| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | UnidirectionalChannels | BidirectionalChannels | Voltage-ReverseStandoff(Typ) | Voltage-Breakdown(Min) | Voltage-Clamping(Max)@Ipp | Current-PeakPulse(10/1000µs) | Power-PeakPulse | PowerLineProtection | Applications | Capacitance@Frequency | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RCLAMP2574NQTCTTVS DIODE 2.5VWM 20VC SLP3020N10 |
732 | 2.21 |
RFQ |
Datasheet |
10-UDFN Exposed Pad | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, RailClamp® | Active | Steering (Rail to Rail) | 8 | - | 2.5V (Max) | 2.7V | 20V | 40A (8/20µs) | 1000W (1kW) | Yes | Automotive, Ethernet | 3.75pF @ 1MHz | -40°C ~ 125°C (TJ) | Surface Mount |
|
SMDA15.TBTTVS DIODE 15VWM 30VC 8-SO |
497 | 2.77 |
RFQ |
Datasheet |
8-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT) | SMDA | Obsolete | Zener | 4 | - | 15V (Max) | 16.7V | 30V | 10A (8/20µs) | 300W | No | General Purpose | 100pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
UCLAMP3301P.TCTTVS DIODE 3.3VWM 8VC SLP1006P2 |
674 | 0.68 |
RFQ |
Datasheet |
2-UDFN | Tape & Reel (TR),Cut Tape (CT) | uClamp® | Active | Zener | 1 | - | 3.3V (Max) | 3.5V | 8V | 5A (8/20µs) | 40W | No | General Purpose | 25pF @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
SM712.TCTTVS DIODE 12V/7V 26V/12V SOT23-3 |
3,545 | 1.65 |
RFQ |
Datasheet |
TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR),Cut Tape (CT) | - | Active | Zener | - | 2 | 12V (Max), 7V (Max) | 13.3V, 7.5V | 26V, 12V | 17A (8/20µs) | 400W | No | RS-485 | 75pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
|
UCLAMP0301PQTNTTVS DIODE 3VWM 8VC SLP1006P2 |
2,135 | 0.68 |
RFQ |
Datasheet |
2-UDFN | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, uClamp® | Active | Zener | 1 | - | 3V (Max) | 3.1V | 8V | 5A (8/20µs) | 40W | No | Automotive | 25pF @ 1MHz | -40°C ~ 85°C (TJ) | Surface Mount |
|
SMF05.TCTTVS DIODE 5VWM 12.5VC SC70-5 |
2,108 | 0.71 |
RFQ |
Datasheet |
5-TSSOP, SC-70-5, SOT-353 | Tape & Reel (TR),Cut Tape (CT) | SMF | Active | Zener | 4 | - | 5V (Max) | 6V | 12.5V | 12A (8/20µs) | 200W | No | General Purpose | 150pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
SMDA24C-8.TBTTVS DIODE 24VWM 43VC 14SO |
2,280 | 3.10 |
RFQ |
Datasheet |
14-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT) | SMDAC-8 | Active | Zener | - | 8 | 24V (Max) | 26.7V | 43V | 5A (8/20µs) | 300W | No | General Purpose | 50pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
RCLAMP0584J.TCTTVS DIODE 5VWM 15VC SLP2710P8 |
3,779 | 1.09 |
RFQ |
Datasheet |
10-UFDFN | Tape & Reel (TR),Cut Tape (CT) | RailClamp® | Active | Steering (Rail to Rail) | 4 | - | 5V (Max) | 6.5V | 15V | 5A (8/20µs) | 75W | Yes | HDMI | 0.45pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
SMS3.3.TCTTVS DIODE 3.3VWM 8.7VC SOT23-6 |
2,152 | 1.16 |
RFQ |
Datasheet |
SOT-23-6 | Tape & Reel (TR),Cut Tape (CT) | SMS | Active | Zener | 4 | - | 3.3V (Max) | 3.5V | 8.7V | 12A (8/20µs) | 200W | No | General Purpose | 35pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
UCLAMP0541Z.TFTTVS DIODE 5VWM 15VC SLP0603P2X3 |
