| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ALS70A103NT500CAP ALUM 10000UF 20% 500V SCREW |
3,065 | 135.76 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 10000 µF | ±20% | 500 V | 30mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 21.4 A @ 100 Hz | 28.7 A @ 10 kHz | 24 mOhms | 1.252 (31.80mm) | 3.031 Dia (77.00mm) | 8.740 (222.00mm) | - | Chassis Mount |
|
|
ALS70A133QT500CAP ALUM 13000UF 20% 500V SCREW |
3,685 | 167.91 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 13000 µF | ±20% | 500 V | 23mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 26.5 A @ 100 Hz | 35.5 A @ 10 kHz | 18 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 8.740 (222.00mm) | - | Chassis Mount |
|
EDK106M035A9BAACAP ALUM 10UF 20% 35V SMD |
69,909 | 0.28 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDK | Active | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 24 mA @ 120 Hz | 30 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.222 (5.65mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EDK476M016A9DAACAP ALUM 47UF 20% 16V SMD |
2,997 | 0.33 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDK | Active | 47 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 45 mA @ 120 Hz | 56.25 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.222 (5.65mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
ELH476M450AQ1AACAP ALUM 47UF 20% 450V SNAP |
3,924 | 4.25 |
RFQ |
Datasheet |
Bulk | ELH | Active | 47 µF | ±20% | 450 V | 1.46Ohm @ 20kHz | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 500 mA @ 120 Hz | 725 mA @ 10 kHz | - | 0.394 (10.00mm) | 0.866 Dia (22.00mm) | 1.063 (27.00mm) | - | Through Hole |
|
EDH107M025A9HAACAP ALUM 100UF 20% 25V SMD |
484 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDH | Active | 100 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 100 mA @ 120 Hz | 125 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ALC70A103CF063CAP ALUM 10000UF 20% 63V SNAP |
3,584 | 10.20 |
RFQ |
Datasheet |
Bulk | ALC70 | Active | 10000 µF | ±20% | 63 V | 40mOhm @ 100Hz | 13000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 6.85 A @ 100 Hz | 9.4 A @ 10 kHz | 30 mOhms | 0.394 (10.00mm) | 1.181 Dia (30.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
ALF70C133DF063CAP ALUM 13000UF 20% 63V SNAP |
3,845 | 10.85 |
RFQ |
Datasheet |
Bulk | ALF70 | Active | 13000 µF | ±20% | 63 V | 34mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 7.82 A @ 100 Hz | 10.03 A @ 10 kHz | 26 mOhms | 0.886 (22.50mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole, Press-Fit |
|
ALC10A331DD450CAP ALUM 330UF 20% 450V SNAP |
3,113 | 11.31 |
RFQ |
Datasheet |
Bulk | ALC10 | Active | 330 µF | ±20% | 450 V | 364mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.2 A @ 100 Hz | 3.68 A @ 10 kHz | 242 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
ALC70A681DF400CAP ALUM 680UF 20% 400V SNAP |
2,984 | 11.74 |
RFQ |
Datasheet |
Bulk | ALC70 | Active | 680 µF | ±20% | 400 V | 205mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.99 A @ 100 Hz | 6.92 A @ 10 kHz | 109 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
|
ALC70A221DE630CAP ALUM 220UF 20% 630V SNAP |
3,563 | 11.89 |
RFQ |
Datasheet |
Bulk | ALC70 | Active | 220 µF | ±20% | 630 V | 596mOhm @ 100Hz | 15000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.04 A @ 100 Hz | 4.4 A @ 10 kHz | 410 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.850 (47.00mm) | - | Through Hole |
|
|
ALC40A331DF450CAP ALUM 330UF 20% 450V SNAP |
2,530 | 14.08 |
RFQ |
Datasheet |
Bulk | ALC40 | Active | 330 µF | ±20% | 450 V | 206mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.53 A @ 100 Hz | 5.14 A @ 10 kHz | 198 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.047 (52.00mm) | - | Through Hole |
|
ESL107M016AC3AACAP ALUM 100UF 20% 16V RADIAL |
3,466 | 0.25 |
RFQ |
Datasheet |
Bulk | ESL | Active | 100 µF | ±20% | 16 V | 230mOhm @ 100kHz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 172.5 mA @ 120 Hz | 345 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
PEH532RDH4220M2CAP ALUM 2200UF 20% 200V SNAP |
2,032 | 16.30 |
RFQ |
Datasheet |
Box | PEH532 | Active | 2200 µF | ±20% | 200 V | 67mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.1 A @ 100 Hz | 8.7 A @ 20 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.165 (55.00mm) | - | Through Hole |
|
ALC40A471DH450CAP ALUM 470UF 20% 450V SNAP |
2,267 | 17.37 |
RFQ |
Datasheet |
Bulk | ALC40 | Active | 470 µF | ±20% | 450 V | 232mOhm @ 100Hz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3 A @ 100 Hz | 5.82 A @ 10 kHz | 138 mOhms | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 2.441 (62.00mm) | - | Through Hole |
|
ALC10C102EL450CAP ALUM 1000UF 20% 450V SNAP |
2,522 | 20.36 |
RFQ |
Datasheet |
Box | ALC10 | Active | 1000 µF | ±20% | 450 V | 114mOhm @ 100Hz | 18000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.95 A @ 100 Hz | 9.32 A @ 10 kHz | 75 mOhms | 0.886 (22.50mm) | 1.575 Dia (40.00mm) | 3.228 (82.00mm) | - | Through Hole |
|
ESL107M035AE3AACAP ALUM 100UF 20% 35V RADIAL |
3,295 | 0.29 |
RFQ |
Datasheet |
Bulk | ESL | Active | 100 µF | ±20% | 35 V | 85mOhm @ 100kHz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 272.5 mA @ 120 Hz | 545 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EDH476M100A9PAACAP ALUM 47UF 20% 100V SMD |
2,212 | 0.84 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDH | Active | 47 µF | ±20% | 100 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 170 mA @ 120 Hz | 212.5 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
|
EDH107M063A9PAACAP ALUM 100UF 20% 63V SMD |
2,410 | 0.89 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDH | Active | 100 µF | ±20% | 63 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 340 mA @ 120 Hz | 425 mA @ 10 kHz | - | - | 0.394 Dia (10.00mm) | 0.413 (10.50mm) | 0.406 L x 0.406 W (10.30mm x 10.30mm) | Surface Mount |
|
ALS70A562QW630CAP ALUM 5600UF 20% 630V SCREW |
2,244 | 163.04 |
RFQ |
Datasheet |
Bulk | ALS70 | Active | 5600 µF | ±20% | 630 V | 31mOhm @ 100Hz | 20000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 21.5 A @ 100 Hz | 33.3 A @ 10 kHz | 21 mOhms | 1.252 (31.80mm) | 3.543 Dia (90.00mm) | 6.654 (169.00mm) | - | Chassis Mount |
