| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Voltage-Isolation | CurrentTransferRatio(Min) | CurrentTransferRatio(Max) | TurnOn/TurnOffTime(Typ) | Rise/FallTime(Typ) | InputType | OutputType | Voltage-Output(Max) | Current-Output/Channel | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | VceSaturation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ILD610-1OPTOISO 5.3KV 2CH TRANS 8DIP |
3,460 | 0.85 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 5300Vrms | 40% @ 10mA | 80% @ 10mA | 3µs, 2.9µs | 2µs, 2µs | DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 400mV | -55°C ~ 100°C | Through Hole |
|
VOMA617A-8X001TOPTOCOUPLER, PHOTOTRANSISTOR OUT |
2,786 | 0.88 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | Active | 1 | 3750Vrms | 130% @ 5mA | 260% @ 5mA | 4.9µs, 3.3µs | 2.3µs, 3.2µs | DC | Transistor | 80V | 50mA | 1.33V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
|
SFH6326-X001OPTOISOLATR 5.3KV 2CH TRANS 8DIP |
2,655 | 0.92 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 5300Vrms | 19% @ 16mA | - | 200ns, 500ns | - | DC | Transistor | 25V | 8mA | 1.33V | 25 mA | - | -55°C ~ 100°C | Through Hole |
|
SFH6326-X017OPTOISOLATR 5.3KV 2CH TRANS 8SMD |
3,925 | 0.94 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 5300Vrms | 19% @ 16mA | - | 200ns, 500ns | - | DC | Transistor | 25V | 8mA | 1.33V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
TCET4600OPTOISO 5.3KV 4CH TRANS 16-DIP |
3,147 | 0.96 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 20% @ 5mA | 300% @ 5mA | 6µs, 5µs | 3µs, 4.7µs | AC, DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 300mV | -55°C ~ 100°C | Through Hole |
|
TCET4600GOPTOISO 5.3KV 4CH TRANS 16DIP |
3,490 | 0.96 |
RFQ |
Tube | - | Active | 4 | 5300Vrms | 20% @ 5mA | 300% @ 5mA | 6µs, 5µs | 3µs, 4.7µs | AC, DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 300mV | -55°C ~ 100°C | Through Hole | |
|
|
VOMA617A-4X001TOPTOCOUPLER, PHOTOTRANSISTOR OUT |
2,130 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | Active | 1 | 3750Vrms | 160% @ 5mA | 320% @ 5mA | 4.9µs, 3.3µs | 2.3µs, 3.2µs | DC | Transistor | 80V | 50mA | 1.33V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
|
SFH6326-X009TOPTOISOLATR 5.3KV 2CH TRANS 8SMD |
2,335 | 0.99 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 2 | 5300Vrms | 19% @ 16mA | - | 200ns, 500ns | - | DC | Transistor | 25V | 8mA | 1.33V | 25 mA | - | -55°C ~ 100°C | Surface Mount |
|
|
ILD620-X007TOPTOISO 5.3KV 2CH TRANS 8SMD |
2,687 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Active | 2 | 5300Vrms | 50% @ 5mA | 600% @ 5mA | 3µs, 2.3µs | 20µs, 2µs | AC, DC | Transistor | 70V | 50mA | 1.15V | 60 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
|
ILD55-X009OPTOISO 5.3KV 2CH DARL 8SMD |
2,372 | 1.04 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 5300Vrms | 100% @ 10mA | - | - | 10µs, 35µs | DC | Darlington | 55V | 125mA | 1.25V | 60 mA | 1V | -55°C ~ 100°C | Surface Mount |
|
|
ILQ1-X006OPTOISO 5.3KV 4CH TRANS 16DIP |
3,870 | 1.11 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 20% @ 10mA | 300% @ 10mA | 700ns, 1.4µs | 1.9µs, 1.4µs | DC | Transistor | 50V | 50mA | 1.25V | 60 mA | 400mV | -40°C ~ 100°C | Through Hole |
|
ILQ1-X007OPTOISO 5.3KV 4CH TRANS 16SMD |
3,988 | 1.11 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 20% @ 10mA | 300% @ 10mA | 700ns, 1.4µs | 1.9µs, 1.4µs | DC | Transistor | 50V | 50mA | 1.25V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
|
ILQ1-X009OPTOISO 5.3KV 4CH TRANS 16SMD |
2,331 | 1.11 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 20% @ 10mA | 300% @ 10mA | 700ns, 1.4µs | 1.9µs, 1.4µs | DC | Transistor | 50V | 50mA | 1.25V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
SFH6916-X001OPTOISO 3.75KV 4CH TRANS 16SOP |
3,231 | 1.14 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 3750Vrms | 50% @ 5mA | 300% @ 5mA | 15µs, 500ns | 1µs, 30µs | DC | Transistor | 70V | 50mA | 1.15V | 50 mA | 400mV | -55°C ~ 100°C | Surface Mount |
|
VOMA618A-4X001TOPTOCOUPLER-PHOTO-TRANSISTOR DET |
3,796 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR) | VOMA618A | Active | 1 | 3750Vrms | 160% @ 1mA | 320% @ 1mA | 6.8µs, 2.3µs | 1.8µs, 1.7µs | DC | Transistor | 80V | 50mA | 1.28V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
|
VOMA618A-X001TOPTOCOUPLER-PHOTO-TRANSISTOR DET |
3,288 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR) | VOMA618A | Active | 1 | 3750Vrms | 50% @ 1mA | 600% @ 1mA | 6.8µs, 2.3µs | 1.8µs, 1.7µs | DC | Transistor | 80V | 50mA | 1.28V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
|
VOMA618A-2X001TOPTOCOUPLER-PHOTO-TRANSISTOR DET |
3,051 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR) | VOMA618A | Active | 1 | 3750Vrms | 63% @ 1mA | 125% @ 1mA | 6.8µs, 2.3µs | 1.8µs, 1.7µs | DC | Transistor | 80V | 50mA | 1.28V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
|
VOMA618A-8X001TOPTOCOUPLER-PHOTO-TRANSISTOR DET |
3,391 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR) | VOMA618A | Active | 1 | 3750Vrms | 130% @ 1mA | 260% @ 1mA | 6.8µs, 2.3µs | 1.8µs, 1.7µs | DC | Transistor | 80V | 50mA | 1.28V | 20 mA | 400mV | -40°C ~ 110°C | Surface Mount |
|
ILQ2-X007OPTOISO 5.3KV 4CH TRANS 16SMD |
2,742 | 1.16 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 100% @ 10mA | 500% @ 10mA | 1.2µs, 2.3µs | 2.6µs, 2.2µs | DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 400mV | -40°C ~ 100°C | Surface Mount |
|
|
ILQ2-X016OPTOISO 5.3KV 4CH TRANS 16DIP |
2,411 | 1.19 |
RFQ |
Datasheet |
Tube | - | Active | 4 | 5300Vrms | 100% @ 10mA | 500% @ 10mA | 1.2µs, 2.3µs | 2.6µs, 2.2µs | DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 400mV | -40°C ~ 100°C | Through Hole |
