| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRFP26N60LPBFMOSFET N-CH 600V 26A TO247-3 |
1,986 | 10.47 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 26A (Tc) | 10V | 250mOhm @ 16A, 10V | 5V @ 250µA | 180 nC @ 10 V | ±30V | 5020 pF @ 25 V | - | 470W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHG100N60E-GE3MOSFET N-CH 600V 30A TO247AC |
392 | 6.87 |
RFQ |
Datasheet |
Tube | E | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 30A (Tc) | 10V | 100mOhm @ 13A, 10V | 5V @ 250µA | 50 nC @ 10 V | ±30V | 1851 pF @ 100 V | - | 208W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHG039N60E-GE3MOSFET N-CH 600V 63A TO247AC |
406 | 11.67 |
RFQ |
Datasheet |
Tube | E | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 63A (Tc) | 10V | 39mOhm @ 32A, 10V | 5V @ 250µA | 126 nC @ 10 V | ±30V | 4369 pF @ 100 V | - | 357W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
SI4103DY-T1-GE3MOSFET P-CH 30V 14A/16A 8SO |
3,481 | 0.81 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® Gen III | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 14A (Ta), 16A (Tc) | 4.5V, 10V | 7.9mOhm @ 10A, 10V | 2V @ 250µA | 140 nC @ 10 V | ±20V | 5200 pF @ 15 V | - | 2.5W (Ta), 5.2W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI4634DY-T1-E3MOSFET N-CH 30V 24.5A 8SO |
5,000 | 1.85 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 24.5A (Tc) | 4.5V, 10V | 5.2mOhm @ 15A, 10V | 2.6V @ 250µA | 68 nC @ 10 V | ±20V | 3150 pF @ 15 V | - | 2.5W (Ta), 5.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRFR420PBFMOSFET N-CH 500V 2.4A DPAK |
2,996 | 1.35 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 2.4A (Tc) | 10V | 3Ohm @ 1.4A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±20V | 360 pF @ 25 V | - | 2.5W (Ta), 42W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRFU9010PBFMOSFET P-CH 50V 5.3A TO251AA |
2,900 | 1.60 |
RFQ |
Datasheet |
Tube | - | Active | P-Channel | MOSFET (Metal Oxide) | 50 V | 5.3A (Tc) | 10V | 500mOhm @ 2.8A, 10V | 4V @ 250µA | 9.1 nC @ 10 V | ±20V | 240 pF @ 25 V | - | 25W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IRF9640PBF-BE3MOSFET P-CH 200V 11A TO220AB |
1,990 | 2.14 |
RFQ |
Tube | - | Active | P-Channel | MOSFET (Metal Oxide) | 200 V | 11A (Tc) | 10V | 500mOhm @ 6.6A, 10V | 4V @ 250µA | 44 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
|
IRFI9520GPBFMOSFET P-CH 100V 5.2A TO220-3 |
1,172 | 2.59 |
RFQ |
Datasheet |
Tube | - | Active | P-Channel | MOSFET (Metal Oxide) | 100 V | 5.2A (Tc) | 10V | 600mOhm @ 3.1A, 10V | 4V @ 250µA | 18 nC @ 10 V | ±20V | 390 pF @ 25 V | - | 37W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRFI740GLCPBFMOSFET N-CH 400V 5.7A TO220-3 |
1,058 | 4.08 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 400 V | 5.7A (Tc) | 10V | 550mOhm @ 3.4A, 10V | 4V @ 250µA | 39 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
SIHA21N80AE-GE3MOSFET N-CH 800V 7.5A TO220 |
1,004 | 2.93 |
RFQ |
Tube | E | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 7.5A (Tc) | 10V | 235mOhm @ 11A, 10V | 4V @ 250µA | 72 nC @ 10 V | ±30V | 1388 pF @ 100 V | - | 33W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
|
IRFSL9N60APBFMOSFET N-CH 600V 9.2A I2PAK |
457 | 2.99 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 9.2A (Tc) | 10V | 750mOhm @ 5.5A, 10V | 4V @ 250µA | 49 nC @ 10 V | ±30V | 1400 pF @ 25 V | - | 170W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IRFPC40PBFMOSFET N-CH 600V 6.8A TO247-3 |
500 | 3.85 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 6.8A (Tc) | 10V | 1.2Ohm @ 4.1A, 10V | 4V @ 250µA | 60 nC @ 10 V | ±20V | 1300 pF @ 25 V | - | 150W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHP21N80AE-GE3MOSFET N-CH 800V 17.4A TO220AB |
987 | 4.55 |
RFQ |
Datasheet |
Tube | E | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 17.4A (Tc) | 10V | 235mOhm @ 11A, 10V | 4V @ 250µA | 72 nC @ 10 V | ±30V | 1388 pF @ 100 V | - | 32W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IRFBC40ASPBFMOSFET N-CH 600V 6.2A D2PAK |
484 | 4.66 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 6.2A (Tc) | 10V | 1.2Ohm @ 3.7A, 10V | 4V @ 250µA | 42 nC @ 10 V | ±30V | 1036 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SIHG21N60EF-GE3MOSFET N-CH 600V 21A TO247AC |
118 | 4.69 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 21A (Tc) | 10V | 176mOhm @ 11A, 10V | 4V @ 250µA | 84 nC @ 10 V | ±30V | 2030 pF @ 100 V | - | 227W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHG21N80AE-GE3MOSFET N-CH 800V 17.4A TO247AC |
2,025 | 5.01 |
RFQ |
Datasheet |
Tube | E | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 17.4A (Tc) | 10V | 235mOhm @ 11A, 10V | 4V @ 250µA | 72 nC @ 10 V | ±30V | 1388 pF @ 100 V | - | 32W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHG125N60EF-GE3MOSFET N-CH 600V 25A TO247AC |
545 | 5.14 |
RFQ |
Tube | EF | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Tc) | 10V | 125mOhm @ 12A, 10V | 5V @ 250µA | 47 nC @ 10 V | ±30V | 1533 pF @ 100 V | - | 179W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
|
SIHF12N50C-E3MOSFET N-CH 500V 12A TO220 |
997 | 5.51 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 12A (Tc) | 10V | 555mOhm @ 4A, 10V | 5V @ 250µA | 48 nC @ 10 V | ±30V | 1375 pF @ 25 V | - | 36W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SIHP16N50C-E3MOSFET N-CH 500V 16A TO220AB |
963 | 6.12 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 16A (Tc) | 10V | 380mOhm @ 8A, 10V | 5V @ 250µA | 68 nC @ 10 V | ±30V | 1900 pF @ 25 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
