| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IPD50N04S308ATMA1OPTLMOS N-CHANNEL POWER MOSFET |
3,387 | 1.00 |
RFQ |
Bulk | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 50A (Tc) | 10V | 7.5mOhm @ 50A, 10V | 4V @ 40µA | 35 nC @ 10 V | ±20V | 2350 pF @ 25 V | - | 68W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
IRLR3802TRPBFIRLR3802 - HEXFET POWER MOSFET |
3,831 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 12 V | 84A (Tc) | 2.8V, 4.5V | 8.5mOhm @ 15A, 4.5V | 1.9V @ 250µA | 41 nC @ 5 V | ±12V | 2490 pF @ 6 V | - | 88W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFB23N20DPBFSMPS HEXFET POWER MOSFET |
2,759 | 1.00 |
RFQ |
Datasheet |
Tube | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 24A (Tc) | 10V | 100mOhm @ 14A, 10V | 5.5V @ 250µA | 86 nC @ 10 V | ±30V | 1960 pF @ 25 V | - | 3.8W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRLR8729TRLPBFIRLR8729 - 20V-30V N-CHANNEL |
2,305 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 58A (Tc) | 4.5V, 10V | 8.9mOhm @ 25A, 10V | 2.35V @ 25µA | 16 nC @ 4.5 V | ±20V | 1350 pF @ 15 V | - | 55W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRF2804S-7PPFET, 240A I(D), 40V, 0.0016OHM |
3,246 | 0.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 240A (Tc) | 10V | 1.6mOhm @ 160A, 10V | 4V @ 250µA | 260 nC @ 10 V | ±20V | 6930 pF @ 25 V | - | 330W (Tc) | -55°C ~ 175°C (TJ) | |
|
IRFL4315PBFHEXFET POWER MOSFET |
2,838 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 2.6A (Ta) | 10V | 185mOhm @ 1.6A, 10V | 5V @ 250µA | 19 nC @ 10 V | ±30V | 420 pF @ 25 V | - | 2.8W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
AUIRFB3806AUTOMOTIVE N CHANNEL |
2,245 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 43A (Tc) | 10V | 15.8mOhm @ 25A, 10V | 4V @ 50µA | 30 nC @ 10 V | ±20V | 1150 pF @ 50 V | - | 71W (Tc) | -55°C ~ 175°C (TJ) | Through Hole | |
|
|
IRFR3303TRPBFHEXFET N-CHANNEL POWER MOSFET |
2,709 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 33A (Tc) | 10V | 31mOhm @ 18A, 10V | 4V @ 250µA | 29 nC @ 10 V | ±20V | 750 pF @ 25 V | - | 57W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRFS3206TRLAUTOMOTIVE POWER MOSFET |
3,221 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 120A (Tc) | 10V | 3mOhm @ 75A, 10V | 4V @ 150µA | 170 nC @ 10 V | ±20V | 6540 pF @ 50 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRFN8401TRAUTOMOTIVE HEXFET POWER MOSFET |
2,311 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 84A (Tc) | 10V | 4.6mOhm @ 50A, 10V | 3.9V @ 50µA | 66 nC @ 10 V | ±20V | 2170 pF @ 25 V | - | 4.2W (Ta), 63W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRFR825PBFHEXFET N-CHANNEL POWER MOSFET |
3,894 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 6A (Tc) | 10V | 1.3Ohm @ 3.7A, 10V | 5V @ 250µA | 34 nC @ 10 V | ±20V | 1346 pF @ 25 V | - | 119W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFR7540TRLPBFHEXFET POWER MOSFET |
2,537 | 1.00 |
RFQ |
Datasheet |
Tube | HEXFET®, StrongIRFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 90A (Tc) | 6V, 10V | 4.8mOhm @ 66A, 10V | 3.7V @ 100µA | 130 nC @ 10 V | ±20V | 4360 pF @ 25 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF7468TRPBFSMPS HEXFET POWER MOSFET |
2,904 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 9.4A (Ta) | 4.5V, 10V | 15.5mOhm @ 9.4A, 10V | 2V @ 250µA | 34 nC @ 4.5 V | ±12V | 2460 pF @ 20 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IRF7488TRPBFPOWER FIELD-EFFECT TRANSISTOR, 6 |
2,441 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 6.3A (Ta) | 10V | 29mOhm @ 3.8A, 10V | 4V @ 250µA | 57 nC @ 10 V | ±20V | 1680 pF @ 25 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7807VPBFHEXFET POWER MOSFET |
3,492 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8.3A (Ta) | 4.5V | 25mOhm @ 7A, 4.5V | 3V @ 250µA | 14 nC @ 5 V | ±20V | - | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRLU3915PBFIRLU3915 - HEXFET POWER MOSFET |
2,138 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 30A (Tc) | 5V, 10V | 14mOhm @ 30A, 10V | 3V @ 250µA | 92 nC @ 10 V | ±16V | 1870 pF @ 25 V | - | 120W (Tc) | -55°C ~ 175°C (TJ) | Through Hole | |
|
|
IRFPS3810PBFMOSFET N-CH 100V 170A SUPER-247 |
2,214 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 170A (Tc) | - | 9mOhm @ 100A, 10V | 5V @ 250µA | 390 nC @ 10 V | ±30V | 6790 pF @ 25 V | - | 580W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
AUIRFR1010ZAUTOMOTIVE N CHANNEL |
2,656 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 42A (Tc) | - | 7.5mOhm @ 42A, 10V | 4V @ 100µA | 95 nC @ 10 V | - | 2840 pF @ 25 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF1010ZSPBFMOSFET N-CH 55V 75A D2PAK |
2,636 | 1.00 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 75A (Tc) | - | 7.5mOhm @ 75A, 10V | 4V @ 250µA | 95 nC @ 10 V | ±20V | 2840 pF @ 25 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF8707PBFMOSFET N-CH 30V 11A 8SO |
3,156 | 1.00 |
RFQ |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | - | 11.9mOhm @ 11A, 10V | 2.35V @ 25µA | 9.3 nC @ 4.5 V | ±20V | 760 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
