| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DB2S20900LDIODE SCHOTTKY 20V 500MA SOD523 |
3,521 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 7pF @ 10V, 1MHz | 2.4 ns | 30 µA @ 10 V | 20 V | 500mA | 125°C (Max) | 510 mV @ 500 mA | |
|
|
DB3X201K0LDIODE SCHOTTKY 20V 500MA SC59 |
2,482 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 12pF @ 10V, 1MHz | 4.3 ns | 10 µA @ 10 V | 20 V | 500mA | 125°C (Max) | 550 mV @ 500 mA | |
|
DB2L32400L1DIODE SCHOTTKY 30V 500MA 0201 |
3,359 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 10pF @ 10V, 1MHz | 3.2 ns | 225 µA @ 30 V | 30 V | 500mA | 150°C (Max) | 490 mV @ 500 mA | |
|
|
DB2L33400L1DIODE SCHOTTKY 30V 500MA 0201 |
3,576 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 10pF @ 10V, 1MHz | 3.5 ns | 45 µA @ 30 V | 30 V | 500mA | 150°C (Max) | 540 mV @ 500 mA | |
|
|
DB2L33500L1DIODE SCHOTTKY 30V 100MA 0201 |
3,715 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 4.4pF @ 10V, 1MHz | 1.6 ns | 70 µA @ 30 V | 30 V | 100mA | 150°C (Max) | 400 mV @ 100 mA | |
|
DB2G32500L1DIODE SCHOTTKY 30V 1A 0402 |
2,398 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 34pF @ 10V, 1MHz | 10.3 ns | 300 µA @ 30 V | 30 V | 1A | 150°C (Max) | 480 mV @ 1 A | |
|
DB2J40700LDIODE SCHOTTKY 40V 500MA SMINI2 |
2,755 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 10.5pF @ 10V, 1MHz | 3.6 ns | 100 µA @ 35 V | 40 V | 500mA | 125°C (Max) | 550 mV @ 500 mA | ||
|
DB2S20500LDIODE SCHOTTKY 15V 200MA SSMINI2 |
2,263 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 6.1pF @ 10V, 1MHz | 2.2 ns | 50 µA @ 6 V | 15 V | 200mA | 125°C (Max) | 390 mV @ 200 mA | ||
|
|
DB2S30800LDIODE SCHOTTKY 30V 100MA SSMINI2 |
2,192 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 2.9pF @ 10V, 1MHz | 1.3 ns | 120 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 420 mV @ 100 mA | ||
|
|
DB2S31000LDIODE SCHOTTKY 30V 200MA SSMINI2 |
3,276 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 4.5pF @ 10V, 1MHz | 1.6 ns | 200 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 470 mV @ 200 mA | ||
|
|
DB2S31600LDIODE SCHOTTKY 30V 100MA SSMINI2 |
2,530 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 2pF @ 10V, 1MHz | 800 ps | 15 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 550 mV @ 100 mA | ||
|
DB3X316K0LDIODE SCHOTTKY 30V 100MA MINI3 |
2,572 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 2pF @ 10V, 1MHz | 800 ps | 15 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 550 mV @ 100 mA | ||
|
|
DB3X317K0LDIODE SCHOTTKY 30V 1A MINI3 |
2,108 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 22pF @ 10V, 1MHz | 7.8 ns | 100 µA @ 30 V | 30 V | 1A | 125°C (Max) | 520 mV @ 1 A | ||
|
DB3J407K0LDIODE SCHOTTKY 40V 500MA SMINI3 |
2,898 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 12pF @ 10V, 1MHz | 5 ns | 100 µA @ 35 V | 40 V | 500mA | 125°C (Max) | 550 mV @ 500 mA | ||
|
DB2731600LDIODE SCHOTTKY 30V 100MA |
2,124 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 2pF @ 10V, 1MHz | 800 ps | 15 µA @ 30 V | 30 V | 100mA | 125°C (Max) | 550 mV @ 100 mA | ||
|
DB2J20900LDIODE SCHOTTKY 20V 500MA SMINI2 |
2,607 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 7pF @ 10V, 1MHz | 2.4 ns | 30 µA @ 10 V | 20 V | 500mA | 125°C (Max) | 500 mV @ 500 mA | |
|
|
DB3X313K0LDIODE SCHOTTKY 30V 200MA MINI3 |
2,421 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 3.8pF @ 10V, 1MHz | 1.5 ns | 50 µA @ 30 V | 30 V | 200mA | 125°C (Max) | 550 mV @ 200 mA | ||
|
|
DB3X407K0LDIODE SCHOTTKY 40V 500MA MINI3 |
2,526 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 10.5pF @ 10V, 1MHz | 3.6 ns | 100 µA @ 35 V | 40 V | 500mA | 125°C (Max) | 550 mV @ 500 mA | ||
|
|
DB3X209K0LDIODE SCHOTTKY 20V 500MA MINI3 |
2,215 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Discontinued at Digi-Key | Surface Mount | 7pF @ 10V, 1MHz | 2.4 ns | 30 µA @ 10 V | 20 V | 500mA | 125°C (Max) | 500 mV @ 500 mA | ||
|
|
DB2J31400LDIODE SCHOTTKY 30V 30MA SMINI2 |
2,302 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Discontinued at Digi-Key | Surface Mount | 1.5pF @ 10V, 1MHz | 1 ns | 300 nA @ 30 V | 30 V | 30mA (DC) | 125°C (Max) | 1 V @ 30 mA |
