| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IXFA16N50P-TRLMOSFET N-CH 500V 16A TO263 |
3,101 | 3.20 |
RFQ |
Tape & Reel (TR) | HiPerFET™, Polar | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 16A (Tc) | 10V | 400mOhm @ 8A, 10V | 5.5V @ 2.5mA | 36 nC @ 10 V | ±30V | 2480 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXFA14N60P-TRLMOSFET N-CH 600V 14A TO263 |
3,237 | 3.20 |
RFQ |
Tape & Reel (TR) | HiPerFET™, Polar | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 14A (Tc) | 10V | 550mOhm @ 7A, 10V | 5.5V @ 2.5mA | 36 nC @ 10 V | ±30V | 2500 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
IXTP230N04T4MOSFET N-CH 40V 230A TO220AB |
3,149 | 3.24 |
RFQ |
Datasheet |
Tube | Trench | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 230A (Tc) | 10V | 2.9mOhm @ 115A, 10V | 4V @ 250µA | 140 nC @ 10 V | ±15V | 7400 pF @ 25 V | - | 340W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXTA130N10T-TRLMOSFET N-CH 100V 130A TO263 |
2,883 | 3.24 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Trench | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 130A (Tc) | 10V | 9.1mOhm @ 25A, 10V | 4.5V @ 250µA | 104 nC @ 10 V | ±30V | 5080 pF @ 25 V | - | 360W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IXTA1N120P-TRLMOSFET N-CH 1200V 1A TO263 |
3,547 | 3.25 |
RFQ |
Tape & Reel (TR) | Polar | Active | N-Channel | MOSFET (Metal Oxide) | 1200 V | 1A (Tc) | 10V | 20Ohm @ 500mA, 10V | 4.5V @ 50µA | 17.6 nC @ 10 V | ±20V | 550 pF @ 25 V | - | 63W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXTA102N15T-TRLMOSFET N-CH 150V 102A TO263 |
2,414 | 3.25 |
RFQ |
Tape & Reel (TR) | Trench | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 102A (Tc) | 10V | 18mOhm @ 51A, 10V | 5V @ 1mA | 87 nC @ 10 V | ±20V | 5220 pF @ 25 V | - | 455W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
IXFP8N85XMOSFET N-CH 850V 8A TO220AB |
3,238 | 3.28 |
RFQ |
Datasheet |
Tube | HiPerFET™, Ultra X | Active | N-Channel | MOSFET (Metal Oxide) | 850 V | 8A (Tc) | 10V | 850mOhm @ 4A, 10V | 5.5V @ 250µA | 17 nC @ 10 V | ±30V | 654 pF @ 25 V | - | 200W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXFA44N25X3MOSFET N-CH 250V 44A TO263 |
3,551 | 4.39 |
RFQ |
Tube | HiPerFET™, Ultra X3 | Active | N-Channel | MOSFET (Metal Oxide) | 250 V | 44A (Tc) | 10V | 40mOhm @ 22A, 10V | 4.5V @ 1mA | 33 nC @ 10 V | ±20V | 2200 pF @ 25 V | - | 240W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXFA50N20X3MOSFET N-CH 200V 50A TO263 |
3,689 | 4.39 |
RFQ |
Tube | HiPerFET™, Ultra X3 | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 50A (Tc) | 10V | 30mOhm @ 25A, 10V | 4.5V @ 1mA | 33 nC @ 10 V | ±20V | 2100 pF @ 25 V | - | 240W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXFA7N100P-TRLMOSFET N-CH 1000V 7A TO263 |
3,883 | 4.40 |
RFQ |
Tape & Reel (TR) | HiPerFET™, Polar | Active | N-Channel | MOSFET (Metal Oxide) | 1000 V | 7A (Tc) | 10V | 1.9Ohm @ 3.5A, 10V | 6V @ 1mA | 47 nC @ 10 V | ±30V | 2590 pF @ 25 V | - | 300W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXTP10N60PMOSFET N-CH 600V 10A TO220AB |
