| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SS34B-HFDIODE SCHOTTKY 3A 40V SMB |
16,367 | 0.38 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 450pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 3A | -55°C ~ 150°C | 550 mV @ 3 A | ||
|
ACGRAT103L-HFDIODE GEN PURP 600V 1A 2010 |
1,654 | 0.36 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8.2pF @ 4V, 1MHz | - | 5 µA @ 600 V | 600 V | 1A | -65°C ~ 175°C | 930 mV @ 1 A |
|
|
ACGRAT105L-HFDIODE GEN PURP 1KV 1A 2010 |
19,993 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8.2pF @ 4V, 1MHz | - | 5 µA @ 1000 V | 1000 V | 1A | -65°C ~ 175°C | 930 mV @ 1 A |
|
CDBURT0530LL-HFDIODE SCHOTTKY 20V 500MA 0603 |
6,523 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 30pF @ 1V, 1MHz | - | 100 µA @ 20 V | 20 V | 500mA | -55°C ~ 125°C | 460 mV @ 500 mA | |
|
RS2D-HFRECTIFIER FAST RECOVERY 200V 2A |
4,995 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 22pF @ 4V, 1MHz | 150 ns | 5 µA @ 200 V | 200 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
RS2G-HFRECTIFIER FAST RECOVERY 400V 2A |
4,985 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 22pF @ 4V, 1MHz | 150 ns | 5 µA @ 400 V | 400 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
|
RS2M-HFRECTIFIER FAST RECOVERY 1000V 2A |
4,390 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 22pF @ 4V, 1MHz | 500 ns | 5 µA @ 1000 V | 1000 V | 2A | -55°C ~ 150°C | 1.3 V @ 2 A | |
|
RS1J-HFRECTIFIER FAST RECOVERY 600V 1A |
4,369 | 0.37 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.3 V @ 1 A | ||
|
CDBH0230-GDIODE SCHOTTKY 30V 200MA SOD523 |
3,992 | 0.37 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 10pF @ 1V, 1MHz | 5 ns | 2 µA @ 25 V | 30 V | 100mA | 125°C | 1 V @ 100 mA | ||
|
|
RS1G-HFRECTIFIER FAST RECOVERY 400V 1A |
3,950 | 0.37 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 150 ns | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.3 V @ 1 A | ||
|
CSFA103-GDIODE GEN PURP 200V 1A DO214AC |
6,892 | 0.43 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 35 ns | 5 µA @ 200 V | 200 V | 1A | -55°C ~ 150°C | 950 mV @ 1 A | |
|
CGRTS4004-HFDIODE GEN PURP 400V 1A TS/SOD-12 |
3,147 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 6pF @ 4V, 1MHz | - | 10 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1 V @ 1 A | |
|
|
S2M-HFRECTIFIER GEN PURP 1000V 2A SMA |
3,082 | 0.37 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 25pF @ 4V, 1MHz | - | 5 µA @ 1000 V | 1000 V | 2A | -55°C ~ 150°C | 1.1 V @ 2 A | ||
|
CGRM4004-HFDIODE GEN PURP 400V 1A SOD123 |
2,440 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | - | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.1 V @ 1 A | |
|
CDBQR00340-HFDIODE SCHOTTKY 40V 30MA 0402 |
10,000 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Obsolete | Surface Mount | 1.5pF @ 1V, 1MHz | - | 1 µA @ 40 V | 40 V | 30mA | 125°C (Max) | 370 mV @ 1 mA | |
|
ACGRCT302-HFDIODE GEN PURP 400V 3A 3220 |
2,945 | 0.71 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Last Time Buy | Surface Mount | 23pF @ 4V, 1MHz | - | 5 µA @ 400 V | 400 V | 3A | -65°C ~ 175°C | 1 V @ 3 A |
|
|
ACDBCT360-HFDIODE SCHOTTKY 60V 3A 3220 |
2,492 | 0.75 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Last Time Buy | Surface Mount | 180pF @ 4V, 1MHz | - | 500 µA @ 60 V | 60 V | 3A | -55°C ~ 150°C | 700 mV @ 3 A |
|
|
ACDBCT3100-HFDIODE SCHOTTKY 100V 3A 3220 |
2,486 | 0.80 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Last Time Buy | Surface Mount | 180pF @ 4V, 1MHz | - | 500 µA @ 100 V | 100 V | 3A | -55°C ~ 150°C | 850 mV @ 3 A |
|
1N4148-GDIODE GEN PURP 75V 150MA DO35 |
54,470 | 0.13 |
RFQ |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Obsolete | Through Hole | - | - | 5 µA @ 75 V | 75 V | 150mA | -65°C ~ 200°C | 1 V @ 10 mA | |
|
CDSL4148-GDIODE GEN PURP 75V 150MA SOD80 |
223,401 | 0.15 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Obsolete | Surface Mount | 4pF @ 0V, 1MHz | 4 ns | 2.5 µA @ 75 V | 75 V | 150mA | 175°C (Max) | 1 V @ 100 mA |
