Power Transformers(6768)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | Type | Voltage-Primary | Voltage-Secondary(FullLoad) | Current-Output(Max) | PrimaryWinding(s) | SecondaryWinding(s) | CenterTap | Power-Max | MountingType | TerminationStyle | Size/Dimension | Height-Seated(Max) | Voltage-Isolation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3FL30-400PWR XFMR LAMINATED 12VA TH |
3,573 | 20.64 |
|
Bulk | 3FL | Active | Laminated Core | 115V, 230V | Parallel 17V, Series 34V | Parallel 800mA, Series 400mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 63.50mm L x 50.80mm W | 27.05mm | 1500Vrms | |
|
PL56-36-130BPWR XFMR LAMINATED 56VA TH |
3,755 | 20.69 |
|
Bulk | PL56-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 3.12A, Series 1.56A | Dual | Dual | No | 56VA | Through Hole | PC Pin | 76.20mm L x 64.00mm W | 48.50mm | 3500Vrms | |
|
|
PL56-20-130BPWR XFMR LAMINATED 56VA TH |
3,808 | 24.14 |
|
Bulk | PL56-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 10V, Series 20V | Parallel 5.6A, Series 2.8A | Dual | Dual | No | 56VA | Through Hole | PC Pin | 76.20mm L x 64.00mm W | 48.50mm | 3500Vrms | |
|
3FD-436PWR XFMR LAMINATED 6VA TH |
2,382 | 9.50 |
|
Tube | 3FD-4xx | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 340mA, Series 170mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.50mm L x 34.83mm W | 34.55mm | 2500Vrms | |
|
3FD-416PWR XFMR LAMINATED 6VA TH |
2,652 | 9.50 |
|
Tube | 3FD-4xx | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 800mA, Series 400mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.50mm L x 34.83mm W | 38.00mm | 2500Vrms | |
|
|
3FD-424PWR XFMR LAMINATED 6VA TH |
2,114 | 9.50 |
|
Tube | 3FD-4xx | Active | Laminated Core | 115V, 230V | Parallel 12V, Series 24V | Parallel 500mA, Series 250mA | Dual | Dual | No | 6VA | Through Hole | PC Pin | 41.50mm L x 34.83mm W | 38.00mm | 2500Vrms | |
|
3FD-516PWR XFMR LAMINATED 12VA TH |
2,613 | 12.67 |
|
Tube | 3FD-5xx | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 1.6A, Series 800mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 48.50mm L x 41.52mm W | 38.00mm | 2500Vrms | |
|
|
3FD-524PWR XFMR LAMINATED 12VA TH |
239 | 12.67 |
|
Tube | 3FD-5xx | Active | Laminated Core | 115V, 230V | Parallel 12V, Series 24V | Parallel 1A, Series 500mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 48.50mm L x 41.52mm W | 38.00mm | 2500Vrms | |
|
PL30-24-130BPWR XFMR LAMINATED 30VA TH |
3,781 | 20.96 |
|
Bulk | PL30-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 12V, Series 24V | Parallel 2.5A, Series 1.25A | Dual | Dual | No | 30VA | Through Hole | PC Pin | 66.70mm L x 55.60mm W | 41.00mm | 3500Vrms | |
|
3FS-312PWR XFMR LAMINATED 2.4VA TH |
2,323 | 5.25 |
|
Tube | 3FS-3xx | Active | Laminated Core | 115V | Parallel 6.3V, Series 12.6V | Parallel 400mA, Series 200mA | Single | Dual | No | 2.4VA | Through Hole | PC Pin | 35.56mm L x 31.00mm W | 32.10mm | 2500Vrms | |
|
3FD-328PWR XFMR LAMINATED 2.4VA TH |
3,417 | 5.61 |
|
Tube | 3FD-3xx | Active | Laminated Core | 115V, 230V | Parallel 14V, Series 28V | Parallel 170mA, Series 85mA | Dual | Dual | No | 2.4VA | Through Hole | PC Pin | 35.56mm L x 31.00mm W | 32.10mm | 2500Vrms | |
|
3FD-210PWR XFMR LAMINATED 1.1VA TH |
2,114 | 5.62 |
|
Tube | 3FD-2xx | Active | Laminated Core | 115V, 230V | Parallel 5V, Series 10V | Parallel 220mA, Series 110mA | Dual | Dual | No | 1.1VA | Through Hole | PC Pin | 35.56mm L x 31.00mm W | 25.40mm | 2500Vrms | |
|
PL5.0-36-130BPWR XFMR LAMINATED 5VA TH |
2,319 | 8.05 |
|
Tube | PL5.0-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 18V, Series 36V | Parallel 280mA, Series 140mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.28mm L x 36.37mm W | 35.60mm | 3500Vrms | |
|
|
PL5.0-28-130BPWR XFMR LAMINATED 5VA TH |
540 | 8.05 |
|
Tube | PL5.0-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 14V, Series 28V | Parallel 360mA, Series 180mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.28mm L x 36.37mm W | 35.60mm | 3500Vrms | |
|
|
PL5.0-12-130BPWR XFMR LAMINATED 5VA TH |
3,253 | 8.05 |
|
Tube | PL5.0-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 800mA, Series 400mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.28mm L x 36.37mm W | 35.60mm | 3500Vrms | |
|
|
PL5.0-16-130BPWR XFMR LAMINATED 5VA TH |
3,309 | 8.05 |
|
Tube | PL5.0-xx-130B | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 620mA, Series 310mA | Dual | Dual | No | 5VA | Through Hole | PC Pin | 41.28mm L x 36.37mm W | 35.60mm | 3500Vrms | |
|
3FS-420PWR XFMR LAMINATED 6VA TH |
3,085 | 9.13 |
|
Tube | 3FS-4xx | Active | Laminated Core | 115V | Parallel 10V, Series 20V | Parallel 600mA, Series 300mA | Single | Dual | No | 6VA | Through Hole | PC Pin | 41.50mm L x 34.83mm W | 34.55mm | 2500Vrms | |
|
|
3FD-528PWR XFMR LAMINATED 12VA TH |
3,636 | 12.67 |
|
Tube | 3FD-5xx | Active | Laminated Core | 115V, 230V | Parallel 14V, Series 28V | Parallel 840mA, Series 420mA | Dual | Dual | No | 12VA | Through Hole | PC Pin | 48.50mm L x 41.52mm W | 38.00mm | 2500Vrms | |
|
3FS-210PWR XFMR LAMINATED 1.1VA TH |
2,275 | 5.21 |
|
Tube | 3FS-2xx | Active | Laminated Core | 115V | Parallel 5V, Series 10V | Parallel 220mA, Series 110mA | Single | Dual | No | 1.1VA | Through Hole | PC Pin | 35.56mm L x 31.00mm W | 25.40mm | 2500Vrms | |
|
|
3FS-216PWR XFMR LAMINATED 1.1VA TH |
3,071 | 5.21 |
|
Tube | 3FS-2xx | Active | Laminated Core | 115V | Parallel 8V, Series 16V | Parallel 140mA, Series 70mA | Single | Dual | No | 1.1VA | Through Hole | PC Pin | 35.56mm L x 31.00mm W | 25.40mm | 2500Vrms |
