| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
STU16N60M2MOSFET N-CH 600V 12A IPAK |
2,190 | 0.00 |
RFQ |
Datasheet |
Tube | MDmesh™ M2 | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 12A (Tc) | 10V | 320mOhm @ 6A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±25V | 700 pF @ 100 V | - | 110W (Tc) | 150°C (TJ) | Through Hole |
|
STFU15N80K5MOSFET N-CH 800V 14A TO220FP |
3,207 | 0.00 |
RFQ |
Datasheet |
Tube | MDmesh™ K5 | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 14A (Tc) | 10V | 375mOhm @ 7A, 10V | 5V @ 100µA | 32 nC @ 10 V | ±30V | 1100 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
STW37N60DM2AGMOSFET N-CH 600V 28A TO247 |
3,920 | 0.00 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101, MDmesh™ DM2 | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 28A (Tc) | 10V | 110mOhm @ 14A, 10V | 5V @ 250µA | 54 nC @ 10 V | ±25V | 2400 pF @ 100 V | - | 210W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
STF33N60DM2MOSFET N-CH 650V 24A TO220FP |
2,847 | 0.00 |
RFQ |
Tube | MDmesh™ DM2 | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 24A (Tc) | 10V | 130mOhm @ 12A, 10V | 5V @ 250µA | 43 nC @ 10 V | ±25V | 1870 pF @ 100 V | - | 35W (Tc) | -55°C ~ 150°C (TJ) | Through Hole | |
|
|
STW48N60DM2MOSFET N-CH 600V 40A TO247 |
3,844 | 0.00 |
RFQ |
Datasheet |
Tube | MDmesh™ DM2 | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 40A (Tc) | 10V | 79mOhm @ 20A, 10V | 5V @ 250µA | 70 nC @ 10 V | ±25V | 3250 pF @ 100 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
STF7LN80K5MOSFET N-CH 800V 5A TO220FP |
3,566 | 0.00 |
RFQ |
Datasheet |
Tube | MDmesh™ | Active | N-Channel | MOSFET (Metal Oxide) | 800 V | 5A (Tc) | 10V | 1.15Ohm @ 2.5A, 10V | 5V @ 100µA | 12 nC @ 10 V | ±30V | 270 pF @ 100 V | - | 25W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
;;2.jpg)
|
STD46N6F7MOSFET N-CH 60V 15A DPAK |
2,894 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | STripFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 15A (Tc) | 10V | 14mOhm @ 7.5A, 10V | 4V @ 250µA | 17 nC @ 10 V | ±20V | 1065 pF @ 30 V | - | 60W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
STL11N6F7MOSFET N-CH 60V 11A POWERFLAT |
3,771 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | STripFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 11A (Ta) | 10V | 12mOhm @ 5.5A, 10V | 4V @ 250µA | 17 nC @ 10 V | ±20V | 1035 pF @ 30 V | - | 2.9W (Ta), 48W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
STL120N4LF6AGMOSFET N-CH 40V 120A POWERFLAT |
2,175 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, STripFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 120A (Tc) | 5V, 10V | 3.6mOhm @ 13A, 10V | 3V @ 250µA | 80 nC @ 10 V | ±20V | 4260 pF @ 25 V | - | 96W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
STD28P3LLH6AGMOSFET P-CH 30V 12A DPAK |
3,780 | 1.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, STripFET™ H6 | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 12A (Tc) | 4.5V, 10V | 30mOhm @ 6A, 10V | 2.5V @ 250µA | 29 nC @ 10 V | ±18V | 1480 pF @ 25 V | - | 33W (Tc) | 150°C (TJ) | Surface Mount |
|
|
STD19N3LLH6AGMOSFET N-CH 30V 10A DPAK |
2,933 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, STripFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Tc) | 4.5V, 10V | 33mOhm @ 5A, 10V | 2.5V @ 250µA | 3.7 nC @ 4.5 V | ±20V | 321 pF @ 25 V | - | 30W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
STD20P3H6AGMOSFET P-CH 30V 20A DPAK |
3,710 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101, STripFET™ F6 | Active | P-Channel | MOSFET (Metal Oxide) | 30 V | 20A (Tc) | 10V | 50mOhm @ 10A, 10V | 4V @ 250µA | 12.8 nC @ 10 V | ±20V | 635 pF @ 25 V | - | 40W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
STD40P3LLH6MOSFET P-CH 30V 40A DPAK |
3,022 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | STripFET™ H6 | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 40A (Tc) | 4.5V, 10V | 15mOhm @ 20A, 10V | 2.5V @ 250µA | 24 nC @ 4.5 V | ±20V | 2615 pF @ 25 V | - | 60W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
STL12HN65M2MOSFET POWERFLAT HV |
3,983 | 0.00 |
RFQ |
Tape & Reel (TR) | * | Active | - | - | - | 6A (Tc) | - | - | - | - | - | - | - | - | - | Surface Mount | |
|
|
STL20NF06LAGMOSFET N-CH 60V 20A POWERFLAT |
2,847 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101, STripFET™ II | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 20A (Tc) | 5V, 10V | 40mOhm @ 4A, 10V | 2.5V @ 250µA | 22.5 nC @ 10 V | ±20V | 670 pF @ 25 V | - | 4.8W (Ta), 75W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
STS9P3LLH6MOSFET P-CH 30V 9A 8SO |
2,288 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | STripFET™ H6 | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 9A (Ta) | 4.5V, 10V | 15mOhm @ 4.5A, 10V | 2V @ 250µA | 24 nC @ 4.5 V | ±20V | 2615 pF @ 25 V | - | 2.7W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
STE139N65M5MOSFET N-CH 650V 130A ISOTOP |
3,461 | 0.00 |
RFQ |
Datasheet |
Tube | MDmesh™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 650 V | 130A (Tc) | 10V | 17mOhm @ 65A, 10V | 5V @ 250µA | 363 nC @ 10 V | ±25V | 15600 pF @ 100 V | - | 672W (Tc) | 150°C (TJ) | Chassis Mount |
|
|
STD11N60M2-EPMOSFET N-CH 600V 7.5A DPAK |
2,829 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | MDmesh™ M2-EP | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 7.5A (Tc) | 10V | 595mOhm @ 3.75A, 10V | 4.75V @ 250µA | 12.4 nC @ 10 V | ±25V | 390 pF @ 100 V | - | 85W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
STH140N6F7-6MOSFET N-CH 60V 80A H2PAK-6 |
3,933 | 0.00 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | STripFET™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 80A (Tc) | 10V | 3.2mOhm @ 40A, 10V | 4V @ 250µA | 55 nC @ 10 V | ±20V | 3100 pF @ 25 V | - | 158W (Tc) | 175°C (TJ) | Surface Mount | |
|
STH110N7F6-2MOSFET N-CH 68V 80A H2PAK-2 |
2,480 | 0.00 |
RFQ |
Tape & Reel (TR) | STripFET™ F6 | Active | N-Channel | MOSFET (Metal Oxide) | 68 V | 80A (Tc) | 10V | 6.3mOhm @ 55A, 10V | 4V @ 250µA | 100 nC @ 10 V | ±20V | 5850 pF @ 25 V | - | 176W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
