| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NTLJS2103PTAGMOSFET P-CH 12V 3.5A 6WDFN |
74,162 | 0.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 12 V | 3.5A (Ta) | 1.2V, 4.5V | 40mOhm @ 3A, 4.5V | 800mV @ 250µA | 15 nC @ 4.5 V | ±8V | 1157 pF @ 6 V | - | 700mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTLJS3113PTAGMOSFET P-CH 20V 3.5A 6WDFN |
56,140 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 3.5A (Ta) | 1.5V, 4.5V | 40mOhm @ 3A, 4.5V | 1V @ 250µA | 15.7 nC @ 4.5 V | ±8V | 1329 pF @ 16 V | - | 700mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTLJS4149PTAGMOSFET P-CH 30V 2.7A 6WDFN |
27,000 | 0.30 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 2.7A (Ta) | 2.5V, 4.5V | 62mOhm @ 2A, 4.5V | 1V @ 250µA | 15 nC @ 4.5 V | ±12V | 960 pF @ 15 V | - | 700mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
NTMFS4744NT3GMOSFET N-CH 30V 7A 5DFN |
5,000 | 0.33 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 7A (Ta) | 4.5V, 11.5V | 7.6mOhm @ 30A, 10V | 2.5V @ 250µA | 17 nC @ 4.5 V | ±20V | 1300 pF @ 12 V | - | 880mW (Ta), 47.2W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4834NT3GMOSFET N-CH 30V 13A/130A 5DFN |
2,614 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta), 130A (Tc) | 4.5V, 11.5V | 3mOhm @ 30A, 10V | 2.5V @ 250µA | 48 nC @ 4.5 V | ±20V | 4500 pF @ 12 V | - | 900mW (Ta), 86.2W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4835NT3GMOSFET N-CH 30V 13A/130A 5DFN |
325,000 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta), 130A (Tc) | 4.5V, 11.5V | 3.5mOhm @ 30A, 10V | 2.5V @ 250µA | 52 nC @ 11.5 V | ±20V | 3100 pF @ 12 V | - | 890mW (Ta), 62.5W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4836NT3GMOSFET N-CH 30V 11A/90A 5DFN |
2,732 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 11A (Ta), 90A (Tc) | 4.5V, 11.5V | 4mOhm @ 30A, 10V | 2.5V @ 250µA | 28 nC @ 4.5 V | ±20V | 2677 pF @ 12 V | - | 890mW (Ta), 55.6W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4837NHT3GMOSFET N-CH 30V 10.2A/75A 5DFN |
3,818 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 10.2A (Ta), 75A (Tc) | 4.5V, 11.5V | 5mOhm @ 30A, 10V | 2.5V @ 250µA | 23.8 nC @ 4.5 V | ±20V | 3016 pF @ 12 V | - | 880mW (Ta), 48W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4837NT3GMOSFET N-CH 30V 10A/74A 5DFN |
2,896 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta), 74A (Tc) | 4.5V, 11.5V | 5mOhm @ 30A, 10V | 2.5V @ 250µA | 22 nC @ 4.5 V | ±20V | 2048 pF @ 12 V | - | 880mW (Ta), 47.2W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4839NHT3GMOSFET N-CH 30V 9.5A/64A 5DFN |
5,000 | 0.31 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 9.5A (Ta), 64A (Tc) | 4.5V, 11.5V | 5.5mOhm @ 30A, 10V | 2.5V @ 250µA | 43.5 nC @ 11.5 V | ±20V | 2354 pF @ 12 V | - | 870mW (Ta), 42.4W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4839NT1GMOSFET N-CH 30V 9.5A/64A 5DFN |
268,110 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 9.5A (Ta), 64A (Tc) | 4.5V, 11.5V | 5.5mOhm @ 30A, 10V | 2.5V @ 250µA | 18 nC @ 4.5 V | ±20V | 1588 pF @ 12 V | - | 870mW (Ta), 41.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4839NT3GMOSFET N-CH 30V 9.5A/64A 5DFN |
3,024 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 9.5A (Ta), 64A (Tc) | 4.5V, 11.5V | 5.5mOhm @ 30A, 10V | 2.5V @ 250µA | 18 nC @ 4.5 V | ±20V | 1588 pF @ 12 V | - | 870mW (Ta), 41.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4841NHT3GMOSFET N-CH 30V 8.6A/59A 5DFN |
2,434 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 8.6A (Ta), 59A (Tc) | 4.5V, 10V | 7mOhm @ 30A, 10V | 2.5V @ 250µA | 33 nC @ 11.5 V | ±20V | 2113 pF @ 12 V | - | 870mW (Ta), 41.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
NTMFS4841NT3GMOSFET N-CH 30V 8.3A/57A 5DFN |
3,098 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 8.3A (Ta), 57A (Tc) | 4.5V, 10V | 7mOhm @ 30A, 10V | 2.5V @ 250µA | 17 nC @ 4.5 V | ±20V | 1436 pF @ 12 V | - | 870mW (Ta), 41.7W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDP5N50MOSFET N-CH 500V 5A TO220-3 |
3,442 | 0.00 |
RFQ |
Datasheet |
Tube | UniFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 5A (Tc) | 10V | 1.4Ohm @ 2.5A, 10V | 5V @ 250µA | 15 nC @ 10 V | ±30V | 640 pF @ 25 V | - | 85W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
FDC636PMOSFET P-CH 20V 2.8A SUPERSOT6 |
3,231 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 2.8A (Ta) | 2.5V, 4.5V | 130mOhm @ 2.8A, 4.5V | 1V @ 250µA | 8.5 nC @ 4.5 V | ±8V | 390 pF @ 10 V | - | 1.6W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDS6294MOSFET N-CH 30V 13A 8SOIC |
2,828 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | 4.5V, 10V | 11.3mOhm @ 13A, 10V | 3V @ 250µA | 14 nC @ 5 V | ±20V | 1205 pF @ 15 V | - | 3W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
FDS6630AMOSFET N-CH 30V 6.5A 8SOIC |
2,447 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 6.5A (Ta) | 4.5V, 10V | 38mOhm @ 6.5A, 10V | 3V @ 250µA | 7 nC @ 5 V | ±20V | 460 pF @ 15 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDT434PMOSFET P-CH 20V 6A SOT223-4 |
3,751 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | PowerTrench® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 6A (Ta) | 2.5V, 4.5V | 50mOhm @ 6A, 4.5V | 1V @ 250µA | 19 nC @ 4.5 V | ±8V | 1187 pF @ 10 V | - | 3W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
FDZ294NMOSFET N-CH 20V 6A 9BGA |
3,413 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | PowerTrench® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 6A (Ta) | 2.5V, 4.5V | 23mOhm @ 6A, 4.5V | 1.5V @ 250µA | 10 nC @ 4.5 V | ±12V | 670 pF @ 10 V | - | 1.7W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
