| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TK14A65W,S5XMOSFET N-CH 650V 13.7A TO220SIS |
3,770 | 2.96 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 13.7A (Ta) | 10V | 250mOhm @ 6.9A, 10V | 3.5V @ 690µA | 35 nC @ 10 V | ±30V | 1300 pF @ 300 V | - | 40W (Tc) | 150°C (TJ) | Through Hole |
|
TK16E60W5,S1VXMOSFET N-CH 600V 15.8A TO220 |
3,792 | 2.97 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 15.8A (Ta) | 10V | 230mOhm @ 7.9A, 10V | 4.5V @ 790µA | 43 nC @ 10 V | ±30V | 1350 pF @ 300 V | - | 130W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK3R2A10PL,S4XX35 PB-F POWER MOSFET TRANSISTOR |
2,325 | 3.08 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 100A (Tc) | 4.5V, 10V | 3.2mOhm @ 50A, 10V | 2.5V @ 1mA | 161 nC @ 10 V | ±20V | 9500 pF @ 50 V | - | 54W (Tc) | 175°C | Through Hole |
|
|
TK20A60W,S5VXMOSFET N-CH 600V 20A TO220SIS |
3,251 | 3.12 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Ta) | 10V | 155mOhm @ 10A, 10V | 3.7V @ 1mA | 48 nC @ 10 V | ±30V | 1680 pF @ 300 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK3R9E10PL,S1XX35 PB-F POWER MOSFET TRANSISTOR |
3,714 | 2.24 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 100A (Tc) | 4.5V, 10V | 3.9mOhm @ 50A, 10V | 2.5V @ 1mA | 96 nC @ 10 V | ±20V | 6320 pF @ 50 V | - | 230W (Tc) | 175°C | Through Hole |
|
TK17A65W,S5XX35 PB-F POWER MOSFET TRANSISTOR |
2,818 | 3.12 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 17.3A (Ta) | 10V | 200mOhm @ 8.7A, 10V | 3.5V @ 900µA | 45 nC @ 10 V | ±30V | 1800 pF @ 300 V | - | 45W (Tc) | 150°C | Through Hole |
|
|
TK14E65W5,S1XMOSFET N-CH 650V 13.7A TO220 |
2,869 | 3.20 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 13.7A (Ta) | 10V | 300mOhm @ 6.9A, 10V | 4.5V @ 690µA | 40 nC @ 10 V | ±30V | 1300 pF @ 300 V | - | 130W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK12A80W,S4XMOSFET N-CH 800V 11.5A TO220SIS |
3,056 | 3.26 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 11.5A (Ta) | 10V | 450mOhm @ 5.8A, 10V | 4V @ 570µA | 23 nC @ 10 V | ±20V | 1400 pF @ 300 V | - | 45W (Tc) | 150°C | Through Hole |
|
|
TK17A80W,S4XMOSFET N-CH 800V 17A TO220SIS |
2,675 | 4.02 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 17A (Ta) | 10V | 290mOhm @ 8.5A, 10V | 4V @ 850µA | 32 nC @ 10 V | ±20V | 2050 pF @ 300 V | - | 45W (Tc) | 150°C | Through Hole |
|
|
TK100A06N1,S4XMOSFET N-CH 60V 100A TO220SIS |
3,401 | 2.87 |
RFQ |
Datasheet |
Tube | U-MOSVIII-H | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 100A (Tc) | 10V | 2.7mOhm @ 50A, 10V | 4V @ 1mA | 140 nC @ 10 V | ±20V | 10500 pF @ 30 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK10E60W,S1VXMOSFET N-CH 600V 9.7A TO220 |
2,204 | 2.92 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 9.7A (Ta) | 10V | 380mOhm @ 4.9A, 10V | 3.7V @ 500µA | 20 nC @ 10 V | ±30V | 700 pF @ 300 V | Super Junction | 100W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK100A10N1,S4XMOSFET N-CH 100V 100A TO220SIS |
3,287 | 4.17 |
RFQ |
Datasheet |
Tube | U-MOSVIII-H | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 100A (Tc) | 10V | 3.8mOhm @ 50A, 10V | 4V @ 1mA | 140 nC @ 10 V | ±20V | 8800 pF @ 50 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK25E60X,S1XMOSFET N-CH 600V 25A TO220 |
3,839 | 4.20 |
RFQ |
Datasheet |
Tube | DTMOSIV-H | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Ta) | 10V | 125mOhm @ 7.5A, 10V | 3.5V @ 1.2mA | 40 nC @ 10 V | ±30V | 2400 pF @ 300 V | - | 180W (Tc) | 150°C (TJ) | Through Hole |
|
TK16A60W,S4VXMOSFET N-CH 600V 15.8A TO220SIS |
3,573 | 3.11 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 15.8A (Ta) | 10V | 190mOhm @ 7.9A, 10V | 3.7V @ 790µA | 38 nC @ 10 V | ±30V | 1350 pF @ 300 V | Super Junction | 40W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK72A12N1,S4XMOSFET N-CH 120V 72A TO220SIS |
2,865 | 3.15 |
RFQ |
Datasheet |
Tube | U-MOSVIII-H | Active | N-Channel | MOSFET (Metal Oxide) | 120 V | 72A (Tc) | 10V | 4.5mOhm @ 36A, 10V | 4V @ 1mA | 130 nC @ 10 V | ±20V | 8100 pF @ 60 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK17A65W5,S5XX35 PB-F POWER MOSFET TRANSISTOR |
3,474 | 3.29 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 17.3A (Ta) | 10V | 230mOhm @ 8.7A, 10V | 4.5V @ 900µA | 50 nC @ 10 V | ±30V | 1800 pF @ 300 V | - | 45W (Tc) | 150°C | Through Hole |
|
|
TK25A60X5,S5XMOSFET N-CH 600V 25A TO220SIS |
2,622 | 4.83 |
RFQ |
Datasheet |
Tube | DTMOSIV-H | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Ta) | 10V | 140mOhm @ 7.5A, 10V | 4.5V @ 1.2mA | 60 nC @ 10 V | ±30V | 2400 pF @ 300 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
TK20N60W5,S1VFMOSFET N-CH 600V 20A TO247 |
3,209 | 3.74 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Ta) | 10V | 175mOhm @ 10A, 10V | 4.5V @ 1mA | 55 nC @ 10 V | ±30V | 1800 pF @ 300 V | - | 165W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK16N60W,S1VFMOSFET N CH 600V 15.8A TO247 |
2,649 | 3.99 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 15.8A (Ta) | 10V | 190mOhm @ 7.9A, 10V | 3.7V @ 790µA | 38 nC @ 10 V | ±30V | 1350 pF @ 300 V | Super Junction | 130W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK14N65W5,S1FMOSFET N-CH 650V 13.7A TO247 |
2,554 | 4.10 |
RFQ |
Datasheet |
Tube | DTMOSIV | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 13.7A (Ta) | 10V | 300mOhm @ 6.9A, 10V | 4.5V @ 690µA | 40 nC @ 10 V | ±30V | 1300 pF @ 300 V | - | 130W (Tc) | 150°C (TJ) | Through Hole |
