| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
UPR10E3/TR13DIODE GEN PURP 100V 2.5A DO216 |
2,915 | 0.62 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 25 ns | 2 µA @ 100 V | 100 V | 2.5A | -55°C ~ 150°C | 975 mV @ 2 A | |
|
JANTX1N6622US/TRRECTIFIER UFR,FRR |
2,661 | 14.46 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/585 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 10pF @ 10V, 1MHz | 30 ns | 500 nA @ 660 V | 660 V | 2A | -65°C ~ 150°C | 1.4 V @ 1.2 A | |
|
|
UPR15E3/TR13DIODE GEN PURP 150V 2.5A DO216 |
2,562 | 0.62 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 25 ns | 2 µA @ 150 V | 150 V | 2.5A | -55°C ~ 150°C | 975 mV @ 2 A | |
|
|
UPR5E3/TR13DIODE GEN PURP 50V 2.5A DO216 |
2,436 | 0.62 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 25 ns | 2 µA @ 50 V | 50 V | 2.5A | -55°C ~ 150°C | 975 mV @ 2 A | |
|
JANTX1N6629DIODE GEN PURP 880V 1.4A |
3,634 | 14.55 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 50 ns | 2 µA @ 880 V | 880 V | 1.4A | -65°C ~ 150°C | 1.4 V @ 1.4 A |
|
JANTX1N6630RECTIFIER |
3,832 | 14.55 |
RFQ |
Bulk | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 50 ns | 2 µA @ 990 V | 900 V | 3A | -65°C ~ 175°C | 1.7 V @ 3 A | |
|
|
JANTX1N6620US/TRRECTIFIER UFR,FRR |
2,103 | 14.57 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/585 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 10pF @ 10V, 1MHz | 30 ns | 500 nA @ 220 V | 220 V | 2A | -65°C ~ 150°C | 1.4 V @ 1.2 A | |
|
JANTX1N6623/TRRECTIFIER UFR,FRR |
2,829 | 14.60 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/585 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 10pF @ 10V, 1MHz | 50 ns | 500 nA @ 880 V | 880 V | 1A | -65°C ~ 150°C | 1.55 V @ 1 A | |
|
|
JANTX1N6631/TRRECTIFIER UFR,FRR |
2,604 | 14.60 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 60 ns | 4 µA @ 1000 V | - | 2A | -65°C ~ 175°C | 1.95 V @ 2 A | |
|
|
JANTX1N6626DIODE GEN PURP 220V 1.75A AXIAL |
2,020 | 14.63 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 30 ns | 2 µA @ 220 V | 220 V | 1.75A | -65°C ~ 150°C | 1.35 V @ 2 A |
|
|
1N6540/TRRECTIFIER UFR,FRR |
2,946 | 14.63 |
RFQ |
Tape & Reel (TR) | RoHS | - | - | Active | - | - | - | - | - | - | - | - | ||
|
1N5821US/TRDIODE SMALL-SIGNAL SCHOTTKY |
2,173 | 14.69 |
RFQ |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 100 µA @ 30 V | 30 V | 3A | -65°C ~ 125°C | 500 mV @ 3 A | ||
|
|
JANTXV1N5620USRECTIFIER |
3,005 | 14.70 |
RFQ |
Bulk | Military, MIL-PRF-19500/427 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 2 µs | - | 800 V | 1A | -65°C ~ 200°C | 1.3 V @ 3 A | |
|
|
JANTX1N6630/TRRECTIFIER UFR,FRR |
3,285 | 14.70 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 50 ns | 2 µA @ 990 V | 900 V | 3A | -65°C ~ 175°C | 1.7 V @ 3 A | |
|
|
1N3647STANDARD RECTIFIER |
3,368 | 14.75 |
RFQ |
Bulk | Military, MIL-PRF-19500/279 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 1 µA @ 3000 V | - | 250mA | -65°C ~ 150°C | 5 V @ 250 mA | |
|
|
JANTX1N6626/TRRECTIFIER UFR,FRR |
2,231 | 14.78 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/590 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 40pF @ 10V, 1MHz | 30 ns | 2 µA @ 220 V | 220 V | 1.75A | -65°C ~ 150°C | 1.35 V @ 2 A | |
|
|
JANTXV1N5807DIODE GEN PURP 50V 3A AXIAL |
2,825 | 14.79 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 65pF @ 10V, 1MHz | 30 ns | 5 µA @ 50 V | 50 V | 3A | -65°C ~ 175°C | 875 mV @ 4 A |
|
|
JANTXV1N5809DIODE GEN PURP 100V 3A AXIAL |
3,357 | 14.79 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 65pF @ 10V, 1MHz | 30 ns | 5 µA @ 100 V | 100 V | 3A | -65°C ~ 175°C | 875 mV @ 4 A |
|
|
JANTXV1N5811DIODE GEN PURP 150V 3A AXIAL |
2,358 | 14.79 |
RFQ |
Datasheet |
Bulk | Military, MIL-PRF-19500/477 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 65pF @ 10V, 1MHz | 30 ns | 5 µA @ 150 V | 150 V | 3A | -65°C ~ 175°C | 875 mV @ 4 A |
|
JANTXV1N5620US/TRSTD RECTIFIER |
2,584 | 14.85 |
RFQ |
Tape & Reel (TR) | Military, MIL-PRF-19500/427 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 2 µs | - | 800 V | 1A | -65°C ~ 200°C | 1.3 V @ 3 A |
