| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | CoreType | Material | Diameter | InductanceFactor(Al) | Tolerance | Gap | EffectivePermeability(µe) | InitialPermeability(µi) | CoreFactor(ΣI/A)mm-1 | EffectiveLength(le)mm | EffectiveArea(Ae)mm² | MinimumCoreCrossSection(Amin)mm² | EffectiveMagneticVolume(Ve)mm³ | Finish | Height | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
597700022177 TOROID PLASTIC COATED |
787 | 0.34 |
RFQ |
Datasheet |
Bag | - | Active | Toroid | - | 77 | 0.402 (10.20mm) | 945 nH | -30%, +25% | Ungapped | - | 2000 | 2.86 | 20.7 | 7.2 | - | 150 | Plastic | 0.150 (3.81mm) |
|
899825252198 EFD CORE SET |
576 | 1.22 |
RFQ |
Datasheet |
Bulk | - | Active | EFD | - | - | - | - | ±25% | Ungapped | - | 2400 | 104 | 58.8 | 58 | 55 | 3320 | Uncoated | 0.492 (12.50mm) |
|
597500512175 TOROID PLASTIC COATED |
128 | 1.23 |
RFQ |
Datasheet |
Bulk | - | Active | Toroid | - | 75 | 0.665 (16.90mm) | 2.35 µH | -25%, +20% | Ungapped | - | 5000 | 2.6 | 38.5 | 14.5 | - | 560 | Plastic | 0.207 (5.25mm) |
|
597700050177 TOROID |
509 | 1.49 |
RFQ |
Datasheet |
Bulk | - | Active | Toroid | - | 77 | 0.825 (20.96mm) | - | ±25% | Ungapped | - | 2000 | - | 52 | 46 | - | 2360 | Uncoated | 0.468 (11.89mm) |
|
629523012195 RM CORE SET |
334 | 1.51 |
RFQ |
Datasheet |
Bulk | - | Active | RM | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 67 | 40.3 | 60 | 55.4 | 2419 | Uncoated | 0.323 (8.20mm) |
|
927700200277 U CORE |
576 | 1.57 |
RFQ |
Datasheet |
Box | - | Active | U | - | 77 | - | - | - | Ungapped | - | 2000 | 139 | 95 | 68 | - | 6500 | Uncoated | - |
|
427724240977 SLEEVE |
2,494 | 1.53 |
RFQ |
Datasheet |
Bulk | - | Active | ROD | - | 77 | 0.512 (13.00mm) | - | - | Ungapped | - | 2000 | - | - | - | - | - | Uncoated | - |
|
|
286700680267 MULTI-APERTURE CORE |
3,495 | 1.78 |
RFQ |
Datasheet |
Tray | - | Active | Multi-Hole (2) | - | 67 | - | 180 nH | - | Ungapped | - | 40 | - | - | - | - | - | Uncoated | 1.062 (26.97mm) |
|
569518122195 POT CORE SET |
2,634 | 1.79 |
RFQ |
Datasheet |
Tray | - | Active | P (Pot Core) | - | 95 | 0.030 (0.76mm) | - | ±25% | Ungapped | - | 3000 | 60 | 25.9 | 43 | 36 | 1120 | Uncoated | 0.211 (5.36mm) |
|
569836232198 POT CORE SET |
230 | 4.36 |
RFQ |
Datasheet |
Bulk | - | Active | PS | - | - | - | - | ±25% | Ungapped | - | 2400 | 29 | 55.3 | 164 | - | 9780 | Uncoated | 0.429 (10.90mm) |
|
959544450295 ETD CORE SET |
233 | 4.83 |
RFQ |
Datasheet |
Bulk | - | Active | ETD | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 60 | 103.5 | 173 | 117.7 | 17940 | Uncoated | 0.878 (22.30mm) |
|
|
569536232195 POT CORE SET |
248 | 4.99 |
RFQ |
Datasheet |
Bulk | - | Active | PS | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 29 | 50 | 164 | - | 9780 | Uncoated | 0.429 (10.90mm) |
|
|
427714200977 SLEEVE |
3,663 | 0.46 |
RFQ |
Datasheet |
Bulk | - | Active | ROD | - | 77 | - | - | - | Ungapped | - | 2000 | - | - | - | - | - | Uncoated | - |
|
597801860178 TOROID |
143 | 8.73 |
RFQ |
Datasheet |
Bulk | - | Active | Toroid | - | 78 | - | - | ±25% | Ungapped | - | 2300 | - | 98 | 178 | - | 17500 | Uncoated | - |
|
|
594301590143 TOROID |
224 | 36.32 |
RFQ |
Datasheet |
Bulk | - | Active | Toroid | - | 43 | - | - | ±25% | Ungapped | - | 800 | - | 230 | 277 | - | 63700 | Uncoated | 0.500 (12.70mm) |
|
947810200278 E CORE SET |
2,180 | 0.32 |
RFQ |
Datasheet |
Bulk | - | Active | E | - | 78 | - | - | ±25% | Ungapped | - | 2300 | 234 | 29.6 | 12.7 | 12.2 | 376 | Uncoated | 0.250 (6.35mm) |
|
899510102198 EFD CORE SET |
3,609 | 0.50 |
RFQ |
Datasheet |
Bulk | - | Active | EFD | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 327 | 23.6 | 7.2 | 6.6 | 171 | Uncoated | 0.205 (5.20mm) |
|
899515152195 EFD CORE SET |
2,962 | 0.81 |
RFQ |
Datasheet |
Bulk | - | Active | EFD | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 223 | 34.4 | 15.4 | 12.7 | 531 | Uncoated | 0.295 (7.50mm) |
|
|
567814092178 POT CORE SET |
4,000 | 1.02 |
RFQ |
Datasheet |
Bulk | - | Active | PS | - | 78 | 0.551 (14.00mm) | - | ±25% | Ungapped | - | 2300 | 79 | 19.8 | 25.1 | - | 495 | Uncoated | 0.165 (4.20mm) |
|
|
569509062195 POT CORE SET |
2,366 | 1.26 |
RFQ |
Datasheet |
Bulk | - | Active | PS | - | 95 | - | - | ±25% | Ungapped | - | 3000 | 120 | 13.5 | 11.2 | - | 152 | Uncoated | - |