2,581 | 3.31 |
RFQ |
Datasheet |
Tube | Polar | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 10A (Tc) | 10V | 740mOhm @ 5A, 10V | 5.5V @ 250µA | 32 nC @ 10 V | ±30V | 1610 pF @ 25 V | - | 200W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IXTP8N70X2MMOSFET N-CH 700V 4A TO220 |
3,830 | 3.33 |
RFQ |
Datasheet |
Tube | Ultra X2 | Active | N-Channel | MOSFET (Metal Oxide) | 700 V | 4A (Tc) | 10V | 550mOhm @ 500mA, 10V | 5V @ 250µA | 12 nC @ 10 V | ±30V | 800 pF @ 10 V | - | 32W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXTA3N100PMOSFET N-CH 1000V 3A TO263 |
2,507 | 3.34 |
RFQ |
Datasheet |
Tube | Polar | Active | N-Channel | MOSFET (Metal Oxide) | 1000 V | 3A (Tc) | 10V | 4.8Ohm @ 1.5A, 10V | 4.5V @ 250µA | 39 nC @ 10 V | ±20V | 1100 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IXTP56N15TMOSFET N-CH 150V 56A TO220AB |
2,066 | 3.34 |
RFQ |
Datasheet |
Tube | Trench | Active | N-Channel | MOSFET (Metal Oxide) | 150 V | 56A (Tc) | 10V | 36mOhm @ 28A, 10V | 4.5V @ 250µA | 34 nC @ 10 V | ±30V | 2250 pF @ 25 V | - | 300W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IXTA90N075T2MOSFET N-CH 75V 90A TO263 |
3,610 | 3.37 |
RFQ |
Datasheet |
Tube | TrenchT2™ | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 90A (Tc) | 10V | 10mOhm @ 25A, 10V | 4V @ 250µA | 54 nC @ 10 V | ±20V | 3290 pF @ 25 V | - | 180W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IXTA12N65X2MOSFET N-CH 650V 12A TO263AA |
3,797 | 3.38 |
RFQ |
Datasheet |
Tube | Ultra X2 | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 12A (Tc) | 10V | 300mOhm @ 6A, 10V | 5V @ 250µA | 17 nC @ 10 V | ±30V | 1100 pF @ 25 V | - | 180W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IXTA3N100D2HV-TRLMOSFET N-CH 1000V 3A TO263HV |
3,865 | 3.38 |
RFQ |
Tape & Reel (TR) | Depletion | Active | N-Channel | MOSFET (Metal Oxide) | 1000 V | 3A (Tj) | 0V | 6Ohm @ 1.5A, 0V | 4.5V @ 250µA | 37.5 nC @ 5 V | ±20V | 1020 pF @ 25 V | Depletion Mode | 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount | |
|
|
IXTP1N120PMOSFET N-CH 1200V 1A TO220AB |
3,260 | 3.40 |
RFQ |
Datasheet |
Tube | Polar | Active | N-Channel | MOSFET (Metal Oxide) | 1200 V | 1A (Tc) | 10V | 20Ohm @ 500mA, 10V | 4.5V @ 50µA | 17.6 nC @ 10 V | ±20V | 550 pF @ 25 V | - | 63W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
IXFA20N50P3MOSFET N-CH 500V 20A TO263 |
2,188 | 3.40 |
RFQ |
Datasheet |
Tube | HiPerFET™, Polar3™ | Active | N-Channel | MOSFET (Metal Oxide) | 500 V | 20A (Tc) | 10V | 300mOhm @ 10A, 10V | 5V @ 1.5mA | 36 nC @ 10 V | ±30V | 1800 pF @ 25 V | - | 380W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IXFA130N10T2-TRLMOSFET N-CH 100V 130A TO263 |
3,771 | 3.43 |
RFQ |
Tape & Reel (TR) | HiPerFET™, TrenchT2™ | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 130A (Tc) | 10V | 10.1mOhm @ 65A, 10V | 4.5V @ 1mA | 130 nC @ 10 V | ±20V | 6600 pF @ 25 V | - | 360W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
