| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | IGBTType | Voltage-CollectorEmitterBreakdown(Max) | Current-Collector(Ic)(Max) | Current-CollectorPulsed(Icm) | Vce(on)(Max)@VgeIc | Power-Max | SwitchingEnergy | InputType | GateCharge | Td(on/off)@25°C | TestCondition | ReverseRecoveryTime(trr) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IXGA36N60A3IGBT |
2,391 | 0.00 |
RFQ |
Datasheet |
Tube | GenX3™ | Obsolete | PT | 600 V | - | 200 A | 1.4V @ 15V, 30A | 220 W | 740µJ (on), 3mJ (off) | Standard | 80 nC | 18ns/330ns | 400V, 30A, 5Ohm, 15V | 23 ns | -55°C ~ 150°C (TJ) | Surface Mount |
|
IXGH28N60A3IGBT |
2,721 | 0.00 |
RFQ |
Datasheet |
Tube | GenX3™ | Obsolete | PT | 600 V | 75 A | 170 A | 1.4V @ 15V, 24A | 190 W | 700µJ (on), 2.4mJ (off) | Standard | 66 nC | 18ns/300ns | 480V, 24A, 10Ohm, 15V | 26 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
IXXN200N65A4IGBT |
2,434 | 0.00 |
RFQ |
Datasheet |
Tube | XPT™, GenX4™ | Active | - | 650 V | 440 A | 1200 A | 1.8V @ 15V, 200A | 1250 W | 8.8mJ (on), 6.7mJ (off) | Standard | 736 nC | 140ns/1.04µs | 400V, 100A, 1Ohm, 15V | 160 ns | -55°C ~ 175°C (TJ) | Chassis Mount |
|
|
IXYA20N65B3IGBT |
2,008 | 0.00 |
RFQ |
Datasheet |
Tube | XPT™, GenX3™ | Active | - | 650 V | 58 A | 108 A | 2.1V @ 15V, 20A | 230 W | 500µJ (on), 700µJ (off) | Standard | 29 nC | 12ns/103ns | 400V, 20A, 20Ohm, 15V | 25 ns | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IXYH75N120B4IGBT |
2,737 | 0.00 |
RFQ |
Datasheet |
Tube | XPT™, GenX4™ | Active | - | 1200 V | 240 A | 440 A | 2.2V @ 15V, 75A | 1150 W | 4.5mJ (on), 2.7mJ (off) | Standard | 157 nC | 22ns/182ns | 600V, 50A, 3Ohm, 15V | 66 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
IXYQ40N65C3D1IGBT |
3,659 | 0.00 |
RFQ |
Datasheet |
Tube | XPT™, GenX3™ | Active | - | 650 V | 80 A | 180 A | 2.35V @ 15V, 40A | 300 W | 830µJ (on), 650µJ (off) | Standard | 66 nC | 23ns/110ns | 400V, 30A, 10Ohm, 15V | 40 ns | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXGM17N100APOWER MOSFET TO-3 |
2,085 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | - | 1000 V | 34 A | 68 A | 4V @ 15V, 17A | 150 W | 3mJ (off) | Standard | 120 nC | 100ns/500ns | 800V, 17A, 82Ohm, 15V | 200 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXGM20N60POWER MOSFET TO-3 |
3,447 | 0.00 |
RFQ |
Tube | - | Obsolete | - | 600 V | 40 A | 80 A | 2.5V @ 15V, 20A | 150 W | 2mJ (on), 3.2mJ (off) | Standard | 120 nC | 100ns/600ns | 480V, 20A, 82Ohm, 15V | 200 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGM20N60APOWER MOSFET TO-3 |
2,980 | 0.00 |
RFQ |
Tube | - | Obsolete | - | 600 V | 40 A | 80 A | 3V @ 15V, 20A | 150 W | 2mJ (on), 2mJ (off) | Standard | 120 nC | 100ns/600ns | 480V, 20A, 82Ohm, 15V | 200 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGM25N100APOWER MOSFET TO-3 |
2,561 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | - | 1000 V | 50 A | 100 A | 4V @ 15V, 25A | 200 W | 5mJ (off) | Standard | 180 nC | 100ns/500ns | 800V, 25A, 33Ohm, 15V | 200 ns | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXGM30N60POWER MOSFET TO-3 |
3,864 | 0.00 |
RFQ |
Tube | - | Obsolete | - | 600 V | 50 A | 100 A | 2.5V @ 15V, 30A | 200 W | - | Standard | 180 nC | 100ns/500ns | - | 200 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGM40N60POWER MOSFET TO-3 |
3,638 | 0.00 |
RFQ |
Tube | - | Obsolete | - | 600 V | 75 A | 150 A | 2.5V @ 15V, 40A | 250 W | - | Standard | 250 nC | 100ns/600ns | 480V, 40A, 22Ohm, 15V | 200 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGM40N60ALPOWER MOSFET TO-3 |
2,599 | 0.00 |
RFQ |
Tube | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
IXGP48N60B3DISC IGBT PT-MID FREQUENCY TO-22 |
3,542 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 48 A | 280 A | 1.8V @ 15V, 32A | 300 W | 840µJ (on), 660µJ (off) | Standard | 115 nC | 22ns/130ns | 480V, 30A, 5Ohm, 15V | 25 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGH56N60B3DISC IGBT PT-MID FREQUENCY TO-24 |
2,875 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 130 A | 350 A | 1.8V @ 15V, 44A | 330 W | 1.3mJ (on), 1.05mJ (off) | Standard | 138 nC | 26ns/155ns | 480V, 44A, 5Ohm, 15V | 41 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGT64N60B3DISC IGBT PT-MID FREQUENCY TO-26 |
3,751 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 64 A | 400 A | 1.8V @ 15V, 50A | 460 W | 1.5mJ (on), 1mJ (off) | Standard | 168 nC | 25ns/138ns | 480V, 50A, 3Ohm, 15V | 41 ns | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXGR72N60C3DISC IGBT PT-HIFREQUENCY ISOPLUS |
2,130 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 80 A | 400 A | 2.7V @ 15V, 50A | 200 W | 1.03mJ (on), 480µJ (off) | Standard | 175 nC | 27ns/77ns | 480V, 50A, 2Ohm, 15V | 37 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGK120N60B3DISC IGBT PT-MID FREQUENCY TO-26 |
3,396 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 280 A | 600 A | 1.8V @ 15V, 100A | 780 W | 2.9mJ (on), 3.5mJ (off) | Standard | 465 nC | 40ns/227ns | 480V, 100A, 2Ohm, 15V | 87 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXGP28N60A3MDISC IGBT PT-LOW FREQUENCY TO-22 |
2,591 | 0.00 |
RFQ |
Tube | GenX3™ | Obsolete | PT | 600 V | 38 A | 200 A | 1.4V @ 15V, 24A | 64 W | - | Standard | 66 nC | 18ns/300ns | 480V, 24A, 10Ohm, 15V | 26 ns | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
IXYP30N65B3D1IGBT 650V 30A TO220 |
2,213 | 0.00 |
RFQ |
Tube | GenX3™, XPT™ | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | Through Hole |
