| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2SK3466(TE24L,Q)MOSFET N-CH 500V 5A 4TFP |
2,376 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 5A (Ta) | 10V | 1.5Ohm @ 5A, 10V | 4V @ 1mA | 17 nC @ 10 V | ±30V | 780 pF @ 10 V | - | 50W (Tc) | 150°C (TJ) | Surface Mount |
|
2SK3662(F)MOSFET N-CH 60V 35A TO220NIS |
3,016 | 0.00 |
RFQ |
Datasheet |
Bulk | U-MOSIII | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 35A (Ta) | 4V, 10V | 12.5mOhm @ 18A, 10V | 2.5V @ 1mA | 91 nC @ 10 V | ±20V | 5120 pF @ 10 V | - | 35W (Tc) | 150°C (TJ) | Through Hole |
|
|
2SK3844(Q)MOSFET N-CH 60V 45A TO220NIS |
3,951 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Ta) | 10V | 5.8mOhm @ 23A, 10V | 4V @ 1mA | 196 nC @ 10 V | ±20V | 12400 pF @ 10 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
2SK3868(Q,M)MOSFET N-CH 500V 5A TO220SIS |
2,709 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 5A (Ta) | 10V | 1.7Ohm @ 2.5A, 10V | 4V @ 1mA | 16 nC @ 10 V | ±30V | 550 pF @ 25 V | - | 35W (Tc) | 150°C (TJ) | Through Hole |
|
2SK3906(Q)MOSFET N-CH 600V 20A TO3P |
3,691 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 20A (Ta) | 10V | 330mOhm @ 10A, 10V | 4V @ 1mA | 60 nC @ 10 V | ±30V | 4250 pF @ 25 V | - | 150W (Tc) | 150°C (TJ) | Through Hole |
|
|
2SK4016(Q)MOSFET N-CH 600V 13A TO220SIS |
2,328 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Ta) | 10V | 500mOhm @ 6.5A, 10V | 4V @ 1mA | 62 nC @ 10 V | ±30V | 3100 pF @ 25 V | - | 50W (Tc) | 150°C (TJ) | Through Hole |
|
2SK4017(Q)MOSFET N-CH 60V 5A PW-MOLD2 |
2,567 | 0.00 |
RFQ |
Datasheet |
Bulk | U-MOSIII | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 5A (Ta) | 4V, 10V | 100mOhm @ 2.5A, 10V | 2.5V @ 1mA | 15 nC @ 10 V | ±20V | 730 pF @ 10 V | - | 20W (Tc) | 150°C (TJ) | Through Hole |
|
|
2SK4021(Q)MOSFET N-CH 250V 4.5A PW-MOLD2 |
3,850 | 0.00 |
RFQ |
Datasheet |
Bulk | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 250 V | 4.5A (Ta) | 10V | 1Ohm @ 2.5A, 10V | 3.5V @ 1mA | 10 nC @ 10 V | ±20V | 440 pF @ 10 V | - | 20W (Tc) | 150°C (TJ) | Through Hole |
|
TPC8026(TE12L,Q,M)MOSFET N-CH 30V 13A 8SOP |
3,550 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 13A (Ta) | 4.5V, 10V | 6.6mOhm @ 6.5A, 10V | 2.5V @ 1mA | 42 nC @ 10 V | ±20V | 1800 pF @ 10 V | - | 1W (Ta) | 150°C (TJ) | Surface Mount |
|
|
TPC8036-H(TE12L,QMMOSFET N-CH 30V 18A 8SOP |
2,201 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSVI-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A (Ta) | 4.5V, 10V | 4.5mOhm @ 9A, 10V | 2.3V @ 1mA | 49 nC @ 10 V | ±20V | 4600 pF @ 10 V | - | 1W (Ta) | 150°C (TJ) | Surface Mount |
|
|
TPCA8025(TE12L,Q,MMOSFET N-CH 30V 40A 8SOP |
2,356 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSIV | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 40A (Ta) | 4.5V, 10V | 3.5mOhm @ 20A, 10V | 2.5V @ 1mA | 49 nC @ 10 V | ±20V | 2200 pF @ 10 V | - | 1.6W (Ta), 45W (Tc) | 150°C (TJ) | Surface Mount |
