| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PEV227KLL4210QE4ALUMINUM ELECTROLYTIC, VERTICAL |
3,471 | 5.50 |
RFQ |
Datasheet |
Tray | PEV227 | Active | 2100 µF | -10%, +30% | 40 V | 49mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 6.65 A @ 100 Hz | 19.76 A @ 100 kHz | - | - | 0.748 L x 0.748 W (19.00mm x 19.00mm) | 1.181 (30.00mm) | 1.102 L x 1.102 W (28.00mm x 28.00mm) | Surface Mount |
|
PES227KLP4300QE4ALUMINUM ELECTROLYTIC, RADIAL CR |
2,836 | 5.59 |
RFQ |
Datasheet |
Tray | PES227 | Active | 3000 µF | -10%, +30% | 40 V | 35mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 7.42 A @ 100 Hz | 22.048 A @ 100 kHz | - | - | 1.693 L x 0.787 W (43.00mm x 20.00mm) | 0.697 (17.70mm) | 1.994 L x 0.689 W (50.65mm x 17.50mm) | Surface Mount |
|
|
PEV227MKP4110QE4ALUMINUM ELECTROLYTIC, VERTICAL |
3,442 | 5.59 |
RFQ |
Datasheet |
Tray | PEV227 | Active | 1100 µF | -10%, +30% | 63 V | 76mOhm @ 100Hz | 6300 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 5.215 A @ 100 Hz | 15.496 A @ 100 kHz | - | - | 0.669 L x 0.669 W (17.00mm x 17.00mm) | 1.496 (38.00mm) | 1.024 L x 1.024 W (26.00mm x 26.00mm) | Surface Mount |
|
|
PEV227MLL4110QE4ALUMINUM ELECTROLYTIC, VERTICAL |
3,569 | 9.56 |
RFQ |
Datasheet |
Tray | PEV227 | Active | 1100 µF | -10%, +30% | 63 V | 77mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 5.32 A @ 100 Hz | 15.808 A @ 100 kHz | - | - | 0.748 L x 0.748 W (19.00mm x 19.00mm) | 1.181 (30.00mm) | 1.102 L x 1.102 W (28.00mm x 28.00mm) | Surface Mount |
|
PEH536VCD3180M2CAP ALUM 180UF 20% 400V SNAP |
3,517 | 4.62 |
RFQ |
Datasheet |
Bulk | PEH536 | Active | 180 µF | ±20% | 400 V | 480mOhm @ 100Hz | 4600 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1 A @ 100 Hz | - | - | 0.394 (10.00mm) | 1.181 Dia (30.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
|
PEV227KKP4220ME4ALUMINUM ELECTROLYTIC, VERTICAL |
3,860 | 5.67 |
RFQ |
Datasheet |
Tray | PEV227 | Active | 2200 µF | ±20% | 40 V | 47mOhm @ 100Hz | 6300 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 6.65 A @ 100 Hz | 19.76 A @ 100 kHz | - | - | 0.669 L x 0.669 W (17.00mm x 17.00mm) | 1.496 (38.00mm) | 1.024 L x 1.024 W (26.00mm x 26.00mm) | Surface Mount |
|
ELG108M200AT3AACAP ALUM 1000UF 20% 200V SNAP |
3,656 | 3.58 |
RFQ |
Datasheet |
Bulk | ELG | Active | 1000 µF | ±20% | 200 V | 90mOhm @ 20kHz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 2.3 A @ 120 Hz | 3.45 A @ 10 kHz | - | 0.394 (10.00mm) | 1.378 Dia (35.00mm) | 1.457 (37.00mm) | - | Through Hole |
|
|
PEV227MLP4160QE4ALUMINUM ELECTROLYTIC, VERTICAL |
3,617 | 5.69 |
RFQ |
Datasheet |
Tray | PEV227 | Active | 1600 µF | -10%, +30% | 63 V | 55mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 6.055 A @ 100 Hz | 17.992 A @ 100 kHz | - | - | 0.748 L x 0.748 W (19.00mm x 19.00mm) | 1.496 (38.00mm) | 1.102 L x 1.102 W (28.00mm x 28.00mm) | Surface Mount |
|
ALC80A622BD040CAP ALUM 6200UF 20% 40V SNAP |
3,556 | 3.65 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 6200 µF | ±20% | 40 V | 87mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.29 A @ 100 Hz | 5.78 A @ 10 kHz | 70 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
ALC80D622BD040CAP ALUM 6200UF 20% 40V SNAP |
