| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRLR120NPBFHEXFET POWER MOSFET |
3,303 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 10A (Tc) | 4V, 10V | 185mOhm @ 6A, 10V | 2V @ 250µA | 20 nC @ 5 V | ±16V | 440 pF @ 25 V | - | 48W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
IRFB23N15DPBFIRFB23N15 - SMPS HEXFET POWER MO |
3,048 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 23A (Tc) | 10V | 90mOhm @ 14A, 10V | 5.5V @ 250µA | 56 nC @ 10 V | ±30V | 1200 pF @ 25 V | - | 3.8W (Ta), 136W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRLR7843PBFHEXFET POWER MOSFET |
3,329 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 161A (Tc) | 4.5V, 10V | 3.3mOhm @ 15A, 10V | 2.3V @ 250µA | 50 nC @ 4.5 V | ±20V | 4380 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFR18N15DTRPBFMOSFET N-CH 150V 18A DPAK |
3,504 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 18A (Tc) | - | 125mOhm @ 11A, 10V | 5.5V @ 250µA | 43 nC @ 10 V | ±30V | 900 pF @ 25 V | - | 110W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFR4104PBFHEXFET N-CHANNEL POWER MOSFET |
3,530 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 42A (Tc) | 10V | 5.5mOhm @ 42A, 10V | 4V @ 250µA | 89 nC @ 10 V | ±20V | 2950 pF @ 25 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
IRFS7437-7PPBFMOSFET N-CH 40V 195A D2PAK |
3,138 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 195A (Tc) | - | 1.4mOhm @ 100A, 10V | 3.9V @ 150µA | 225 nC @ 10 V | ±20V | 7437 pF @ 25 V | - | 231W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFS7787PBFMOSFET N-CH 75V 76A TO263-3-2 |
3,103 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 76A (Tc) | - | 8.4mOhm @ 46A, 10V | 3.7V @ 100µA | 109 nC @ 10 V | ±20V | 4020 pF @ 25 V | - | 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
IRFSL3806PBFHEXFET N-CHANNEL POWER MOSFET |
2,097 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 43A (Tc) | 10V | 15.8mOhm @ 25A, 10V | 4V @ 50µA | 30 nC @ 10 V | ±20V | 1150 pF @ 50 V | - | 71W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRF7201PBFHEXFET POWER MOSFET |
2,487 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 7.3A (Tc) | 4.5V, 10V | 30mOhm @ 7.3A, 10V | 1V @ 250µA | 28 nC @ 10 V | ±20V | 550 pF @ 25 V | - | 2.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF7413TRPBFMOSFET N-CH 30V 13A 8SO |
3,622 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | - | 11mOhm @ 7.3A, 10V | 3V @ 250µA | 79 nC @ 10 V | ±20V | 1800 pF @ 25 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7811AVTRPBFSMALL SIGNAL FIELDCHANNEL, SILIC |
2,646 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 10.8A (Ta) | 4.5V | 14mOhm @ 15A, 4.5V | 3V @ 250µA | 26 nC @ 5 V | ±20V | 1801 pF @ 10 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRFR18N15DTRLPHEXFET SMPS POWER MOSFET |
3,890 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 18A (Tc) | - | 125mOhm @ 11A, 10V | 5.5V @ 250µA | 43 nC @ 10 V | - | 900 pF @ 25 V | - | - | - | Surface Mount |
|
|
IRFR6215PBFPFET, 13A I(D), 150V, 0.295OHM |
2,351 | 0.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | P-Channel | MOSFET (Metal Oxide) | 150 V | 13A (Tc) | 10V | 295mOhm @ 6.6A, 10V | 4V @ 250µA | 66 nC @ 10 V | ±20V | 860 pF @ 25 V | - | 110W (Tc) | -55°C ~ 175°C (TJ) | |
|
|
AUIRLR014NMOSFET N-CH 55V 10A DPAK |
3,380 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 10A (Tc) | - | 140mOhm @ 6A, 10V | 3V @ 250µA | 7.9 nC @ 5 V | ±16V | 265 pF @ 25 V | - | 28W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
AUIRLR014NTRLAUTOMOTIVE POWER MOSFET |
2,642 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 10A (Tc) | 4.5V, 10V | 140mOhm @ 6A, 10V | 3V @ 250µA | 7.9 nC @ 5 V | ±16V | 265 pF @ 25 V | - | 28W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF7821PBFHEXFET POWER MOSFET |
3,416 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 13.6A (Ta) | 4.5V, 10V | 9.1mOhm @ 13A, 10V | 1V @ 250µA | 14 nC @ 4.5 V | ±20V | 1010 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 155°C (TJ) | Surface Mount | |
|
|
IRF8736PBFHEXFET POWER MOSFET |
3,876 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A (Ta) | 4.5V, 10V | 4.8mOhm @ 18A, 10V | 2.35V @ 50µA | 26 nC @ 4.5 V | ±20V | 2315 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IRLR3410PBFHEXFET POWER MOSFET |
3,133 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 17A (Tc) | 4V, 10V | 105mOhm @ 10A, 10V | 2V @ 250µA | 34 nC @ 5 V | ±16V | 800 pF @ 25 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
IRF7413ZPBFMOSFET N-CH 30V 13A 8SO |
2,036 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | - | 10mOhm @ 13A, 10V | 2.25V @ 250µA | 14 nC @ 4.5 V | ±20V | 1210 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7476TRPBFHEXFET POWER MOSFET |
2,780 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 12 V | 15A (Ta) | 2.8V, 4.5V | 8mOhm @ 15A, 4.5V | 1.9V @ 250µA | 40 nC @ 4.5 V | ±12V | 2550 pF @ 6 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
