| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FDMS8558SDCMOSFET N-CH 25V 38A/90A 8PQFN |
3,222 | 1.00 |
RFQ |
Datasheet |
Bulk | PowerTrench®, SyncFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 38A (Ta), 90A (Tc) | - | 1.5mOhm @ 38A, 10V | 2.2V @ 1mA | 81 nC @ 10 V | ±12V | 5118 pF @ 13 V | - | 3.3W (Ta), 89W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FDMS3006SDC34A, 30V, 0.0019OHM, N-CHANNEL |
3,524 | 0.00 |
RFQ |
Datasheet |
Bulk | Dual Cool™, PowerTrench®, SyncFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 34A (Ta) | 4.5V, 10V | 1.9mOhm @ 30A, 10V | 3V @ 1mA | 80 nC @ 10 V | ±20V | 5725 pF @ 15 V | - | 3.3W (Ta), 89W (Tc) | -55°C ~ 150°C (TJ) | |
|
FDN371N2.5A, 20V, 1-ELEMENT, N-CHANNEL |
3,171 | 0.00 |
RFQ |
Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 2.5A (Ta) | 2.5V, 4.5V | 50mOhm @ 2.5A, 4.5V | 1.5V @ 250µA | 10.7 nC @ 4.5 V | ±12V | 815 pF @ 10 V | - | 500mW (Ta) | -55°C ~ 150°C (TJ) | ||
|
FDS4410ASINGLE N CHANNEL, LOGIC-LEVEL, P |
2,507 | 1.00 |
RFQ |
Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta) | - | 13.5mOhm @ 10A, 10V | 3V @ 250µA | 16 nC @ 5 V | - | 1205 pF @ 15 V | - | - | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
FDMS8558S38A, 25V, 0.0015OHM, N-CHANNEL |
2,958 | 0.00 |
RFQ |
Datasheet |
Bulk | PowerTrench®, SyncFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 33A (Ta), 90A (Tc) | 4.5V, 10V | 1.5mOhm @ 33A, 10V | 2.2V @ 1mA | 81 nC @ 10 V | ±12V | 5118 pF @ 13 V | - | 2.5W (Ta), 78W (Tc) | -55°C ~ 150°C (TJ) | |
|
FDMS9408L-F085MOSFET N-CH 40V 80A 8PQFN |
2,045 | 1.00 |
RFQ |
Bulk | Automotive, AEC-Q101, PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 80A (Tc) | - | 1.7mOhm @ 80A, 10V | 3V @ 250µA | 110 nC @ 10 V | ±20V | 5750 pF @ 20 V | - | 214W (Tj) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
FDC6392S2.2A, 20V, P-CHANNEL, MOSFET |
2,987 | 1.00 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.2A (Ta) | 2.5V, 4.5V | 150mOhm @ 2.2A, 4.5V | 1.5V @ 250µA | 5.2 nC @ 4.5 V | ±12V | 369 pF @ 10 V | Schottky Diode (Isolated) | 960mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FDMS8560S35A, 25V, 0.0018OHM, N-CHANNEL |
3,116 | 0.00 |
RFQ |
Datasheet |
Bulk | PowerTrench®, SyncFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 30A (Ta), 70A (Tc) | 4.5V, 10V | 1.8mOhm @ 30A, 10V | 2.2V @ 1mA | 68 nC @ 10 V | ±12V | 4350 pF @ 13 V | - | 2.5W (Ta), 65W (Tc) | -55°C ~ 150°C (TJ) | |
|
IRF614BFP001MOSFET N-CH 250V 2.8A TO220F-3 |
2,618 | 1.00 |
RFQ |
Datasheet |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 250 V | 2.8A (Tc) | - | 2Ohm @ 1.4A, 10V | 4V @ 250µA | 10.5 nC @ 10 V | ±30V | 275 pF @ 25 V | - | 40W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
FQA38N3038.4A, 300V, N-CHANNEL, MOSFET |
3,315 | 1.00 |
RFQ |
Datasheet |
Bulk | QFET® | Active | N-Channel | MOSFET (Metal Oxide) | 300 V | 38.4A (Tc) | 10V | 85mOhm @ 19.2A, 10V | 5V @ 250µA | 120 nC @ 10 V | ±30V | 4400 pF @ 25 V | - | 290W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
FCPF20N60ST20A, 600V, 0.19OHM, N CHANNEL |
3,000 | 0.00 |
RFQ |
Bulk | SuperFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Tc) | - | - | - | - | - | - | - | - | - | ||
|
|
FDN3401FDN3401 |
3,397 | 1.00 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
|
FCB20N60-F085MOSFET N-CH 600V 20A D2PAK |
3,736 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, SuperFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Tc) | - | 198mOhm @ 20A, 10V | 5V @ 250µA | 102 nC @ 10 V | ±30V | 3080 pF @ 25 V | - | 341W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FDMS9408-F085N-CHANNEL MOSFET |
2,879 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101, PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 80A (Tc) | 10V | 1.8mOhm @ 80A, 10V | 4V @ 250µA | 92 nC @ 10 V | ±20V | 5120 pF @ 25 V | - | 214W (Tj) | -55°C ~ 175°C (TJ) | Surface Mount |
|
FDS9431A-F085MOSFET P-CH 20V 3.5A 8SOIC |
2,992 | 1.00 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 3.5A (Ta) | - | 130mOhm @ 3.5A, 4.5V | 1V @ 250µA | 8.5 nC @ 4.5 V | ±8V | 405 pF @ 10 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FCPF11N60T11A, 600V, 0.38OHM, N-CHANNEL |
3,728 | 0.00 |
RFQ |
Bulk | SuperFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 11A (Tc) | 10V | 380mOhm @ 5.5A, 10V | 5V @ 250µA | 52 nC @ 10 V | ±30V | 1490 pF @ 25 V | - | 36W (Tc) | -55°C ~ 150°C (TJ) | ||
|
|
FDPF13N50NZ1-ELEMENT, N-CHANNEL |
2,344 | 1.00 |
RFQ |
Bulk | UniFET-II™ | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 12A | - | 540mOhm @ 6A, 10V | 5V @ 250µA | 39 nC @ 10 V | - | 1930 pF @ 25 V | - | 42W (Tc) | - | Through Hole | |
|
FDMC8884-FSMOSFET N-CH 30V 9A/15A 8MLP |
3,962 | 1.00 |
RFQ |
Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 9A (Ta), 15A (Tc) | - | 19mOhm @ 9A, 10V | 2.5V @ 250µA | 14 nC @ 10 V | ±20V | 685 pF @ 15 V | - | 2.3W (Ta), 18W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
FQB17P10TMMOSFET P-CH 100V 16.5A D2PAK |
2,936 | 0.00 |
RFQ |
Datasheet |
Bulk | QFET® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 16.5A (Tc) | 10V | 190mOhm @ 8.25A, 10V | 4V @ 250µA | 39 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 3.75W (Ta), 100W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
HUFA76645S3SMOSFET N-CH 100V 75A D2PAK |
3,507 | 0.00 |
RFQ |
Datasheet |
Tube | UltraFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 75A (Tc) | 4.5V, 10V | 14mOhm @ 75A, 10V | 3V @ 250µA | 153 nC @ 10 V | ±16V | 4400 pF @ 25 V | - | 310W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
