Diodes - Bridge Rectifiers(9417)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeType | Technology | Voltage-PeakReverse(Max) | Current-AverageRectified(Io) | Voltage-Forward(Vf)(Max)@If | Current-ReverseLeakage@Vr | OperatingTemperature | MountingType | VRRM(V) | I(AV)(A) | IFSM(A) | VF@IF(V) | VF@IF(A) | IR(μA) | Trr(ns) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
GBU4B-T1BRect, 100V, 4A |
3,944 | 1.52 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 100 V | 2.8 A | 1 V @ 4 A | 5 µA @ 100 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU4K-T1BRect, 800V, 4A |
2,389 | 1.52 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 800 V | 2.8 A | 1 V @ 4 A | 5 µA @ 800 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU4A1BRect, 50V, 4A |
2,112 | 1.52 |
RFQ |
Datasheet |
Box | - | Active | Single Phase | Standard | 50 V | 2.8 A | 1 V @ 4 A | 5 µA @ 50 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU4A-T1BRect, 50V, 4A |
3,396 | 1.52 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 50 V | 2.8 A | 1 V @ 4 A | 5 µA @ 50 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU4J-T1BRect, 600V, 4A |
2,643 | 1.52 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 600 V | 2.8 A | 1 V @ 4 A | 5 µA @ 600 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
RS2505M-C-LVBDGE RCT GLASS 600V LV 25A RS25M |
3,027 | 1.55 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 600 V | 25 A | 920 mV @ 12.5 A | 5 µA @ 600 V | 150°C (TJ) | Through Hole | 4-SIP, RS-25M | ||||||
|
|
GBU6K-T1BRect, 800V, 6A |
3,206 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 800 V | 4.2 A | 1 V @ 6 A | 5 µA @ 800 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6B1BRect, 100V, 6A |
2,949 | 1.58 |
RFQ |
Datasheet |
Box | - | Active | Single Phase | Standard | 100 V | 4.2 A | 1 V @ 6 A | 5 µA @ 100 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6G-T1BRect, 400V, 6A |
3,129 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 400 V | 4.2 A | 1 V @ 6 A | 5 µA @ 400 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6B-T1BRect, 100V, 6A |
2,795 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 100 V | 4.2 A | 1 V @ 6 A | 5 µA @ 100 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6A-T1BRect, 50V, 6A |
2,590 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 50 V | 4.2 A | 1 V @ 6 A | 5 µA @ 50 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6J-T1BRect, 600V, 6A |
2,566 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 600 V | 4.2 A | 1 V @ 6 A | 5 µA @ 600 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6M-T1BRect, 1000V, 6A |
3,059 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 1 kV | 4.2 A | 1 V @ 6 A | 5 µA @ 1000 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6D-T1BRect, 200V, 6A |
3,597 | 1.58 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 200 V | 4.2 A | 1 V @ 6 A | 5 µA @ 200 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
|
GBU6J1BRect, 600V, 6A |
2,808 | 1.58 |
RFQ |
Datasheet |
Box | - | Active | Single Phase | Standard | 600 V | 4.2 A | 1 V @ 6 A | 5 µA @ 600 V | -50°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBU | ||||||
|
GBU2508RECT BRIDGE 800V 25A GBU |
3,248 | 1.62 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 800 V | 25 A | 1 V @ 12.5 A | 5 µA @ 800 V | -55°C ~ 150°C (TJ) | Through Hole | 4-ESIP, GBU | ||||||
|
|
GBU2510RECT BRIDGE 1000V 25A GBU |
3,818 | 1.62 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 1 kV | 25 A | 1 V @ 12.5 A | 5 µA @ 1000 V | -55°C ~ 150°C (TJ) | Through Hole | 4-ESIP, GBU | ||||||
|
GBL606GLASS PASSIVATED BRIDGE RECTIFIE |
3,849 | 1.08 |
RFQ |
Tube | GBL | Active | Single Phase | Standard | 600 V | 6 A | 1 V @ 3 A | 10 µA @ 600 V | -55°C ~ 150°C (TJ) | Through Hole | 4-SIP, GBJ | |||||||
|
|
GBU1510ARECT BRIDGE 1000V 15A GBU |
3,345 | 1.67 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 1 kV | 15 A | 1 V @ 7.5 A | 5 µA @ 1000 V | -55°C ~ 150°C (TJ) | Through Hole | 4-ESIP, GBU | ||||||
|
|
RS2508MBRIDGE REC GLASS 1200V 25A RS25M |
3,271 | 1.70 |
RFQ |
Datasheet |
Tube | - | Active | Single Phase | Standard | 1.2 kV | 25 A | 1.05 V @ 12.5 A | 500 nA @ 1200 V | 150°C (TJ) | Through Hole | 4-SIP, RS-25M |
