| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
M0955LC200FAST DIODE |
3,671 | 166.20 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 3.4 µs | 50 mA @ 2000 V | 2000 V | 955A | -40°C ~ 125°C | 2.07 V @ 1900 A | ||
|
|
M0955LC250FAST DIODE |
2,195 | 169.63 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 3.4 µs | 50 mA @ 2500 V | 2500 V | 955A | -40°C ~ 125°C | 2.07 V @ 1900 A | ||
|
|
W4767MC220RECTIFIER DIODE |
3,128 | 171.60 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 26 µs | 50 mA @ 2200 V | 2200 V | 4755A | -40°C ~ 175°C | 1.05 V @ 3000 A | ||
|
|
W3477MC360RECTIFIER DIODE |
3,554 | 174.00 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 38 µs | 100 mA @ 3600 V | 3600 V | 3470A | -40°C ~ 160°C | 1.34 V @ 3000 A | ||
|
|
W1748LC180RECTIFIER DIODE |
2,925 | 115.78 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | 30 mA @ 1800 V | 1800 V | 1748A | -40°C ~ 175°C | 1.93 V @ 3770 A | ||
|
|
M0759YC160FAST DIODE |
3,501 | 116.24 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 2 µs | 50 mA @ 1600 V | 1600 V | 759A | -40°C ~ 125°C | 1.7 V @ 1500 A | ||
|
|
W2340JK120RECTIFIER DIODE |
2,698 | 116.48 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | - | 1200 V | 2340A | - | - | ||
|
|
W1748LC220RECTIFIER DIODE |
3,220 | 118.04 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | 30 mA @ 2200 V | 2200 V | 1748A | -40°C ~ 175°C | 1.93 V @ 3770 A | ||
|
|
W2340JK150RECTIFIER DIODE |
2,864 | 118.96 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | - | 1500 V | 2340A | - | - | ||
|
|
MDO1201-22N1DIODE GEN PURP 2.2KV 1950A |
2,776 | 363.45 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | 70 µA @ 2200 V | 2200 V | 1950A | - | 1.15 V @ 3400 A | |
|
W6672TJ320DIODE GEN PURP 1.75KV 6672A - |
2,814 | 373.05 |
RFQ |
Datasheet |
Box | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 52 µs | 100 mA @ 1750 V | 1750 V | 6672A | -40°C ~ 160°C | 1.37 V @ 5000 A | |
|
|
W5984TJ360RECTIFIER DIODE |
3,190 | 379.95 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 47 µs | 100 mA @ 3600 V | 3600 V | 5984A | -40°C ~ 160°C | 1.25 V @ 5000 A | ||
|
|
W6672TJ350DIODE GEN PURP 1.9KV 6672A - |
3,806 | 380.55 |
RFQ |
Datasheet |
Box | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 52 µs | 100 mA @ 1900 V | 1900 V | 6672A | -40°C ~ 160°C | 1.37 V @ 5000 A | |
|
|
W5984TJ400RECTIFIER DIODE |
3,633 | 387.90 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 47 µs | 100 mA @ 4000 V | 4000 V | 5984A | -40°C ~ 160°C | 1.25 V @ 5000 A | ||
|
|
W5984TE360RECTIFIER DIODE |
3,504 | 389.25 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 47 µs | 100 mA @ 3600 V | 3600 V | 5984A | -40°C ~ 160°C | 1.25 V @ 5000 A | ||
|
|
W5984TE400RECTIFIER DIODE |
2,272 | 397.20 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 47 µs | 100 mA @ 4000 V | 4000 V | 5984A | -40°C ~ 160°C | 1.25 V @ 5000 A | ||
|
|
W3090HA600RECTIFIER DIODE |
2,121 | 399.30 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 41 µs | 100 mA @ 6000 V | 6000 V | 3110A | -40°C ~ 150°C | 1.7 V @ 3000 A | ||
|
W6672TE320DIODE GEN PURP 1.75KV 6672A - |
3,952 | 406.20 |
RFQ |
Datasheet |
Box | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 52 µs | 100 mA @ 1750 V | 1750 V | 6672A | -40°C ~ 160°C | 1.37 V @ 5000 A | |
|
|
W6672TE350DIODE GEN PURP 1.9KV 6672A - |
3,541 | 414.60 |
RFQ |
Datasheet |
Box | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | 52 µs | 100 mA @ 1900 V | 1900 V | 6672A | -40°C ~ 160°C | 1.37 V @ 5000 A | |
|
|
W6262ZC200RECTIFIER DIODE |
3,683 | 429.60 |
RFQ |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Chassis Mount | - | - | 150 mA @ 2000 V | 2000 V | 6262A | -40°C ~ 175°C | 1.18 V @ 6800 A |