3,378 | 0.39 |
RFQ |
Datasheet |
0201 (0603 Metric) | Tape & Reel (TR),Cut Tape (CT) | uClamp® | Active | Zener | - | 1 | 5V (Max) | 6V | 15V | 2A (8/20µs) | 25W | No | General Purpose | 6.5pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
UCLAMP2671P.TNTTVS DIODE 26VWM 65VC SGP1610N2 |
2,705 | 0.82 |
RFQ |
Datasheet |
2-UDFN | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, uClamp® | Active | Zener | 1 | - | 26V (Max) | 29V | 65V | 23A (8/20µs) | - | No | Automotive | 155pF @ 1MHz | -40°C ~ 125°C (TJ) | Surface Mount |
|
RCLAMP3324PQTCTTVS DIODE 3.3VWM 4.5VC SGP2510P8 |
2,760 | 1.23 |
RFQ |
Datasheet |
10-UFDFN | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, RailClamp® | Active | Steering (Rail to Rail) | 4 | - | 3.3V (Max) | - | 4.5V | 4.5A (8/20µs) | - | No | Automotive, USB | 0.65pF @ 1MHz | -40°C ~ 125°C (TJ) | Surface Mount |
|
|
SMS15C.TCTTVS DIODE 15VWM 29VC SOT23-6 |
3,411 | 1.52 |
RFQ |
Datasheet |
SOT-23-6 | Tape & Reel (TR),Cut Tape (CT) | SMS | Active | Zener | 5 | - | 15V (Max) | 16.7V | 29V | 12A (8/20µs) | 300W | No | General Purpose | 100pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
RCLAMP1502B.TCTTVS DIODE 15VWM 40VC SC75 |
3,095 | 0.90 |
RFQ |
Datasheet |
SC-75, SOT-416 | Tape & Reel (TR),Cut Tape (CT) | RailClamp® | Active | Zener | 2 | 1 | 15V (Max) | 16.7V | 40V | 5A (8/20µs) | 200W | No | General Purpose | 1.5pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
|
SMDA12C-8.TBTTVS DIODE 12VWM 19VC 14SO |
2,357 | 3.29 |
RFQ |
Datasheet |
14-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT) | SMDAC-8 | Active | Zener | - | 8 | 12V (Max) | 13.3V | 19V | 12A (8/20µs) | 300W | No | General Purpose | 120pF @ 1MHz | -55°C ~ 125°C (TJ) | Surface Mount |
|
UCLAMP2482PWQ.C4V ESD AND EOS PROTECTION FOR 2- |
2,377 | 0.52 |
RFQ |
Datasheet |
3-DFN | Tape & Reel (TR),Cut Tape (CT) | µClamp® | Active | Zener | 1 | - | 24V | - | - | 5A (8/20µs) | - | No | Automotive, CAN | - | - | Surface Mount |
|
RCLAMP3391ZCTFT1-LINE 3.3V 0.20PF ESD SLP0603P2 |
3,866 | 0.19 |
RFQ |
Datasheet |
0201 (0603 Metric) | Tape & Reel (TR),Cut Tape (CT) | - | Active | Zener | - | 1 | 3.3V (Max) | 5.5V | 6.5V | 7A (8/20µs) | 45W | No | HDMI, USB | 0.17pF @ 1MHz | -40°C ~ 85°C (TJ) | Surface Mount |
|
RCLAMP0534PWQ.CLOW CAPACITANCE RAILCLAMP 4-LINE |
2,665 | 0.61 |
RFQ |
Datasheet |
10-UFDFN | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, RailClamp® | Active | Steering (Rail to Rail) | 4 | - | 5V | - | - | - | - | No | Automotive, HDMI | - | - | Surface Mount, Wettable Flank |
.jpg)
|
RCLAMP0592PWQ.CLOW CAPACITANCE RAILCLAMP 2-LINE |
3,573 | 0.76 |
RFQ |
Datasheet |
3-DFN | Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q100, RailClamp® | Active | Zener | 2 | - | 5V | - | - | - | - | No | Automotive, Ethernet | - | - | Surface Mount |
.jpg)
|
RCLAMP0594PWQ.CLOW CAPACITANCE RAILCLAMP 4-LINE |
3,717 | 0.79 |
RFQ |
Datasheet |
10-UFDFN | Tape & Reel (TR),Cut Tape (CT) | RailClamp® | Active | Steering (Rail to Rail) | 4 | - | 5V (Max) | 6V | 15V | 6A (8/20µs) | - | No | HDMI | 0.8pF @ 1MHz (Max) | -55°C ~ 150°C (TJ) | Surface Mount |
