| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | NumberofBits | NumberofD/AConverters | SettlingTime | OutputType | DifferentialOutput | DataInterface | ReferenceType | Voltage-SupplyAnalog | Voltage-SupplyDigital | INL/DNL(LSB) | Architecture | OperatingTemperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DAC8800FSZ-REELIC DAC 8BIT V-OUT 20SOIC |
549 | 39.36 |
RFQ |
Datasheet |
20-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR),Cut Tape (CT) | TrimDAC® | Active | 8 | 8 | 2µs | Voltage - Unbuffered | No | SPI | External | 4V ~ 16V, -12V | - | -, ±1 (Max) | String DAC | -40°C ~ 85°C |
|
AD7249BRZ-REELIC DAC 12BIT V-OUT 16SOIC |
660 | 36.73 |
RFQ |
Datasheet |
16-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR),Cut Tape (CT) | DACPORT® | Active | 12 | 2 | 10µs | Voltage - Buffered | No | SPI | External, Internal | ±11.4V ~ 15.75V | - | ±0.5 (Max), ±0.9 (Max) | R-2R | -40°C ~ 85°C |
|
AD3541RBCPZ16-RL7SINGLE CH 16 BIT LVSS |
1,423 | 38.57 |
RFQ |
Datasheet |
28-VFQFN, CSP | Tape & Reel (TR),Cut Tape (CT) | - | Active | 16 | 1 | 100ns | Voltage - Unbuffered | No | SPI | Internal | 4.75V ~ 5.25V | 1.71V ~ 1.89V | ±4 (Max), ±2 (Max) | Current Steering | -40°C ~ 105°C |
|
AD7233BNZIC DAC 12BIT V-OUT 8DIP |
114 | 47.97 |
RFQ |
Datasheet |
8-DIP (0.300, 7.62mm) | Tube | DACPORT® | Active | 12 | 1 | 10µs | Voltage - Buffered | No | SPI | Internal | ±10.8V ~ 16.5V | - | ±0.5 (Max), ±0.9 (Max) | R-2R | -40°C ~ 85°C |
|
AD5542CRZ-REEL7IC DAC 16BIT V-OUT 14SOIC |
209 | 52.61 |
RFQ |
Datasheet |
14-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT) | - | Active | 16 | 1 | 1µs (Typ) | Voltage - Unbuffered | No | SPI, DSP | External | 2.7V ~ 5.5V | 2.7V ~ 5.5V | ±0.5, ±0.5 | R-2R | -40°C ~ 85°C |
|
LTC1592ACG#TRPBFIC DAC 16BIT A-OUT 16SSOP |
784 | 53.96 |
RFQ |
Datasheet |
16-SSOP (0.209, 5.30mm Width) | Tape & Reel (TR),Cut Tape (CT) | SoftSpan™ | Active | 16 | 1 | 2µs (Typ) | Current - Unbuffered | Yes | SPI | External | 5V | 5V | ±0.4, ±0.2 | Multiplying DAC | 0°C ~ 70°C |
|
AD5767BCBZ-RL7IC DAC 12BIT V-OUT 49WLCSP |
1,288 | 51.98 |
RFQ |
Datasheet |
49-UFBGA, WLCSP | Tape & Reel (TR),Cut Tape (CT) | - | Active | 12 | 16 | 12µs | Voltage - Unbuffered | No | SPI, DSP | External | 2.97V ~ 16V | - | ±1, ±1 | String DAC | -40°C ~ 105°C |
|
AD5767BCPZ-RL7IC DAC 12BIT V-OUT 40LFCSP |
646 | 51.98 |
RFQ |
Datasheet |
40-WFQFN Exposed Pad, CSP | Tape & Reel (TR),Cut Tape (CT) | - | Active | 12 | 16 | 12µs | Voltage - Unbuffered | No | SPI, DSP | External | 2.97V ~ 16V | - | ±1, ±1 | String DAC | -40°C ~ 105°C |
|
AD5361BSTZ-REELIC DAC 14BIT V-OUT 52LQFP |
1,240 | 59.98 |
RFQ |
Datasheet |
52-LQFP | Tape & Reel (TR),Cut Tape (CT) | - | Active | 14 | 16 | 30µs | Voltage - Buffered | No | SPI, DSP | External | 8V ~ 16.5V, -4.5V ~ 16.5V | 2.5V ~ 5.5V | ±1 (Max), ±1 (Max) | String DAC | -40°C ~ 85°C |
