| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BSP296NH6327XTSA1MOSFET N-CH 100V 1.2A SOT223-4 |
1,407 | 1.08 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 1.2A (Ta) | 4.5V, 10V | 600mOhm @ 1.2A, 10V | 1.8V @ 100µA | 6.7 nC @ 10 V | ±20V | 152.7 pF @ 25 V | - | 1.8W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IPD50N04S408ATMA1MOSFET N-CH 40V 50A TO252-3 |
421 | 1.09 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 50A (Tc) | 10V | 7.9mOhm @ 50A, 10V | 4V @ 17µA | 22.4 nC @ 10 V | ±20V | 1780 pF @ 6 V | - | 46W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
ISC019N03L5SATMA1MOSFET N-CH 30V 28A/100A TDSON |
6,585 | 1.11 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 28A (Ta), 100A (Tc) | 4.5V, 10V | 1.9mOhm @ 30A, 10V | 2V @ 250µA | 44 nC @ 10 V | ±20V | 2800 pF @ 15 V | - | 2.5W (Ta), 69W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IAUC100N04S6L025ATMA1IAUC100N04S6L025ATMA1 |
1,410 | 1.12 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 100A (Tc) | 4.5V, 10V | 2.56mOhm @ 50A, 10V | 2V @ 24µA | 34 nC @ 10 V | ±16V | 2019 pF @ 25 V | - | 62W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
BSF024N03LT3GXUMA1MOSFET N-CH 30V 15A/106A 2WDSON |
5,000 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 15A (Ta), 106A (Tc) | 4.5V, 10V | 2.4mOhm @ 20A, 10V | 2.2V @ 250µA | 71 nC @ 10 V | ±20V | 5500 pF @ 15 V | - | 2.2W (Ta), 42W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IPD50R500CEAUMA1MOSFET N-CH 550V 7.6A TO252 |
1,344 | 1.15 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 550 V | 7.6A (Tc) | 13V | 500mOhm @ 2.3A, 13V | 3.5V @ 200µA | 18.7 nC @ 10 V | ±20V | 433 pF @ 100 V | - | 57W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
IRF7403TRPBFMOSFET N-CH 30V 8.5A 8SO |
2,925 | 1.16 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 8.5A (Ta) | 4.5V, 10V | 22mOhm @ 4A, 10V | 1V @ 250µA | 57 nC @ 10 V | ±20V | 1200 pF @ 25 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
BSC026N02KSGBSC026N02 - 12V-300V N-CHANNEL P |
38,580 | 0.76 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
IPDH4N03LAGMOSFET N-CH 25V 90A TO252-3 |
2,390 | 1.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 25 V | 90A (Tc) | 4.5V, 10V | 4.2mOhm @ 60A, 10V | 2V @ 40µA | 26 nC @ 5 V | ±20V | 3200 pF @ 15 V | - | 94W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRLR120NTRLPBFMOSFET N-CH 100V 10A DPAK |
2,168 | 1.18 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 10A (Tc) | 4V, 10V | 185mOhm @ 6A, 10V | 2V @ 250µA | 20 nC @ 5 V | ±16V | 440 pF @ 25 V | - | 48W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPI45N06S4-09AKSA2IPI45N06 - 55V-60V N-CHANNEL AUT |
97,500 | 0.77 |
RFQ |
Datasheet |
Bulk | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Tc) | 10V | 9.4mOhm @ 45A, 10V | 4V @ 34µA | 47 nC @ 10 V | ±20V | 3785 pF @ 25 V | - | 71W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
IRF9Z24NSTRLPBFMOSFET P-CH 55V 12A D2PAK |
1,540 | 1.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Last Time Buy | P-Channel | MOSFET (Metal Oxide) | 55 V | 12A (Tc) | 10V | 175mOhm @ 7.2A, 10V | 4V @ 250µA | 19 nC @ 10 V | ±20V | 350 pF @ 25 V | - | 3.8W (Ta), 45W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IPD65R650CEAUMA1MOSFET N-CH 650V 7A TO252-3 |
2,499 | 1.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ CE | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 7A (Tc) | 10V | 650mOhm @ 2.1A, 10V | 3.5V @ 210µA | 23 nC @ 10 V | ±20V | 440 pF @ 100 V | - | 86W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IPD04N03LB GMOSFET N-CH 30V 50A TO252-3 |
1,144 | 1.27 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 50A (Tc) | 4.5V, 10V | 4.1mOhm @ 50A, 10V | 2V @ 70µA | 40 nC @ 5 V | ±20V | 5200 pF @ 15 V | - | 115W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IPN70R360P7SATMA1MOSFET N-CH 700V 12.5A SOT223 |
2,998 | 1.30 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ P7 | Active | N-Channel | MOSFET (Metal Oxide) | 700 V | 12.5A (Tc) | 10V | 360mOhm @ 3A, 10V | 3.5V @ 150µA | 16.4 nC @ 10 V | ±16V | 517 pF @ 400 V | - | 7.2W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
SPP08N50C3XKSA1SPP08N50 - 800V COOLMOS N-CHANNE |
22,195 | 0.85 |
RFQ |
Datasheet |
Bulk | CoolMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 560 V | 7.6A (Tc) | 10V | 600mOhm @ 4.6A, 10V | 3.9V @ 350µA | 32 nC @ 10 V | ±20V | 750 pF @ 25 V | - | 83W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
BSZ110N08NS5ATMA1MOSFET N-CH 80V 40A TSDSON |
2,709 | 1.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | OptiMOS™ | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 40A (Tc) | 6V, 10V | 11mOhm @ 20A, 10V | 3.8V @ 22µA | 18.5 nC @ 10 V | ±20V | 1300 pF @ 40 V | - | 50W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRF7420TRPBFMOSFET P-CH 12V 11.5A 8SO |
2,622 | 1.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Last Time Buy | P-Channel | MOSFET (Metal Oxide) | 12 V | 11.5A (Tc) | 1.8V, 4.5V | 14mOhm @ 11.5A, 4.5V | 900mV @ 250µA | 38 nC @ 4.5 V | ±8V | 3529 pF @ 10 V | - | 2.5W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IPD70R360P7SAUMA1MOSFET N-CH 700V 12.5A TO252-3 |
1,010 | 1.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | CoolMOS™ P7 | Active | N-Channel | MOSFET (Metal Oxide) | 700 V | 12.5A (Tc) | 10V | 360mOhm @ 3A, 10V | 3.5V @ 150µA | 16.4 nC @ 10 V | ±16V | 517 pF @ 400 V | - | 59.4W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFR540ZTRLPBFMOSFET N-CH 100V 35A DPAK |
640 | 1.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 35A (Tc) | 10V | 28.5mOhm @ 21A, 10V | 4V @ 50µA | 59 nC @ 10 V | ±20V | 1690 pF @ 25 V | - | 91W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
