| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FQB19N20LTMMOSFET N-CH 200V 21A D2PAK |
3,744 | 1.79 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | QFET® | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 21A (Tc) | 5V, 10V | 140mOhm @ 10.5A, 10V | 2V @ 250µA | 35 nC @ 5 V | ±20V | 2200 pF @ 25 V | - | 3.13W (Ta), 140W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDD86326MOSFET N-CH 80V 8A/37A DPAK |
3,446 | 2.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 8A (Ta), 37A (Tc) | 6V, 10V | 23mOhm @ 8A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±20V | 1035 pF @ 50 V | - | 3.1W (Ta), 62W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDMC8360LET40MOSFET N-CH 40V 27A/141A POWER33 |
3,643 | 2.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 27A (Ta), 141A (Tc) | 4.5V, 10V | 2.1mOhm @ 27A, 10V | 3V @ 250µA | 80 nC @ 10 V | ±20V | 5300 pF @ 20 V | - | 2.8W (Ta), 75W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
NTMFS6H801NT1GMOSFET N-CH 80V 23A/157A 5DFN |
2,455 | 2.11 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 23A (Ta), 157A (Tc) | 6V, 10V | 2.8mOhm @ 50A, 10V | 4V @ 250µA | 64 nC @ 10 V | ±20V | 4120 pF @ 40 V | - | 3.8W (Ta), 166W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
NTTFS2D1N04HLTWGMOSFET N-CH 40V 24A/150A 8PQFN |
2,645 | 2.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 24A (Ta), 150A (Tc) | 4.5V, 10V | 2.1mOhm @ 23A, 10V | 2V @ 120µA | 43.6 nC @ 10 V | ±20V | 2745 pF @ 20 V | - | 2.2W (Ta), 83W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDMS3500MOSFET N-CH 75V PWR CLIP 56 |
3,357 | 2.29 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 9.2A (Ta), 49A (Tc) | 4.5V, 10V | 14.5mOhm @ 11.5A, 10V | 3V @ 250µA | 91 nC @ 10 V | ±20V | 4765 pF @ 40 V | - | 2.5W (Ta), 96W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDS86141MOSFET N-CH 100V 7A 8SOIC |
3,977 | 2.31 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 7A (Ta) | 6V, 10V | 23mOhm @ 7A, 10V | 4V @ 250µA | 16.5 nC @ 10 V | ±20V | 934 pF @ 50 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDD86250-F085MOSFET N-CH 150V 50A TO252 |
2,100 | 2.36 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 50A (Tc) | 10V | 22mOhm @ 20A, 10V | 4V @ 250µA | 37 nC @ 10 V | ±20V | 1900 pF @ 75 V | - | 160W (Tj) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
NTMFS005N10MCLT1GSINGLE N-CHANNEL POWER MOSFET 10 |
3,306 | 2.30 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 16A (Ta), 105A (Tc) | 4.5V, 10V | 5.1mOhm @ 34A, 10V | 3V @ 192µA | 55 nC @ 10 V | ±20V | 4100 pF @ 50 V | - | 3W (Ta), 125W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
FDD86567-F085MOSFET N-CH 60V 100A DPAK |
2,610 | 2.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 100A (Tc) | 10V | 3.2mOhm @ 80A, 10V | 4V @ 250µA | 82 nC @ 10 V | ±20V | 4950 pF @ 30 V | - | 227W (Tj) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
FDS4470MOSFET N-CH 40V 12.5A 8SOIC |
3,300 | 2.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 12.5A (Ta) | 10V | 9mOhm @ 12.5A, 10V | 5V @ 250µA | 63 nC @ 10 V | +30V, -20V | 2659 pF @ 20 V | - | 2.5W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
FQU17P06TUMOSFET P-CH 60V 12A IPAK |
3,564 | 1.19 |
RFQ |
Datasheet |
Bulk,Tube | QFET® | Last Time Buy | P-Channel | MOSFET (Metal Oxide) | 60 V | 12A (Tc) | 10V | 135mOhm @ 6A, 10V | 4V @ 250µA | 27 nC @ 10 V | ±25V | 900 pF @ 25 V | - | 2.5W (Ta), 44W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
FQB7P20TMMOSFET P-CH 200V 7.3A D2PAK |
3,099 | 2.07 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | QFET® | Last Time Buy | P-Channel | MOSFET (Metal Oxide) | 200 V | 7.3A (Tc) | 10V | 690mOhm @ 3.65A, 10V | 5V @ 250µA | 25 nC @ 10 V | ±30V | 770 pF @ 25 V | - | 3.13W (Ta), 90W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
FDMS86201MOSFET N-CH 120V 11.6A/49A 8PQFN |
2,655 | 2.69 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 120 V | 11.6A (Ta), 49A (Tc) | 6V, 10V | 11.5mOhm @ 11.6A, 10V | 4V @ 250µA | 46 nC @ 10 V | ±20V | 2735 pF @ 60 V | - | 2.5W (Ta), 104W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
NTTFS5C453NLTAGMOSFET N-CH 40V 23A/107A 8WDFN |
3,329 | 2.77 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 23A (Ta), 107A (Tc) | 4.5V, 10V | 3mOhm @ 40A, 10V | 2V @ 250µA | 35 nC @ 10 V | ±20V | 2100 pF @ 25 V | - | 3.3W (Ta), 68W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
FDB28N30TMMOSFET N-CH 300V 28A D2PAK |
16,000 | 2.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | UniFET™ | Active | N-Channel | MOSFET (Metal Oxide) | 300 V | 28A (Tc) | 10V | 129mOhm @ 14A, 10V | 5V @ 250µA | 50 nC @ 10 V | ±30V | 2250 pF @ 25 V | - | 250W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS5C682NLT1GMOSFET N-CH 60V 25A 5DFN |
2,468 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 25A (Tc) | 4.5V, 10V | 21mOhm @ 10A, 10V | 2V @ 16µA | 5 nC @ 10 V | ±20V | 410 pF @ 25 V | - | 28W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
NTMFS5H409NLT1GMOSFET N-CH 40V 41A/270A 5DFN |
3,471 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 41A (Ta), 270A (Tc) | 4.5V, 10V | 1.1mOhm @ 50A, 10V | 2V @ 250µA | 89 nC @ 10 V | ±20V | 5700 pF @ 20 V | - | 3.2W (Ta), 140W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FQP20N06LMOSFET N-CH 60V 21A TO220-3 |
2,948 | 1.56 |
RFQ |
Datasheet |
Tube | QFET® | Last Time Buy | N-Channel | MOSFET (Metal Oxide) | 60 V | 21A (Tc) | 5V, 10V | 55mOhm @ 10.5A, 10V | 2.5V @ 250µA | 13 nC @ 5 V | ±20V | 630 pF @ 25 V | - | 53W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
FDMS10C4D2NMOSFET N-CH 100V 17A 8PQFN |
2,474 | 3.16 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 17A (Tc) | 6V, 10V | 4.2mOhm @ 44A, 10V | 4V @ 250µA | 65 nC @ 10 V | ±20V | 4500 pF @ 50 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
