| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | NumberofChannels | Inputs-Side1/Side2 | Voltage-Isolation | CommonModeTransientImmunity(Min) | InputType | OutputType | Current-Output/Channel | DataRate | PropagationDelaytpLH/tpHL(Max) | Rise/FallTime(Typ) | Voltage-Forward(Vf)(Typ) | Current-DCForward(If)(Max) | Voltage-Supply | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HCPL0639OPTOISO 3.75KV 2CH OPEN COLL 8SO |
2,706 | 6.45 |
RFQ |
Datasheet |
Tube | - | Active | 2 | 2/0 | 3750Vrms | 25kV/µs | DC | Open Collector, Schottky Clamped | 15 mA | 10Mbps | 75ns, 75ns | 17ns, 5ns | 1.75V (Max) | - | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
|
HCPL0639R2OPTOISO 3.75KV 2CH OPEN COLL 8SO |
3,762 | 2.77 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 | 2/0 | 3750Vrms | 25kV/µs | DC | Open Collector, Schottky Clamped | 15 mA | 10Mbps | 75ns, 75ns | 17ns, 5ns | 1.75V (Max) | - | 4.5V ~ 5.5V | -40°C ~ 85°C | Surface Mount |
|
H11N1TVMOPTOISO 4.17KV OPN COLL 6DIP |
3,888 | 6.45 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 4170Vrms | - | DC | Open Collector | 50 mA | 5MHz | 330ns, 330ns | 7.5ns, 12ns | 1.4V | 30mA | 4V ~ 15V | -40°C ~ 85°C | Through Hole |
|
H11N1VMOPTOISO 4.17KV OPN COLL 6DIP |
3,583 | 7.37 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 4170Vrms | - | DC | Open Collector | 50 mA | 5MHz | 330ns, 330ns | 7.5ns, 12ns | 1.4V | 30mA | 4V ~ 15V | -40°C ~ 85°C | Through Hole |
|
H11N1SR2VMOPTOISO 4.17KV OPN COLL 6SMD |
3,493 | 3.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 | 1/0 | 4170Vrms | - | DC | Open Collector | 50 mA | 5MHz | 330ns, 330ns | 7.5ns, 12ns | 1.4V | 30mA | 4V ~ 15V | -40°C ~ 85°C | Surface Mount |
|
|
H11N1SVMOPTOISO 4.17KV OPN COLL 6SMD |
2,767 | 7.64 |
RFQ |
Datasheet |
Tube | - | Active | 1 | 1/0 | 4170Vrms | - | DC | Open Collector | 50 mA | 5MHz | 330ns, 330ns | 7.5ns, 12ns | 1.4V | 30mA | 4V ~ 15V | -40°C ~ 85°C | Surface Mount |
|
FOD2712ATRANSISTOR OUTPUT OPTOCOUPLER, 2 |
3,679 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
HCPL2531SDMHCPL2531 - LOGIC IC OUTPUT OPTOC |
2,250 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
H11N2SR2MH11N2SR2M - LOGIC OUTPUT OPTO-IS |
2,613 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
HCPL2630LOGIC IC OUTPUT OPTOCOUPLER, 2-E |
3,735 | 1.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
FOD0710R2FOD0710 - HIGH CMR, 12.5MBIT/SEC |
3,730 | 0.00 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
74OL6001OPTOISO 5.3KV PUSH PULL 6DIP |
3,838 | 0.00 |
RFQ |
Datasheet |
Tube | OPTOLOGIC™ | Obsolete | 1 | 1/0 | 5300Vrms | 5kV/µs | Logic | Push-Pull, Totem Pole | 40 mA | 15MBd | 100ns, 100ns | 45ns, 5ns | - | - | 4.5V ~ 5.5V | 0°C ~ 70°C | Through Hole |
|
|
74OL6000OPTOISO 5.3KV PUSH PULL 6DIP |
3,088 | 0.00 |
RFQ |
Datasheet |
Tube | OPTOLOGIC™ | Obsolete | 1 | 1/0 | 5300Vrms | 5kV/µs | Logic | Push-Pull, Totem Pole | 40 mA | 15MBd | 100ns, 100ns | 45ns, 5ns | - | - | 4.5V ~ 5.5V | 0°C ~ 70°C | Through Hole |
|
|
74OL6010OPTOISO 5.3KV OPN COLLECTOR 6DIP |
3,924 | 0.00 |
RFQ |
Datasheet |
Tube | OPTOLOGIC™ | Obsolete | 1 | 1/0 | 5300Vrms | 5kV/µs | Logic | Open Collector, Schottky Clamped | 40 mA | 15MBd | 180ns, 120ns | 50ns, 5ns | - | - | 4.5V ~ 15V | 0°C ~ 70°C | Through Hole |
|
|
74OL6011OPTOISO 5.3KV OPN COLLECTOR 6DIP |
2,356 | 0.00 |
RFQ |
Datasheet |
Tube | OPTOLOGIC™ | Obsolete | 1 | 1/0 | 5300Vrms | 5kV/µs | Logic | Open Collector, Schottky Clamped | 40 mA | 15MBd | 180ns, 120ns | 50ns, 5ns | - | - | 4.5V ~ 15V | 0°C ~ 70°C | Through Hole |
|
|
H11L1ISOLAT 7.5KVPK 1CH UNIDIR 6-DIP |
2,010 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 1/0 | 5300Vrms | - | DC | Open Collector | 50 mA | 1MHz | - | - | - | 1.6mA | - | - | Through Hole |
|
|
H11L2ISOLAT 7.5KVPK 1CH UNIDIR 6-DIP |
2,981 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 1/0 | 5300Vrms | - | DC | Open Collector | 50 mA | 1MHz | - | - | - | 10mA | - | - | Through Hole |
|
|
H11L3SCMITT TRIGGER OPTOISOLATOR |
2,876 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 1/0 | 5300Vrms | - | DC | Open Collector | 50 mA | 1MHz | - | - | - | 5mA | - | - | Through Hole |
|
|
74OL6000SOPTOISO 5.3KV PUSH PULL 6SOIC |
3,438 | 0.00 |
RFQ |
Datasheet |
Tube | OPTOLOGIC™ | Obsolete | 1 | 1/0 | 5300Vrms | 5kV/µs | Logic | Push-Pull, Totem Pole | 40 mA | 15MBd | 100ns, 100ns | 45ns, 5ns | - | - | 4.5V ~ 5.5V | 0°C ~ 70°C | Surface Mount |
|
6N137OPTOISO 2.5KV 1CH OPEN COLL 8DIP |
2,197 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 | 1/0 | 2500Vrms | 10kV/µs (Typ) | DC | Open Collector | 50 mA | 10Mbps | 75ns, 75ns | 50ns, 12ns | 1.4V | 50mA | 4.5V ~ 5.5V | -40°C ~ 85°C | Through Hole |
