| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IPB100N04S2-04IPB100N04 - 20V-40V N-CHANNEL AU |
499 | 1.98 |
RFQ |
Datasheet |
Bulk | * | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 10V | 3.3mOhm @ 80A, 10V | 4V @ 250µA | 172 nC @ 10 V | ±20V | 5300 pF @ 25 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SPW16N50C3SPW16N50 - 500V COOLMOS N-CHANNE |
270 | 2.13 |
RFQ |
Datasheet |
Bulk | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 16A (Tc) | 10V | 280mOhm @ 10A, 10V | 3.9V @ 675µA | 66 nC @ 10 V | ±20V | 1600 pF @ 25 V | - | 160W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IPB011N04LGATMA1MOSFET N-CH 40V 180A TO263-7 |
2,592 | 6.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 180A (Tc) | 4.5V, 10V | 1.1mOhm @ 100A, 10V | 2V @ 200µA | 346 nC @ 10 V | ±20V | 29000 pF @ 20 V | - | 250W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
AUIRFS8409AUIRFS8409 - 20V-40V N-CHANNEL A |
286 | 2.26 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 195A (Tc) | 10V | 1.2mOhm @ 100A, 10V | 3.9V @ 250µA | 450 nC @ 10 V | ±20V | 14240 pF @ 25 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SPA21N50C3XKSA1HIGH POWER_LEGACY |
747 | 2.37 |
RFQ |
Datasheet |
Bulk | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 560 V | 21A (Tc) | 10V | 190mOhm @ 13.1A, 10V | 3.9V @ 1mA | 95 nC @ 10 V | ±20V | 2400 pF @ 25 V | - | 34.5W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
AUIRFP1405AUIRFP1405 - 55V-60V N-CHANNEL A |
800 | 2.38 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 55 V | 95A (Tc) | 10V | 5.3mOhm @ 95A, 10V | 4V @ 250µA | 180 nC @ 10 V | ±20V | 5600 pF @ 25 V | - | 310W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
AUIRF1324STRLAUIRF1324 - 20V-40V N-CHANNEL AU |
466 | 2.52 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 24 V | 195A (Tc) | 10V | 1.65mOhm @ 195A, 10V | 4V @ 250µA | 240 nC @ 10 V | ±20V | 7590 pF @ 24 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRFH5053TRPBFMOSFET N-CH 100V 9.3A/46A PQFN |
205 | 2.54 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 9.3A (Ta), 46A (Tc) | 10V | 18mOhm @ 9.3A, 10V | 4.9V @ 100µA | 36 nC @ 10 V | ±20V | 1510 pF @ 50 V | - | 3.1W (Ta), 8.3W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF6643TRPBFMOSFET N-CH 150V 6.2A DIRECTFET |
14,762 | 2.57 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 6.2A (Ta), 35A (Tc) | 10V | 34.5mOhm @ 7.6A, 10V | 4.9V @ 150µA | 55 nC @ 10 V | ±20V | 2340 pF @ 25 V | - | 2.8W (Ta), 89W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
AUIRFS3206TRLAUIRFS3206 - 55V-60V N-CHANNEL A |
139 | 2.67 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 120A (Tc) | 10V | 3mOhm @ 75A, 10V | 4V @ 150µA | 170 nC @ 10 V | ±20V | 6540 pF @ 50 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPA65R125C7IPA65R125 - 650V AND 700V COOLMO |
412 | 2.71 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
IPP65R125C7IPP65R125 - 650V AND 700V COOLMO |
143 | 2.71 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
AUIRFS4115-7TRLMOSFET_(120V,300V) |
662 | 2.81 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 105A (Tc) | 10V | 11.8mOhm @ 63A, 10V | 5V @ 250µA | 110 nC @ 10 V | ±20V | 5320 pF @ 50 V | - | 380W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
AUIRF1404STRLMOSFET_(20V,40V) |
800 | 3.10 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 75A (Tc) | 10V | 4mOhm @ 95A, 10V | 4V @ 250µA | 200 nC @ 10 V | ±20V | 7360 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
SPA20N65C3XKSPA20N65 - 650V AND 700V COOLMOS |
165 | 3.32 |
RFQ |
Datasheet |
Bulk | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 20.7A (Tc) | 10V | 190mOhm @ 13.1A, 10V | 3.9V @ 1mA | 114 nC @ 10 V | ±20V | 2400 pF @ 25 V | - | 34.5W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IAUA250N04S6N007AUMA1MOSFET_(20V 40V) PG-HSOF-5 |
2,769 | 3.73 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 40 V | 435A (Tj) | 7V, 10V | 0.7mOhm @ 100A, 10V | 3V @ 130µA | 151 nC @ 10 V | ±20V | 9898 pF @ 25 V | - | 250W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPZ65R095C7IPZ65R095 - 650V AND 700V COOLMO |
410 | 4.25 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
AUIRFP2907AUIRFP2907 - 75V-100V N-CHANNEL |
450 | 4.35 |
RFQ |
Datasheet |
Bulk | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 90A (Tc) | 10V | 4.5mOhm @ 125A, 10V | 4V @ 250µA | 620 nC @ 10 V | ±20V | 13000 pF @ 25 V | - | 470W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
SPB11N60C3ATMA1MOSFET N-CH 650V 11A TO263-3 |
2,029 | 4.59 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ | Not For New Designs | N-Channel | MOSFET (Metal Oxide) | 650 V | 11A (Tc) | 10V | 380mOhm @ 7A, 10V | 3.9V @ 500µA | 60 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
BSS138NH6327XTSA2MOSFET N-CH 60V 230MA SOT23-3 |
3,863 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 230mA (Ta) | 4.5V, 10V | 3.5Ohm @ 230mA, 10V | 1.4V @ 26µA | 1.4 nC @ 10 V | ±20V | 41 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
