| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1SS424(TPL3,F)DIODE SCHOTTKY 20V 200MA SSM |
3,610 | 0.23 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 20pF @ 0V, 1MHz | - | 50 µA @ 20 V | 20 V | 200mA | 125°C (Max) | 500 mV @ 200 mA | |
|
|
1SS387,L3FDIODE GEN PURP 80V 100MA ESC |
3,644 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 3pF @ 0V, 1MHz | 4 ns | 500 nA @ 80 V | 80 V | 100mA | 125°C (Max) | 1.2 V @ 100 mA | |
|
1SS416,L3MDIODE SCHOTTKY 30V 100MA SOD923 |
10,000 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 15pF @ 0V, 1MHz | - | 50 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 500 mV @ 100 mA | |
|
1SS413,L3MDIODE SCHOTTKY 20V 50MA FSC |
2,038 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 3.9pF @ 0V, 1MHz | - | 500 nA @ 20 V | 20 V | 50mA | 125°C (Max) | 550 mV @ 50 mA | |
|
1SS427,L3MDIODE GEN PURP 80V 100MA SOD923 |
30,000 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 0.3pF @ 0V, 1MHz | 1.6 ns | 500 nA @ 80 V | 80 V | 100mA | -55°C ~ 150°C | 1.2 V @ 100 mA | |
|
1SS401(TE85L,F)DIODE SCHOTTKY 20V 300MA SC70 |
2,184 | 0.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 46pF @ 0V, 1MHz | - | 50 µA @ 20 V | 20 V | 300mA | 125°C (Max) | 450 mV @ 300 mA | |
|
1SS403E,L3FSINGLE SWITCHING DIODE 200V 0.1A |
3,992 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 3pF @ 0V, 1MHz | 60 ns | 1 µA @ 200 V | 200 V | 100mA | 150°C (Max) | 1.2 V @ 100 mA | |
|
1SS322(TE85L,F)SMALL-SIGNAL SCHOTTKY BARRIER DI |
3,598 | 0.30 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 18pF @ 0V, 1MHz | - | 5 µA @ 40 V | 40 V | 100mA | 125°C (Max) | 600 mV @ 100 mA | |
|
CUS05S30,H3FDIODE SCHOTTKY 30V 500MA USC |
2,938 | 0.33 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 55pF @ 0V, 1MHz | - | 150 µA @ 10 V | 30 V | 500mA | 125°C (Max) | 340 mV @ 100 mA | |
|
1SS413CT,L3FDIODE SCHOTTKY 20V 50MA SOD882 |
2,651 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 3.9pF @ 0V, 1MHz | - | 500 nA @ 20 V | 20 V | 50mA | -55°C ~ 125°C | 550 mV @ 50 mA | |
|
|
CUS05S40,H3FDIODE SCHOTTKY 40V 500MA USC |
3,093 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 42pF @ 0V, 1MHz | - | 30 µA @ 10 V | 40 V | 500mA | 125°C (Max) | 350 mV @ 100 mA | |
|
|
CTS05S40,L3FDIODE SCHOTTKY 40V 500MA CST2 |
3,886 | 0.36 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 42pF @ 0V, 1MHz | - | 30 µA @ 10 V | 40 V | 500mA | 125°C (Max) | 350 mV @ 100 mA | |
|
CMF05(TE12L,Q,M)DIODE GEN PURP 1KV 500MA MFLAT |
3,560 | 0.56 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 100 ns | 50 µA @ 800 V | 1000 V | 500mA | -40°C ~ 125°C | 2.7 V @ 500 mA | |
|
CMS11(TE12L,Q,M)DIODE SCHOTTKY 40V 2A MFLAT |
3,163 | 0.64 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 95pF @ 10V, 1MHz | - | 500 µA @ 40 V | 40 V | 2A | -40°C ~ 150°C | 550 mV @ 2 A | |
|
|
CMS05(TE12L,Q,M)DIODE SCHOTTKY 30V 5A MFLAT |
3,076 | 0.83 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 330pF @ 10V, 1MHz | - | 800 µA @ 30 V | 30 V | 5A | -40°C ~ 150°C | 450 mV @ 5 A | |
|
TRS2E65F,S1QPB-F DIODE TO-220-2L IF=2A VRRM= |
3,981 | 1.13 |
RFQ |
Tube | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 8.7pF @ 650V, 1MHz | 0 ns | 20 µA @ 650 V | 650 V | 2A (DC) | 175°C (Max) | 1.6 V @ 2 A | ||
|
|
TRS6E65F,S1QDODE SCHOTTKY 650V TO220 |
2,670 | 2.98 |
RFQ |
Datasheet |
Tube | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 22pF @ 650V, 1MHz | 0 ns | 30 µA @ 650 V | 650 V | 6A (DC) | 175°C (Max) | 1.6 V @ 6 A | |
|
1SS187,LFDIODE GEN PURP 80V 100MA S-MINI |
3,252 | 0.04 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 4pF @ 0V, 1MHz | 4 ns | 500 nA @ 80 V | 80 V | 100mA | 125°C (Max) | 1.2 V @ 100 mA | |
|
CTS05F40,L3FDIODE SCHOTTKY 40V 500MA CST2 |
2,522 | 0.04 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 28pF @ 0V, 1MHz | - | 15 µA @ 40 V | 40 V | 500mA | 150°C (Max) | 810 mV @ 500 mA | |
|
|
TRS10E65F,S1QDODE SCHOTTKY 650V TO220 |
2,123 | 4.90 |
RFQ |
Datasheet |
Tube | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 36pF @ 650V, 1MHz | 0 ns | 50 µA @ 650 V | 650 V | 10A (DC) | 175°C (Max) | 1.6 V @ 10 A |
