| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SI1424EDH-T1-BE3MOSFET N-CH 20V 4A/4A SC70-6 |
2,709 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 4A (Ta), 4A (Tc) | - | 33mOhm @ 5A, 4.5V | 1V @ 250µA | 18 nC @ 8 V | ±8V | - | - | 1.56W (Ta), 2.8W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
.jpg)
|
SI2305CDS-T1-BE3P-CHANNEL 8-V (D-S) MOSFET |
2,765 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 8 V | 4.4A (Ta), 5.8A (Tc) | 1.8V, 4.5V | 35mOhm @ 4.4A, 4.5V | 1V @ 250µA | 30 nC @ 8 V | ±8V | 960 pF @ 4 V | - | 960mW (Ta), 1.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SI1317DL-T1-BE3MOSFET P-CH 20V 1.4A/1.4A SC70-3 |
3,037 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 1.4A (Ta), 1.4A (Tc) | - | 150mOhm @ 1.4A, 4.5V | 800mV @ 250µA | 6.5 nC @ 4.5 V | ±8V | 272 pF @ 10 V | - | 400mW (Ta), 500mW (Tc) | -50°C ~ 150°C (TJ) | Surface Mount |
|
|
SI2301BDS-T1-BE3P-CHANNEL 2.5-V (G-S) MOSFET |
3,955 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.2A (Ta) | 2.5V, 4.5V | 100mOhm @ 2.8A, 4.5V | 950mV @ 250µA | 10 nC @ 4.5 V | ±8V | 375 pF @ 6 V | - | 700mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SI3440ADV-T1-BE3N-CHANNEL 150-V (D-S) MOSFET |
3,812 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 1.6A (Ta), 2.2A (Tc) | 7.5V, 10V | 380mOhm @ 1.5A, 10V | 4V @ 250µA | 4 nC @ 10 V | ±20V | 80 pF @ 75 V | - | 2W (Ta), 3.6W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI2300DS-T1-BE3N-CHANNEL 30-V (D-S) MOSFET |
2,052 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 3.1A (Ta), 3.6A (Tc) | 2.5V, 4.5V | 68mOhm @ 2.9A, 4.5V | 1.5V @ 250µA | 10 nC @ 10 V | ±12V | 320 pF @ 15 V | - | 1.1W (Ta), 1.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI3483CDV-T1-BE3P-CHANNEL 30-V (D-S) MOSFET |
2,826 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 6.1A (Ta), 8A (Tc) | 4.5V, 10V | 34mOhm @ 6.1A, 10V | 3V @ 250µA | 33 nC @ 10 V | ±20V | 1000 pF @ 15 V | - | 2W (Ta), 4.2W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SI2387DS-T1-GE3P-CHANNEL -80V SOT-23, 164 M @ 1 |
2,967 | 0.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® Gen IV | Active | P-Channel | MOSFET (Metal Oxide) | 80 V | 2.1A (Ta), 3A (Tc) | 4.5V, 10V | 164mOhm @ 2.1A, 10V | 2.5V @ 250µA | 10.2 nC @ 10 V | ±20V | 395 pF @ 40 V | - | 1.3W (Ta), 2.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI1401EDH-T1-BE3MOSFET P-CH 12V 4A/4A SC70-6 |
2,468 | 0.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 12 V | 4A (Ta), 4A (Tc) | - | 34mOhm @ 5.5A, 4.5V | 1V @ 250µA | 36 nC @ 8 V | ±10V | - | - | 1.6W (Ta), 2.8W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI2367DS-T1-BE3P-CHANNEL 20-V (D-S) MOSFET |
3,144 | 0.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.8A (Ta), 3.8A (Tc) | 1.8V, 4.5V | 66mOhm @ 2.5A, 4.5V | 1V @ 250µA | 23 nC @ 8 V | ±8V | 561 pF @ 10 V | - | 960mW (Ta), 1.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI2369DS-T1-BE3P-CHANNEL 30-V (D-S) MOSFET |
2,296 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 5.4A (Ta), 7.6A (Tc) | 4.5V, 10V | 29mOhm @ 5.4A, 10V | 2.5V @ 250µA | 36 nC @ 10 V | ±20V | 1295 pF @ 15 V | - | 1.25W (Ta), 2.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SI2333DDS-T1-BE3P-CHANNEL 12-V (D-S) MOSFET |
2,257 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 12 V | 5A (Ta), 6A (Tc) | 1.5V, 4.5V | 28mOhm @ 5A, 4.5V | 1V @ 250µA | 35 nC @ 8 V | ±8V | 1275 pF @ 6 V | - | 1.2W (Ta), 1.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SQA470CEJW-T1_GE3AUTOMOTIVE N-CHANNEL 30 V (D-S) |
3,910 | 0.44 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 2.25A (Tc) | 2.5V, 4.5V | 65mOhm @ 3A, 4.5V | 1.3V @ 250µA | 6 nC @ 4.5 V | ±12V | 440 pF @ 20 V | - | 13.6W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
SI2377EDS-T1-BE3P-CHANNEL 20-V (D-S) MOSFET |
2,921 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 3.7A (Ta), 4.4A (Tc) | 1.5V, 4.5V | 61mOhm @ 3.2A, 4.5V | 1V @ 250µA | 21 nC @ 8 V | ±8V | - | - | 1.25W (Ta), 1.8W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SIA4265EDJ-T1-GE3P-CHANNEL 20-V (D-S) MOSFET POWE |
2,079 | 0.44 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 7.8A (Ta), 9A (Tc) | 1.8V, 4.5V | 32mOhm @ 4A, 4.5V | 1V @ 250µA | 36 nC @ 8 V | ±8V | 1180 pF @ 0 V | - | 2.9W (Ta), 15.6W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
SIA4371EDJ-T1-GE3P-CHANNEL 30-V (D-S) MOSFET POWE |
3,573 | 0.56 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 6.4A (Ta), 9A (Tc) | 2.5V, 10V | 45mOhm @ 3.7A, 10V | 1.5V @ 250µA | 35 nC @ 10 V | ±12V | - | - | 2.9W (Ta), 15.6W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
SI1443EDH-T1-BE3MOSFET P-CH 30V 4A/4A SC70-6 |
2,960 | 0.56 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 4A (Ta), 4A (Tc) | - | 54mOhm @ 4.3A, 10V | 1.5V @ 250µA | 28 nC @ 10 V | ±12V | - | - | 1.6W (Ta), 2.8W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SQA410CEJW-T1_GE3AUTOMOTIVE N-CHANNEL 20 V (D-S) |
3,705 | 0.45 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 7.8A (Tc) | 1.8V, 4.5V | 28mOhm @ 5A, 4.5V | 1.1V @ 250µA | 8 nC @ 4.5 V | ±8V | 525 pF @ 10 V | - | 13.6W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
SQA413CEJW-T1_GE3AUTOMOTIVE P-CHANNEL 20 V (D-S) |
2,362 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 7.5A (Tc) | 2.5V, 4.5V | 38mOhm @ 4.5A, 4.5V | 1.3V @ 250µA | 16 nC @ 4.5 V | ±12V | 1350 pF @ 10 V | - | 13.6W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount, Wettable Flank |
|
|
SI1302DL-T1-BE3MOSFET N-CH 30V 600MA SC70-3 |
3,083 | 0.46 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 600mA (Ta) | - | 480mOhm @ 600mA, 10V | 3V @ 250µA | 1.4 nC @ 10 V | ±20V | - | - | 280mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
