| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
25CTQ035S25A, 35V, D2PAK, SCHOTTKY RECTIF |
3,398 | 1.34 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 35 V | 15A | 560 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 35 V | -55°C ~ 150°C | Surface Mount |
.jpg)
|
S3D16065DDIODE SCHOTTKY SILICON CARBIDE S |
600 | 5.09 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Silicon Carbide Schottky | 650 V | 23A | 1.8 V @ 8 A | No Recovery Time > 500mA (Io) | 0 ns | 51 µA @ 650 V | -55°C ~ 175°C | Through Hole |
|
SDUR3040WTDIODE GEN PURP 400V 15A TO247AD |
2,098 | 1.71 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Standard | 400 V | 15A | 1.25 V @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 10 µA @ 400 V | -55°C ~ 150°C | Through Hole |
|
|
30CPQ035DIODE SCHOTTKY 35V 15A TO247AD |
3,700 | 2.29 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 35 V | 15A | 680 mV @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 35 V | -55°C ~ 150°C | Through Hole |
|
|
S4D10120DDIODE SCHOTTKY SILICON CARBIDE S |
146 | 4.19 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Silicon Carbide Schottky | 1200 V | 5A | 1.8 V @ 5 A | No Recovery Time > 500mA (Io) | 0 ns | 200 µA @ 1200 V | -55°C ~ 175°C | Through Hole |
|
S3D30065DDIODE SCHOTTKY SILICON CARBIDE S |
295 | 8.66 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 650 V | 15A | 1.7 V @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 25 µA @ 650 V | -55°C ~ 175°C | Through Hole |
|
|
S4D30120DDIODE SCHOTTKY SILICON CARBIDE S |
300 | 10.41 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Silicon Carbide Schottky | 1200 V | 15A | 1.8 V @ 15 A | No Recovery Time > 500mA (Io) | 0 ns | 200 µA @ 1200 V | -55°C ~ 175°C | Through Hole |
|
|
S3D40065DDIODE SCHOTTKY SILICON CARBIDE S |
292 | 12.19 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 650 V | 48A | 1.7 V @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 50 µA @ 650 V | -55°C ~ 175°C | Through Hole |
|
|
40CPQ10040A 100V TO-247AD SCHOTTKY RECT |
432 | 2.94 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 100 V | 20A | 790 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -55°C ~ 150°C | Through Hole |
;;.jpg)
|
208CMQ060DIODE SCHOTTKY 60V 100A PRM4 |
3,818 | 64.02 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Schottky | 60 V | 100A | 680 mV @ 100 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1.1 mA @ 60 V | -55°C ~ 150°C | Chassis Mount |
|
SDURF1030CTDIODE ARRAY GP 300V ITO220AB |
238 | 0.64 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Standard | 300 V | - | 1.3 V @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 30 µA @ 300 V | -55°C ~ 150°C | Through Hole |
|
|
MBRF10150CTDIODE ARRAY SCHOTTKY 150V ITO220 |
3,864 | 0.65 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 150 V | - | 930 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 150 V | -55°C ~ 150°C | Through Hole |
|
10CTQ15010A, 150V, TO-220AB, SCHOTTKY |
484 | 0.77 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 150 V | 5A | 930 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 50 µA @ 150 V | -55°C ~ 175°C | Through Hole |
|
|
MBRF20200CTDIODE ARRAY SCHOTTKY 200V ITO220 |
995 | 0.89 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 200 V | - | 950 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 200 V | -55°C ~ 175°C | Through Hole |
|
|
MBR20150CTDIODE ARRAY SCHOTTKY 150V TO220 |
533 | 0.89 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 150 V | - | 900 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 150 V | -55°C ~ 150°C | Through Hole |
|
|
MBRF20100CTDIODE ARRAY SCHOTTKY 100V ITO220 |
407 | 0.90 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 100 V | - | 800 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -55°C ~ 150°C | Through Hole |
|
|
SBR20100CTDIODE SCHOTTKY 100V TO220AB |
324 | 0.95 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 100 V | - | 900 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 100 V | -55°C ~ 150°C | Through Hole |
|
|
MBR3045CTPDIODE ARRAY SCHOTTKY 45V TO220AB |
473 | 0.99 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 45 V | - | 700 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 45 V | -55°C ~ 150°C | Through Hole |
|
|
SDUR6030WTDIODE ARRAY GP 300V TO247AD |
430 | 2.44 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Standard | 300 V | - | 1.3 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 5 µA @ 300 V | -55°C ~ 150°C | Through Hole |
|
|
40CPQ06040A, 60V, TO-247AD, SCHOTTKY REC |
220 | 2.59 |
RFQ |
Datasheet |
Tube | - | Active | 1 Pair Common Cathode | Schottky | 60 V | 20A | 530 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 60 V | -55°C ~ 150°C | Through Hole |
