| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S2MST Rect, 1000V, 2A |
7,281,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 1000 V | 1000 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
FE6DSF Rect, 200V, 6.00A, 50ns |
1,500 | 0.80 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 50 ns | 5 µA @ 200 V | 200 V | 6A | -50°C ~ 175°C | 980 mV @ 5 A | |
|
S2AST Rect, 50V, 2A |
474,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 50 V | 50 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
|
S2GST Rect, 400V, 2A |
459,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 400 V | 400 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
BY254-CTCUT-TAPE VERSION. STANDARD RECO |
1,700 | 0.81 |
RFQ |
Datasheet |
Strip | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 1.5 µs | 5 µA @ 800 V | 800 V | 3A | -50°C ~ 150°C | 1.1 V @ 3 A | |
|
SK110Schottky D, 100V, 1.00A |
210,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 100 V | 100 V | 1A | -50°C ~ 150°C | 850 mV @ 1 A | |
|
|
S2DST Rect, 200V, 2A |
123,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 200 V | 200 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
ES3FSF Rect, 300V, 3.00A, 25ns |
3,000 | 0.82 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 25 ns | 5 µA @ 300 V | 300 V | 3A | -50°C ~ 150°C | 1.3 V @ 3 A | |
|
FRL1MFast Rect. 1000V, 1.00A, 500ns |
81,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 500 ns | 5 µA @ 1000 V | 1000 V | 1A | -50°C ~ 150°C | 1.3 V @ 1 A | |
|
|
S2BST Rect, 100V, 2A |
36,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 100 V | 100 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
|
S2KST Rect, 800V, 2A |
3,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 800 V | 800 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
SRL1JST Rect, 600V, 1A |
3,000 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1 µs | 1 µA @ 600 V | 600 V | 1A | -50°C ~ 150°C | 1.1 V @ 1 A | |
|
HV6HV Rect., 6000V, 0.20A, 400ns |
2,240 | 0.87 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Through Hole | - | 400 ns | 3 µA @ 6000 V | 6000 V | 200mA | -50°C ~ 150°C | 6 V @ 200 mA | |
|
|
DD600Fast Rect, 6000V, 0.02A, 150ns |
2,968 | 0.89 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | - | Standard | Active | - | - | 150 ns | - | 6000 V | 20mA | - | - | |
|
SK18SchottkyD, 80V, 1A |
1,102,500 | 0.09 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 80 V | 80 V | 1A | -50°C ~ 150°C | 850 mV @ 1 A | |
|
S3YST Rect, 2000V, 3A |
504,000 | 0.93 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 2000 V | 2000 V | 3A | -50°C ~ 150°C | 1.15 V @ 3 A | |
|
DD1000HV Rect, 10000V, 0.02A, 150ns |
89,970 | 0.94 |
RFQ |
Datasheet |
Tape & Reel (TR) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Through Hole | - | 150 ns | 5 µA @ 10000 V | 10000 V | 20mA | -50°C ~ 150°C | 40 V @ 10 mA | |
|
BY550-50-CTCUT-TAPE VERSION. STANDARD RECO |
3,750 | 0.97 |
RFQ |
Datasheet |
Strip | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 1.5 µs | 5 µA @ 50 V | 50 V | 5A | -50°C ~ 175°C | 1 V @ 5 A | |
|
PT800KST Rect, 800V, 8A |
15,400 | 0.98 |
RFQ |
Datasheet |
Tube | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 5 µA @ 800 V | 800 V | 8A | -50°C ~ 150°C | 1.1 V @ 8 A | |
|
|
PT800AST Rect, 50V, 8A |
2,000 | 0.98 |
RFQ |
Datasheet |
Tube | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 5 µA @ 50 V | 50 V | 8A | -50°C ~ 150°C | 1.1 V @ 8 A |
