| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FDD6780A16.4A, 25V, 0.0086OHM, N-CHANNEL |
52,350 | 0.48 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 16.4A (Ta), 30A (Tc) | 4.5V, 10V | 8.6mOhm @ 16.4A, 10V | 3V @ 250µA | 24 nC @ 10 V | ±20V | 1235 pF @ 13 V | - | 3.7W (Ta), 32.6W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
FDS6680SMOSFET N-CH 30V 11.5A 8SOIC |
42,578 | 0.48 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11.5A (Ta) | 4.5V, 10V | 11mOhm @ 11.5A, 10V | 3V @ 250µA | 24 nC @ 5 V | ±20V | 2010 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
SFM9110TFMOSFET P-CH 100V 1A SOT223-4 |
6,784 | 0.48 |
RFQ |
Datasheet |
Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 1A (Ta) | 10V | 1.2Ohm @ 500mA, 10V | 4V @ 250µA | 10 nC @ 10 V | ±30V | 335 pF @ 25 V | - | 2.52W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDB6030LMOSFET N-CH 30V 48A TO263AB |
22,487 | 0.49 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 48A (Ta) | 4.5V, 10V | 13mOhm @ 26A, 10V | 3V @ 250µA | 18 nC @ 5 V | ±20V | 1250 pF @ 15 V | - | 52W (Tc) | -65°C ~ 175°C (TJ) | Surface Mount |
|
HUF76131SK8TN-CHANNEL POWER MOSFET |
10,025 | 0.49 |
RFQ |
Datasheet |
Bulk | UltraFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta) | 4.5V, 10V | 13mOhm @ 10A, 10V | 1V @ 250µA | 47 nC @ 10 V | ±20V | 1605 pF @ 25 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDPF5N50TYDTUMOSFET N-CH 500V 5A TO220F |
51,180 | 0.55 |
RFQ |
Datasheet |
Tube | UniFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 5A (Tc) | 10V | 1.4Ohm @ 2.5A, 10V | 5V @ 250µA | 15 nC @ 10 V | ±30V | 640 pF @ 25 V | - | 28W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
FDP6670ALMOSFET N-CH 30V 80A TO220-3 |
26,871 | 0.55 |
RFQ |
Datasheet |
Tube | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 80A (Ta) | 4.5V, 10V | 6.5mOhm @ 40A, 10V | 3V @ 250µA | 33 nC @ 5 V | ±20V | 2440 pF @ 15 V | - | 68W (Tc) | -65°C ~ 175°C (TJ) | Through Hole |
|
FQU7N20TUMOSFET N-CH 200V 5.3A IPAK |
18,301 | 0.55 |
RFQ |
Datasheet |
Tube | QFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 200 V | 5.3A (Tc) | 10V | 690mOhm @ 2.65A, 10V | 5V @ 250µA | 10 nC @ 10 V | ±30V | 400 pF @ 25 V | - | 2.5W (Ta), 45W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
SI4425DYP-CHANNEL MOSFET |
1,098 | 0.73 |
RFQ |
Datasheet |
Bulk | PowerTrench™ | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta) | 4.5V, 10V | 14mOhm @ 11A, 10V | 3V @ 250µA | 42 nC @ 5 V | ±20V | 3000 pF @ 15 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FDFS2P753AZMOSFET P-CH 30V 3A 8SOIC |
9,106 | 0.49 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 3A (Ta) | 4.5V, 10V | 115mOhm @ 3A, 10V | 3V @ 250µA | 11 nC @ 10 V | ±25V | 455 pF @ 15 V | Schottky Diode (Isolated) | 3.1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDZ206PMOSFET P-CH 20V 13A 30BGA |
369,292 | 0.51 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 13A (Ta) | 2.5V, 4.5V | 9.5mOhm @ 13A, 4.5V | 1.5V @ 250µA | 53 nC @ 4.5 V | ±12V | 4280 pF @ 10 V | - | 2.2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FQD7N10TMMOSFET N-CH 100V 5.8A DPAK |
176,125 | 0.51 |
RFQ |
Datasheet |
Bulk | QFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 5.8A (Tc) | 10V | 350mOhm @ 2.9A, 10V | 4V @ 250µA | 7.5 nC @ 10 V | ±25V | 250 pF @ 25 V | - | 2.5W (Ta), 25W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDJ127PMOSFET P-CH 20V 4.1A SC75-6 FLMP |
43,465 | 0.51 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 4.1A (Ta) | 1.8V, 4.5V | 60mOhm @ 4.1A, 4.5V | 1.5V @ 250µA | 10 nC @ 4.5 V | ±8V | 780 pF @ 10 V | - | 1.6W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
HUF76113T3STN-CHANNEL POWER MOSFET |
34,318 | 0.51 |
RFQ |
Datasheet |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 4.7A (Ta) | 4.5V, 10V | 31mOhm @ 4.7A, 10V | 3V @ 250µA | 20.5 nC @ 10 V | ±20V | 625 pF @ 25 V | - | 1.1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FQD5N50TFMOSFET N-CH 500V 3.5A DPAK |
28,688 | 0.51 |
RFQ |
Datasheet |
Bulk | QFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 3.5A (Tc) | 10V | 1.8Ohm @ 1.75A, 10V | 5V @ 250µA | 17 nC @ 10 V | ±30V | 610 pF @ 25 V | - | 2.5W (Ta), 50W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FQU3N60TUMOSFET N-CH 600V 2.4A IPAK |
21,754 | 0.51 |
RFQ |
Datasheet |
Tube | QFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 2.4A (Tc) | 10V | 3.6Ohm @ 1.2A, 10V | 5V @ 250µA | 13 nC @ 10 V | ±30V | 450 pF @ 25 V | - | 2.5W (Ta), 50W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
FDD6796AMOSFET N-CH 25V 20A/40A TO252 |
749,738 | 0.52 |
RFQ |
Datasheet |
Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 25 V | 20A (Ta), 40A (Tc) | - | 5.7mOhm @ 20A, 10V | 3V @ 250µA | 34 nC @ 10 V | ±20V | 1780 pF @ 13 V | - | 3.7W (Ta), 42W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
SFR9110TFMOSFET P-CH 100V 2.8A DPAK |
122,386 | 0.52 |
RFQ |
Datasheet |
Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 100 V | 2.8A (Tc) | 10V | 1.2Ohm @ 1.4A, 10V | 4V @ 250µA | 10 nC @ 10 V | ±30V | 335 pF @ 25 V | - | 2.5W (Ta), 20W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
RFD4N06LSM9AMOSFET N-CH 60V 4A TO252AA |
67,132 | 0.52 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 4A (Tc) | 5V | 600mOhm @ 1A, 5V | 2.5V @ 250µA | 8 nC @ 10 V | ±10V | - | - | 30W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
HUF76437S3STMOSFET N-CH 60V 71A D2PAK |
27,282 | 0.52 |
RFQ |
Datasheet |
Bulk | UltraFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 71A (Tc) | 4.5V, 10V | 14mOhm @ 71A, 10V | 3V @ 250µA | 71 nC @ 10 V | ±16V | 2230 pF @ 25 V | - | 155W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
