04(TE85L,Q,M)DIODE GEN PURP 600V 1A SFLAT |
3,469 | 0.10 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Last Time Buy | Surface Mount | - | - | 10 µA @ 600 V | 600 V | 1A | -40°C ~ 150°C | 1.1 V @ 1 A | |
|
|
CRS20I30A(TE85L,QMDIODE SCHOTTKY 30V 2A SFLAT |
2,762 | 0.15 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 10V, 1MHz | - | 60 µA @ 30 V | 30 V | 2A | 150°C (Max) | 490 mV @ 2 A | |
|
|
BAS316,H3FDIODE GEN PURP 100V 250MA USC |
3,622 | 0.03 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 0.35pF @ 0V, 1MHz | 3 ns | 200 nA @ 80 V | 100 V | 250mA | 150°C (Max) | 1.25 V @ 150 mA | |
|
|
BAS516,H3FDIODE GEN PURP 100V 250MA ESC |
3,504 | 0.03 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 0.35pF @ 0V, 1MHz | 3 ns | 200 nA @ 80 V | 100 V | 250mA | 150°C (Max) | 1.25 V @ 150 mA | |
|
|
CRS14(TE85L,Q,M)DIODE SCHOTTKY 30V 2A S-FLAT |
2,609 | 0.16 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 90pF @ 10V, 1MHz | - | 50 µA @ 30 V | 30 V | 2A | -40°C ~ 150°C | 490 mV @ 2 A | |
|
|
CRS15(TE85L,Q,M)DIODE SCHOTTKY 30V 3A S-FLAT |
2,160 | 0.16 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 90pF @ 10V, 1MHz | - | 50 µA @ 30 V | 30 V | 3A (DC) | -40°C ~ 150°C | 520 mV @ 3 A | |
|
CUS521,H3FDIODE SCHOTTKY 30V 200MA USC |
2,382 | 0.04 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 26pF @ 0V, 1MHz | - | 30 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 500 mV @ 200 mA | |
|
|
1SS294,LFDIODE SCHOTTKY 40V 100MA SMINI |
3,465 | 0.07 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 25pF @ 0V, 1MHz | - | 5 µA @ 40 V | 40 V | 100mA | 125°C (Max) | 600 mV @ 100 mA | |
|
|
CUS10F40,H3FDIODE SCHOTTKY 40V 1A USC |
3,762 | 0.07 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 74pF @ 0V, 1MHz | - | 20 µA @ 40 V | 40 V | 1A | 150°C (Max) | 670 mV @ 1 A | |
|
|
CMC02(TE12L,Q,M)DIODE GEN PURP 400V 1A M-FLAT |
2,966 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Last Time Buy | Surface Mount | - | - | 10 µA @ 400 V | 400 V | 1A | -40°C ~ 150°C | 1 V @ 1 A | |
|
|
CRS10I30A(TE85L,QMDIODE SCHOTTKY 30V 1A US-FLAT |
3,513 | 0.09 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 50pF @ 10V, 1MHz | - | 60 µA @ 30 V | 30 V | 1A | 150°C | 390 mV @ 700 mA | ||
|
|
CMG05(TE12L,Q,M)DIODE GEN PURP 400V 1A M-FLAT |
2,969 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Last Time Buy | Surface Mount | - | - | 10 µA @ 400 V | 400 V | 1A | -40°C ~ 150°C | 1.1 V @ 1 A | |
|
|
CRH02(TE85L,Q,M)DIODE GEN PURP 200V 500MA S-FLAT |
3,513 | 0.11 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 35 ns | 10 µA @ 200 V | 200 V | 500mA | 150°C (Max) | 950 mV @ 500 mA | |
|
|
CRS05(TE85L,Q,M)DIODE SCHOTTKY 30V 1A SFLAT |
2,233 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 30 V | 30 V | 1A | -40°C ~ 150°C | 450 mV @ 1 A | |
|
|
CRS10I40A(TE85L,QMDIODE GEN PURP 40V 1A S-FLAT |
2,384 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 35pF @ 10V, 1MHz | - | 60 µA @ 40 V | 40 V | 1A | 150°C (Max) | 490 mV @ 700 mA | |
|
|
CRS10I40B(TE85L,QMDIODE SCHOTTKY 40V 1A S-FLAT |
2,859 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 62pF @ 10V, 1MHz | - | 100 µA @ 40 V | 40 V | 1A | 150°C (Max) | 450 mV @ 1 A | |
|
|
CRF02(TE85L,Q,M)DIODE GEN PURP 800V 500MA S-FLAT |
2,546 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 100 ns | 50 µA @ 800 V | 800 V | 500mA | -40°C ~ 150°C | 3 V @ 500 mA |
