| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | TransistorType | Current-Collector(Ic)(Max) | Voltage-CollectorEmitterBreakdown(Max) | VceSaturation(Max)@IbIc | Current-CollectorCutoff(Max) | DCCurrentGain(hFE)(Min)@IcVce | Power-Max | Frequency-Transition | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2SC4081U3HZGT106RTRANS NPN 50V 0.15A UMT3 |
3,025 | 0.39 |
RFQ |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | NPN | 150 mA | 50 V | 400mV @ 5mA, 50mA | 100nA (ICBO) | 120 @ 1mA, 6V | 200 mW | 180MHz | 150°C (TJ) | Surface Mount | |
|
|
2SA1576U3HZGT106RTRANS PNP 50V 0.15A UMT3 |
3,138 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | PNP | 150 mA | 50 V | 500mV @ 5mA, 5mA | 100nA (ICBO) | 120 @ 1mA, 6V | 200 mW | 140MHz | 150°C (TJ) | Surface Mount |
|
|
UMT3906T106TRANS PNP 40V 0.2A UMT3 |
2,437 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | PNP | 200 mA | 40 V | 400mV @ 5mA, 50mA | 50nA | 100 @ 10mA, 1V | 200 mW | 250MHz | 150°C (TJ) | Surface Mount |
|
|
UMT3904T106TRANS NPN 40V 0.2A UMT3 |
3,829 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 200 mA | 40 V | 300mV @ 5mA, 50mA | 50nA | 100 @ 10mA, 1V | 200 mW | 300MHz | 150°C (TJ) | Surface Mount |
|
MMST3904T146TRANS NPN 40V 0.2A SMT3 |
761 | 0.36 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 200 mA | 40 V | 300mV @ 5mA, 50mA | 50nA | 100 @ 10mA, 1V | 200 mW | 300MHz | 150°C (TJ) | Surface Mount |
|
|
2SAR502U3T106TRANS PNP 30V 0.5A UMT3 |
2,696 | 0.41 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | PNP | 500 mA | 30 V | 400mV @ 10mA, 200mA | 200nA (ICBO) | 200 @ 100mA, 2V | 200 mW | 520MHz | 150°C (TJ) | Surface Mount |
|
SST3906T116TRANS PNP 40V 0.2A SST3 |
3,211 | 0.33 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | PNP | 200 mA | 40 V | 400mV @ 5mA, 50mA | 50nA | 100 @ 10mA, 1V | 350 mW | 250MHz | 150°C (TJ) | Surface Mount |
|
|
UMT2907AT106TRANS PNP 60V 0.6A UMT3 |
2,417 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | PNP | 600 mA | 60 V | 1.6V @ 50mA, 500mA | 100nA | 100 @ 150mA, 10V | 200 mW | 200MHz | 150°C (TJ) | Surface Mount |
|
|
2SD1484KT146QTRANS NPN 50V 0.5A SMT3 |
3,932 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 500 mA | 50 V | 400mV @ 15mA, 150mA | 500nA (ICBO) | 120 @ 10mA, 3V | 200 mW | 250MHz | 150°C (TJ) | Surface Mount |
|
2SC5658T2LQTRANS NPN 50V 0.15A VMT3 |
3,333 | 0.41 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 150 mA | 50 V | 400mV @ 5mA, 50mA | 100nA (ICBO) | 120 @ 1mA, 6V | 150 mW | 180MHz | 150°C (TJ) | Surface Mount |
|
|
2SD2704KT146TRANS NPN 20V 0.3A SMT3 |
2,292 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 300 mA | 20 V | 100mV @ 3mA, 30mA | 100nA (ICBO) | 820 @ 4ma, 2V | 200 mW | 35MHz | 150°C (TJ) | Surface Mount |
|
|
2SD2114KT146WTRANS NPN 20V 0.5A SMT3 |
2,579 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 500 mA | 20 V | 400mV @ 20mA, 500mA | 500nA (ICBO) | 1200 @ 10mA, 3V | 200 mW | 350MHz | 150°C (TJ) | Surface Mount |
|
|
2SC4097T106RTRANS NPN 32V 0.5A UMT3 |
3,337 | 0.46 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 500 mA | 32 V | 600mV @ 50mA, 500mA | 1µA (ICBO) | 180 @ 10mA, 3V | 200 mW | 250MHz | 150°C (TJ) | Surface Mount |
|
|
2SD1782KT146RTRANS NPN 80V 0.5A SMT3 |
3,081 | 0.40 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 500 mA | 80 V | 500mV @ 50mA, 500mA | 500nA (ICBO) | 180 @ 100mA, 3V | 200 mW | 120MHz | 150°C (TJ) | Surface Mount |
|
|
2SC3906KT146STRANS NPN 120V 0.05A SMT3 |
2,256 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 50 mA | 120 V | 500mV @ 1mA, 10mA | 500nA (ICBO) | 180 @ 2mA, 6V | 200 mW | 140MHz | 150°C (TJ) | Surface Mount |
|
|
2SC5662T2LPTRANS NPN 11V 0.05A VMT3 |
2,697 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 50 mA | 11 V | 500mV @ 5mA, 10mA | 500nA (ICBO) | 82 @ 5mA, 10V | 150 mW | 3.2GHz | 150°C (TJ) | Surface Mount |
|
|
2SC3837KT146PTRANS NPN 20V 0.05A SMT3 |
2,088 | 0.47 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 50 mA | 20 V | 500mV @ 4mA, 20mA | 500nA (ICBO) | 82 @ 10mA, 10V | 200 mW | 1.5GHz | 150°C (TJ) | Surface Mount |
|
|
2SC5663T2LTRANS NPN 12V 0.5A VMT3 |
2,056 | 0.54 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 500 mA | 12 V | 250mV @ 10mA, 200mA | 100nA (ICBO) | 270 @ 10mA, 2V | 150 mW | 320MHz | 150°C (TJ) | Surface Mount |
|
2SC5866TLRTRANS NPN 60V 2A TSMT3 |
3,621 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 2 A | 60 V | 500mV @ 100mA, 1A | 1µA (ICBO) | 120 @ 100mA, 2V | 500 mW | 200MHz | 150°C (TJ) | Surface Mount |
|
2SCR513RTLTRANS NPN 50V 1A TSMT3 |
2,317 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | NPN | 1 A | 50 V | 350mV @ 25mA, 500mA | 1µA (ICBO) | 180 @ 50mA, 2V | 500 mW | 360MHz | 150°C (TJ) | Surface Mount |
