| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ALS70A512MF400CAP ALUM 5100UF 20% 400V SCREW |
2,696 | 61.12 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 5100 µF | ±20% | 400 V | 36mOhm @ 100Hz | 19000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 14 A @ 100 Hz | 22.7 A @ 10 kHz | 22 mOhms | 1.122 (28.50mm) | 2.598 Dia (66.00mm) | 4.213 (107.00mm) | - | Chassis Mount |
|
|
ALS70A332MF500CAP ALUM 3300UF 20% 500V SCREW |
2,053 | 63.60 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 3300 µF | ±20% | 500 V | 77mOhm @ 100Hz | 19000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 12.3 A @ 100 Hz | 19.7 A @ 10 kHz | 58 mOhms | 1.122 (28.50mm) | 2.598 Dia (66.00mm) | 4.213 (107.00mm) | - | Chassis Mount |
|
|
ALS70A274NF040CAP ALUM 270000UF 20% 40V SCREW |
2,820 | 71.67 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 270000 µF | ±20% | 40 V | 9mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 27.8 A @ 100 Hz | 28.8 A @ 10 kHz | 10 mOhms | 1.252 (31.80mm) | 3.031 Dia (77.00mm) | 4.213 (107.00mm) | - | Chassis Mount |
|
ALS31A472NP400CAP ALUM 4700UF 20% 400V SCREW |
3,683 | 82.22 |
RFQ |
Datasheet |
Bulk | ALS31 | Active | 4700 µF | ±20% | 400 V | 33mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 18 A @ 100 Hz | 26 A @ 10 kHz | 24 mOhms | 1.252 (31.80mm) | 3.032 Dia (77.00mm) | 5.827 (148.00mm) | - | Chassis Mount |
|
EDH108M035S9TAACAP ALUM 1000UF 20% 35V SMD |
251 | 3.47 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDH | Active | 1000 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 800 mA @ 120 Hz | 1 A @ 10 kHz | - | - | 0.630 Dia (16.00mm) | 0.689 (17.50mm) | 0.642 L x 0.642 W (16.30mm x 16.30mm) | Surface Mount |
|
ELH478M035AQ2AACAP ALUM 4700UF 20% 35V SNAP |
139 | 2.67 |
RFQ |
Datasheet |
Box | ELH | Active | 4700 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.4 A @ 120 Hz | 2.784 A @ 10 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
ELG107M400AQ3AACAP ALUM 100UF 20% 400V SNAP |
3,214 | 3.52 |
RFQ |
Datasheet |
Bulk | ELG | Active | 100 µF | ±20% | 400 V | 582mOhm @ 20kHz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 650 mA @ 120 Hz | 942.5 mA @ 10 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
ELG108M100AR2AACAP ALUM 1000UF 20% 100V SNAP |
291 | 3.69 |
RFQ |
Datasheet |
Bulk | ELG | Active | 1000 µF | ±20% | 100 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.5 A @ 120 Hz | 1.74 A @ 10 kHz | - | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
ELH107M400AR1AACAP ALUM 100UF 20% 400V SNAP |
241 | 4.03 |
RFQ |
Datasheet |
Bulk | ELH | Active | 100 µF | ±20% | 400 V | 592mOhm @ 20kHz | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 900 mA @ 120 Hz | 1.305 A @ 10 kHz | - | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
|
ELH108M200AR6AACAP ALUM 1000UF 20% 200V SNAP |
100 | 5.57 |
RFQ |
Datasheet |
Bulk | ELH | Active | 1000 µF | ±20% | 200 V | - | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 3 A @ 120 Hz | 4.5 A @ 10 kHz | - | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
ALP22A472AB040CAP ALUM 4700UF 20% 40V SLD LUG |
2,399 | 6.34 |
RFQ |
Datasheet |
Box | ALP22 | Active | 4700 µF | ±20% | 40 V | - | 12000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.850 (47.00mm) | - | Through Hole |
|
ELH687M400AT4AACAP ALUM 680UF 20% 400V SNAP |
2,895 | 6.98 |
RFQ |
Datasheet |
Bulk | ELH | Active | 680 µF | ±20% | 400 V | - | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
160MS12AAMK1STDCAP ALUM 160UF 10% 120V QC TERM |
2,701 | 9.41 |
RFQ |
Datasheet |
Box | MS | Active | 160 µF | ±10% | 120 V | - | 500 Hrs @ 60°C | -20°C ~ 60°C | - | - | Motor Start | - | - | - | - | 1.535 Dia (39.00mm) | 2.953 (75.00mm) | - | Chassis Mount |
|
ALF70C432DD100CAP ALUM 4300UF 20% 100V SNAP |
2,406 | 10.51 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 4300 µF | ±20% | 100 V | 66mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 5.63 A @ 100 Hz | 7.3 A @ 10 kHz | 53 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole, Press-Fit |
|
|
ALF70C102DD250CAP ALUM 1000UF 20% 250V SNAP |
2,325 | 10.98 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 1000 µF | ±20% | 250 V | 188mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 3.09 A @ 100 Hz | 6.12 A @ 10 kHz | 111 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole, Press-Fit |
|
|
ALF70C391DD450CAP ALUM 390UF 20% 450V SNAP |
3,318 | 11.18 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 390 µF | ±20% | 450 V | 361mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.21 A @ 100 Hz | 5.22 A @ 10 kHz | 203 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole, Press-Fit |
|
|
ALF70C182DF200CAP ALUM 1800UF 20% 200V SNAP |
100 | 11.27 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 1800 µF | ±20% | 200 V | 127mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.11 A @ 100 Hz | 7.42 A @ 10 kHz | 81 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole, Press-Fit |
|
|
ALF70C511DD400CAP ALUM 510UF 20% 400V SNAP |
3,644 | 11.53 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 510 µF | ±20% | 400 V | 272mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.46 A @ 100 Hz | 5.74 A @ 10 kHz | 145 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole, Press-Fit |
|
ALC10A121CC550CAP ALUM 120UF 20% 550V SNAP |
2,997 | 12.96 |
RFQ |
Datasheet |
Bulk | ALC10 | Active | 120 µF | ±20% | 550 V | 2.874Ohm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.14 A @ 100 Hz | 1.86 A @ 10 kHz | 2.506 Ohms | 0.394 (10.00mm) | 1.181 Dia (30.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
ALS30A101DA500CAP ALUM 100UF 20% 500V SCREW |
2,411 | 13.66 |
RFQ |
Datasheet |
Box | ALS30 | Active | 100 µF | ±20% | 500 V | 1.385Ohm @ 100Hz | 11000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 1.6 A @ 100 Hz | 2.9 A @ 10 kHz | 847 mOhms | 0.504 (12.80mm) | 1.417 Dia (36.00mm) | 2.047 (52.00mm) | - | Chassis Mount |