|
|
TPCA8036-H(TE12L,QMOSFET N-CH 30V 38A 8SOP |
3,176 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSVI-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 38A (Ta) | 4.5V, 10V | 4.2mOhm @ 19A, 10V | 2.3V @ 500µA | 50 nC @ 10 V | ±20V | 4600 pF @ 10 V | - | 1.6W (Ta), 45W (Tc) | 150°C (TJ) | Surface Mount |
|
|
TPCA8A02-H(TE12LQMMOSFET N-CH 30V 34A 8SOP |
2,812 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSV-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 34A (Ta) | 4.5V, 10V | 5.3mOhm @ 17A, 10V | 2.3V @ 1mA | 36 nC @ 10 V | ±20V | 3430 pF @ 10 V | - | 1.6W (Ta), 45W (Tc) | 150°C (TJ) | Surface Mount |
|
|
TPCA8A04-H(TE12L,QMOSFET N-CH 30V 44A 8SOP |
2,532 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSV-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 44A (Ta) | 4.5V, 10V | 3.2mOhm @ 22A, 10V | 2.3V @ 1mA | 59 nC @ 10 V | ±20V | 5700 pF @ 10 V | - | - | 150°C (TJ) | Surface Mount |
|
|
TPCP8003-H(TE85L,FMOSFET N-CH 100V 2.2A PS-8 |
2,223 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | U-MOSIII-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 2.2A (Ta) | 4.5V, 10V | 180mOhm @ 1.1A, 10V | 2.3V @ 1mA | 7.5 nC @ 10 V | ±20V | 360 pF @ 10 V | - | 840mW (Ta) | 150°C (TJ) | Surface Mount |
|
|
TK10A60D(STA4,Q,M)MOSFET N-CH 600V 10A TO220SIS |
2,762 | 0.00 |
RFQ |
Datasheet |
Tube | π-MOSVII | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 10A (Ta) | 10V | 750mOhm @ 5A, 10V | 4V @ 1mA | 25 nC @ 10 V | ±30V | 1350 pF @ 25 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK13A60D(STA4,Q,M)MOSFET N-CH 600V 13A TO220SIS |
3,401 | 0.00 |
RFQ |
Datasheet |
Tube | π-MOSVII | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 13A (Ta) | 10V | 430mOhm @ 6.5A, 10V | 4V @ 1mA | 40 nC @ 10 V | ±30V | 2300 pF @ 25 V | - | 50W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK6A60D(STA4,Q,M)MOSFET N-CH 600V 6A TO220SIS |
2,716 | 0.00 |
RFQ |
Datasheet |
Tube | π-MOSVII | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 6A (Ta) | 10V | 1.25Ohm @ 3A, 10V | 4V @ 1mA | 16 nC @ 10 V | ±30V | 800 pF @ 25 V | - | 40W (Tc) | 150°C (TJ) | Through Hole |
|
|
TK72A08N1,S4XMOSFET N-CH 75V 80A TO220SIS |
3,378 | 0.00 |
RFQ |
Datasheet |
Bulk | U-MOSVIII-H | Obsolete | N-Channel | MOSFET (Metal Oxide) | 75 V | 80A (Ta) | 10V | 4.5mOhm @ 40A, 10V | 4V @ 1mA | 175 nC @ 10 V | ±20V | 8200 pF @ 10 V | - | 45W (Tc) | 150°C (TJ) | Through Hole |
|
TPC6111(TE85L,F,M)MOSFET P-CH 20V 5.5A VS-6 |
2,744 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | U-MOSV | Obsolete | P-Channel | MOSFET (Metal Oxide) | 20 V | 5.5A (Ta) | 1.5V, 4.5V | 40mOhm @ 2.8A, 4.5V | 1V @ 1mA | 10 nC @ 5 V | ±8V | 700 pF @ 10 V | - | 700mW (Ta) | 150°C (TJ) | Surface Mount |