|
AD7547KPZIC DAC 12BIT A-OUT 28PLCC |
104 | 1.00 |
RFQ |
Datasheet |
28-LCC (J-Lead) | Bulk,Tube | - | Active | 12 | 2 | 1.5µs | Current - Unbuffered | No | Parallel | External | 10.8V ~ 16.5V | 10.8V ~ 16.5V | ±0.5 (Max), ±1 (Max) | R-2R | -40°C ~ 85°C |
|
|
AD5766BCPZ-RL7IC DAC 16BIT V-OUT 40LFCSP |
988 | 69.88 |
RFQ |
Datasheet |
40-WFQFN Exposed Pad, CSP | Tape & Reel (TR),Cut Tape (CT) | - | Active | 16 | 16 | 12µs | Voltage - Unbuffered | No | SPI, DSP | External | 2.97V ~ 16V | - | ±16, ±1 | String DAC | -40°C ~ 105°C |
|
|
AD7226KRZ-REELIC DAC 8BIT V-OUT 20SOIC |
573 | 79.17 |
RFQ |
Datasheet |
20-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR),Cut Tape (CT) | - | Active | 8 | 4 | 4µs | Voltage - Buffered | No | Parallel | External | 11.4V ~ 16.5V, -5V | 14.25V ~ 15.75V | ±0.5 (Max), ±1 (Max) | R-2R | -40°C ~ 85°C |
|
AD568JQIC DAC 12BIT A-OUT 24CDIP |
2,205 | 1.00 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk,Tube | - | Obsolete | 12 | 1 | 35µs (Typ) | Current - Unbuffered | No | Parallel | Internal | ±13.5V ~ 16.5V | 5V | ±0.75 (Max), ±1 (Max) | R-2R | 0°C ~ 70°C |
|
AD565AKDIC DAC 12BIT A-OUT 24CDIP |
3,731 | 121.47 |
RFQ |
Datasheet |
24-CDIP (0.600, 15.24mm) | Bulk,Tube | - | Active | 12 | 1 | 400ns | Current - Unbuffered | No | Parallel | External, Internal | ±11.4V ~ 16.5V | - | ±0.25, ±0.25 | R-2R | 0°C ~ 70°C |
|
5962-9320401MEAIC DAC 12BIT V-OUT 16CDIP |
3,005 | 1.00 |
RFQ |
Datasheet |
16-CDIP (0.300, 7.62mm) | Bulk,Tube | DACPORT® | Active | 12 | 1 | 10µs | Voltage - Buffered | No | SPI | External, Internal | ±12V ~ 15V | - | ±1 (Max), ±0.9 (Max) | R-2R | -55°C ~ 125°C |
|
|
AD7840SQ/883BIC DAC 14BIT V-OUT 24CDIP |
852 | 209.78 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk,Tube | Military, MIL-STD-883 | Active | 14 | 1 | 4µs | Voltage - Buffered | No | Parallel, Serial | External, Internal | ±5V | - | ±2 (Max), ±0.9 (Max) | R-2R | -55°C ~ 125°C |
|
AD667SEIC DAC 12BIT V-OUT 28LCCC |
730 | 282.75 |
RFQ |
Datasheet |
28-LCC | Bulk,Tube | - | Active | 12 | 1 | 4µs | Voltage - Buffered | No | Parallel | External, Internal | ±11.4V ~ 16.5V | - | ±0.125, ±0.25 | R-2R | -55°C ~ 125°C |
|
5962-9078501MLASEMICONDUCTOR OTHER |
2,356 | 1.00 |
RFQ |
- | Bulk,Tube | - | Active | - | - | - | - | - | - | - | - | - | - | - | - | |
|
DAC8412AT/883CIC DAC 12BIT 28CDIP |
2,577 | 732.15 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Tube | - | Active | 12 | 4 | 10µs (Typ) | Voltage - Buffered | No | Parallel | External | 5V ~ 15V | 5V | ±0.75, -1 | R-2R | -55°C ~ 125°C |
|
|
5962-88663013XIC DAC 8BIT OCTAL 28CLCC |
3,156 | 962.82 |
RFQ |
Datasheet |
28-LCC | Tube | - | Active | 8 | 8 | 5µs, 7µs | Voltage - Buffered | No | Parallel | External | 10.8V ~ 16.5V, -4.5V ~ -5.5V | 13.5V ~ 16.5V | ±1 (Max), ±1 (Max) | R-2R | -55°C ~ 125°C |