2,845 | 3.65 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 6200 µF | ±20% | 40 V | 87mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.29 A @ 100 Hz | 5.78 A @ 10 kHz | 70 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
ALC80F622BD040CAP ALUM 6200UF 20% 40V SNAP |
3,560 | 3.65 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 6200 µF | ±20% | 40 V | 87mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.29 A @ 100 Hz | 5.78 A @ 10 kHz | 70 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
PES227MLP4160QE4ALUMINUM ELECTROLYTIC, RADIAL CR |
2,699 | 5.81 |
RFQ |
Datasheet |
Tray | PES227 | Active | 1600 µF | -10%, +30% | 63 V | 55mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 6.055 A @ 100 Hz | 17.992 A @ 100 kHz | - | - | 1.693 L x 0.787 W (43.00mm x 20.00mm) | 0.697 (17.70mm) | 1.994 L x 0.689 W (50.65mm x 17.50mm) | Surface Mount |
|
|
ALC80A910BB450CAP ALUM 91UF 20% 450V SNAP |
3,095 | 3.69 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 91 µF | ±20% | 450 V | 1.422Ohm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 870 mA @ 100 Hz | 2.51 A @ 10 kHz | 816 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
ALC80D910BB450CAP ALUM 91UF 20% 450V SNAP |
2,056 | 3.69 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 91 µF | ±20% | 450 V | 1.422Ohm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 870 mA @ 100 Hz | 2.51 A @ 10 kHz | 816 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
ALC80F910BB450CAP ALUM 91UF 20% 450V SNAP |
2,993 | 3.69 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 91 µF | ±20% | 450 V | 1.422Ohm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 870 mA @ 100 Hz | 2.51 A @ 10 kHz | 816 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.260 (32.00mm) | - | Through Hole |
|
|
ALC80D392BD063CAP ALUM 3900UF 20% 63V SNAP |
3,446 | 3.71 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 3900 µF | ±20% | 63 V | 96mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.76 A @ 100 Hz | 5.39 A @ 10 kHz | 72 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
ALC80F392BD063CAP ALUM 3900UF 20% 63V SNAP |
3,332 | 3.71 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 3900 µF | ±20% | 63 V | 96mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.76 A @ 100 Hz | 5.39 A @ 10 kHz | 72 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
ALC80D153BD025CAP ALUM 15000UF 20% 25V SNAP |
2,191 | 3.76 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 15000 µF | ±20% | 25 V | 81mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.73 A @ 100 Hz | 5.81 A @ 10 kHz | 71 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
ALC80F153BD025CAP ALUM 15000UF 20% 25V SNAP |
2,572 | 3.76 |
RFQ |
Datasheet |
Bulk | ALC80 | Active | 15000 µF | ±20% | 25 V | 81mOhm @ 100Hz | 6000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 4.73 A @ 100 Hz | 5.81 A @ 10 kHz | 71 mOhms | 0.394 (10.00mm) | 0.984 Dia (25.00mm) | 1.654 (42.00mm) | - | Through Hole |
|
|
PES227HLP4620QE4ALUMINUM ELECTROLYTIC, RADIAL CR |
3,640 | 5.96 |
RFQ |
Datasheet |
Tray | PES227 | Active | 6200 µF | -10%, +30% | 25 V | 27mOhm @ 100Hz | 8400 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 7.56 A @ 100 Hz | 22.464 A @ 100 kHz | - | - | 1.693 L x 0.787 W (43.00mm x 20.00mm) | 0.697 (17.70mm) | 1.994 L x 0.689 W (50.65mm x 17.50mm) | Surface Mount |
