| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CMS04(TE12L,Q,M)DIODE SCHOTTKY 30V 5A MFLAT |
3,959 | 0.83 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 330pF @ 10V, 1MHz | - | 8 mA @ 30 V | 30 V | 5A | -40°C ~ 125°C | 370 mV @ 5 A | |
|
DSF01S30SL,L3FDIODE SCHOTTKY 30V 100MA SL2 |
15,944 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 9.02pF @ 2V, 1MHz | - | 50 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 500 mV @ 100 mA | |
|
CRS06(TE85L,Q,M)DIODE SCHOTTKY 20V 1A SFLAT |
12,447 | 0.50 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 60pF @ 10V, 1MHz | - | 1 mA @ 20 V | 20 V | 1A | -40°C ~ 125°C | 360 mV @ 1 A | |
|
1SS321,LFSMALL SIGNAL SCHOTTKY BARRIER DI |
4,540 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 3.2pF @ 0V, 1MHz | - | 500 nA @ 10 V | 10 V | 50mA | 125°C (Max) | 1 V @ 50 mA | |
|
CTS520,L3FDIODE SCHOTTKY 30V 200MA CST2 |
232,387 | 0.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 16pF @ 0V, 1MHz | - | 5 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 600 mV @ 200 mA | |
|
CUS08F30,H3FDIODE SCHOTTKY 30V 800MA USC |
358,345 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 170pF @ 0V, 1MHz | - | 50 µA @ 30 V | 30 V | 800mA | 125°C (Max) | 220 mV @ 10 mA | |
|
|
CUS10S30,H3FDIODE SCHOTTKY 30V 1A USC |
2,415 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 135pF @ 0V, 1MHz | - | 500 µA @ 30 V | 30 V | 1A | 125°C (Max) | 230 mV @ 100 mA | |
|
CUHS15S40,H3FSBD SINGLE 40V, 1.5A, IN 2 PIN U |
5,990 | 0.51 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 170pF @ 0V, 1MHz | - | 200 µA @ 40 V | 40 V | 1.5A | 150°C | 510 mV @ 1.5 A | ||
|
CCS15F40,L3FDIODE SCHOTTKY 40V 1.5A CST2C |
21,510 | 0.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 130pF @ 0V, 1MHz | - | 25 µA @ 40 V | 40 V | 1.5A | 150°C (Max) | 640 mV @ 1.5 A | |
.jpg)
|
1SS422(TE85L,F)SMALL-SIGNAL SCHOTTKY BARRIER DI |
22,648 | 0.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 15pF @ 0V, 1MHz | - | 50 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 500 mV @ 100 mA | |
|
|
1SS190TE85LFDIODE GEN PURP 80V 100MA SC59-3 |
18,000 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 4pF @ 0V, 1MHz | 4 ns | 500 nA @ 80 V | 80 V | 100mA | 125°C (Max) | 1.2 V @ 100 mA | |
|
1SS372(TE85L,F)SMALL-SIGNAL SCHOTTKY BARRIER DI |
5,167 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 20pF @ 0V, 1MHz | - | 20 µA @ 10 V | 10 V | 100mA | 125°C (Max) | 500 mV @ 100 mA | |
|
BAS516,L3FDIODE GEN PURP 100V 250MA ESC |
3,621 | 0.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 0.35pF @ 0V, 1MHz | 3 ns | 200 nA @ 80 V | 100 V | 250mA | 150°C (Max) | 1.25 V @ 150 mA | |
|
1SS385FV,L3FSMALL-SIGNAL SCHOTTKY BARRIER DI |
7,560 | 0.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 20pF @ 0V, 1MHz | - | 20 µA @ 10 V | 10 V | 100mA | 125°C (Max) | 500 mV @ 100 mA | |
|
|
CUS357,H3FSMALL SIGNAL SCHOTTKY BARRIER DI |
2,685 | 0.21 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 11pF @ 0V, 1MHz | - | 5 µA @ 40 V | 40 V | 100mA | 125°C (Max) | 600 mV @ 100 mA | |
|
|
CTS521,L3FDIODE SCHOTTKY 30V 200MA CST2 |
10,008 | 0.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 25pF @ 0V, 1MHz | - | 30 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 500 mV @ 200 mA | |
|
|
CUS520,H3FDIODE SCHOTTKY 30V 200MA |
2,268 | 0.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 17pF @ 0V, 1MHz | - | 5 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 280 mV @ 10 mA | |
|
1SS405,H3FDIODE SCHOTTKY 20V 50MA ESC |
11,993 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 3.9pF @ 0V, 1MHz | - | 500 nA @ 20 V | 20 V | 50mA | 125°C (Max) | 550 mV @ 50 mA | |
|
CUS551V30,H3FDIODE SCHOTTKY 30V 500MA USC |
2,793 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 100 µA @ 20 V | 30 V | 500mA | 125°C (Max) | 470 mV @ 500 mA | |
|
1SS417CT,L3FDIODE SCHOTTKY 40V 100MA FSC |
7,177 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 15pF @ 0V, 1MHz | - | 5 µA @ 40 V | 40 V | 100mA | 125°C (Max) | 620 mV @ 100 mA |
