| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
IRFU9120PBFMOSFET P-CH 100V 5.6A TO251AA |
3,782 | 1.85 |
RFQ |
Datasheet |
Tube | - | Active | P-Channel | MOSFET (Metal Oxide) | 100 V | 5.6A (Tc) | 10V | 600mOhm @ 3.4A, 10V | 4V @ 250µA | 18 nC @ 10 V | ±20V | 390 pF @ 25 V | - | 2.5W (Ta), 42W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
IRFIZ24GPBFMOSFET N-CH 60V 14A TO220-3 |
2,991 | 1.87 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 14A (Tc) | 10V | 100mOhm @ 8.4A, 10V | 4V @ 250µA | 25 nC @ 10 V | ±20V | 640 pF @ 25 V | - | 37W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
SUM10250E-GE3MOSFET N-CH 250V 63.5A D2PAK |
3,034 | 3.03 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | ThunderFET® | Active | N-Channel | MOSFET (Metal Oxide) | 250 V | 63.5A (Tc) | 7.5V, 10V | 31mOhm @ 30A, 10V | 4V @ 250µA | 88 nC @ 10 V | ±20V | 3002 pF @ 125 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SQJ463EP-T1_GE3MOSFET P-CH 40V 30A PPAK SO-8 |
2,556 | 3.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 30A (Tc) | 4.5V, 10V | 10mOhm @ 18A, 10V | 2.5V @ 250µA | 150 nC @ 10 V | ±20V | 5875 pF @ 20 V | - | 83W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
SQM40031EL_GE3MOSFET P-CH 40V 120A D2PAK |
2,209 | 3.06 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 120A (Tc) | 4.5V, 10V | 3mOhm @ 30A, 10V | 2.5V @ 250µA | 800 nC @ 10 V | ±20V | 39000 pF @ 25 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SQM50028EM_GE3MOSFET N-CH 60V 120A TO263-7 |
3,847 | 3.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 120A (Tc) | 10V | 2mOhm @ 30A, 10V | 3.5V @ 250µA | 185 nC @ 10 V | ±20V | 11900 pF @ 25 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
SUM70040E-GE3MOSFET N-CH 100V 120A TO263 |
3,727 | 3.21 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 120A (Tc) | 7.5V, 10V | 4mOhm @ 20A, 10V | 4V @ 250µA | 120 nC @ 10 V | ±20V | 5100 pF @ 50 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SQJQ141EL-T1_GE3AUTOMOTIVE P-CHANNEL 40 V (D-S) |
2,254 | 3.58 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 390A (Tc) | 4.5V, 10V | 2mOhm @ 10A, 10V | 2.5V @ 250µA | 731 nC @ 10 V | ±20V | 62190 pF @ 25 V | - | 600W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount | |
|
|
SUM60020E-GE3MOSFET N-CH 80V 150A TO263 |
2,485 | 3.25 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 150A (Tc) | 7.5V, 10V | 2.1mOhm @ 30A, 10V | 4V @ 250µA | 227 nC @ 10 V | ±20V | 10680 pF @ 40 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF640PBFMOSFET N-CH 200V 18A TO220AB |
499 | 2.08 |
RFQ |
Datasheet |
Bulk | - | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 18A (Tc) | 10V | 180mOhm @ 11A, 10V | 4V @ 250µA | 70 nC @ 10 V | ±20V | 1300 pF @ 25 V | - | 125W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
|
SQM110P06-8M9L_GE3MOSFET P-CH 60V 110A TO263 |
2,686 | 3.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 60 V | 110A (Tc) | 4.5V, 10V | 8.9mOhm @ 30A, 10V | 2.5V @ 250µA | 200 nC @ 10 V | ±20V | 7450 pF @ 25 V | - | 230W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
SUM40014M-GE3MOSFET N-CH 40V 200A TO263-7 |
3,216 | 3.65 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 200A (Tc) | - | 0.99Ohm @ 20A, 10V | 2.4V @ 250µA | 275 nC @ 10 V | ±20V | 15780 pF @ 20 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
IRF620SPBFMOSFET N-CH 200V 5.2A D2PAK |
3,951 | 2.14 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 5.2A (Tc) | 10V | 800mOhm @ 3.1A, 10V | 4V @ 250µA | 14 nC @ 10 V | ±20V | 260 pF @ 25 V | - | 3W (Ta), 50W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
IRFZ44PBFMOSFET N-CH 60V 50A TO220AB |
2,106 | 2.14 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 50A (Tc) | 10V | 28mOhm @ 31A, 10V | 4V @ 250µA | 67 nC @ 10 V | ±20V | 1900 pF @ 25 V | - | 150W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
SQJQ112E-T1_GE3AUTOMOTIVE N-CHANNEL 100 V (D-S) |
3,413 | 3.84 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, TrenchFET® Gen IV | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 296A (Tc) | 10V | 2.53mOhm @ 20A, 10V | 3.5V @ 250µA | 272 nC @ 10 V | ±20V | 15945 pF @ 25 V | - | 600W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
|
IRF540PBFMOSFET N-CH 100V 28A TO220AB |
2,707 | 2.25 |
RFQ |
Datasheet |
Tube | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 28A (Tc) | 10V | 77mOhm @ 17A, 10V | 4V @ 250µA | 72 nC @ 10 V | ±20V | 1700 pF @ 25 V | - | 150W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
|
IRF9540PBFMOSFET P-CH 100V 19A TO220AB |
3,955 | 2.25 |
RFQ |
Datasheet |
Tube | - | Active | P-Channel | MOSFET (Metal Oxide) | 100 V | 19A (Tc) | 10V | 200mOhm @ 11A, 10V | 4V @ 250µA | 61 nC @ 10 V | ±20V | 1400 pF @ 25 V | - | 150W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
SQM120N04-1M7L_GE3MOSFET N-CH 40V 120A TO263 |
2,408 | 3.60 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 120A (Tc) | 4.5V, 10V | 1.7mOhm @ 30A, 10V | 2.5V @ 250µA | 285 nC @ 10 V | ±20V | 14606 pF @ 20 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
SIE818DF-T1-E3MOSFET N-CH 75V 60A 10POLARPAK |
3,227 | 4.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 75 V | 60A (Tc) | 4.5V, 10V | 9.5mOhm @ 16A, 10V | 3V @ 250µA | 95 nC @ 10 V | ±20V | 3200 pF @ 38 V | - | 5.2W (Ta), 125W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
|
SQM120P06-07L_GE3MOSFET P-CH 60V 120A TO263 |
2,430 | 3.81 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 60 V | 120A (Tc) | 4.5V, 10V | 6.7mOhm @ 30A, 10V | 2.5V @ 250µA | 270 nC @ 10 V | ±20V | 14280 pF @ 25 V | - | 375W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
