| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | MountingType | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | CoilCurrent | CoilType | Features | TerminationStyle | SealRating | CoilInsulation | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | OperatingTemperature | ContactMaterial |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ALZ51F09RELAY GEN PURPOSE SPST 16A 9V |
3,909 | 3.38 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 9VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 44.4 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 6.3 VDC | 0.9 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
ALZ51F18TRELAY GEN PURPOSE SPST 16A 18V |
2,737 | 3.38 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 22.2 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 12.6 VDC | 1.8 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ51F24TRELAY GEN PURPOSE SPST 16A 24V |
3,958 | 3.38 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 16.7 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 16.8 VDC | 2.4 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ52F18TRELAY GEN PURPOSE SPST 16A 18V |
3,580 | 3.38 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 22.2 mA | Non Latching | - | PC Pin | Sealed - Fully | Class F | 12.6 VDC | 1.8 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
JTN1S-PA-F-DC12VRELAY GEN PURPOSE SPDT 20A 12V |
3,383 | 3.40 |
RFQ |
Datasheet |
Bulk | JT-N | Obsolete | Through Hole | 12VDC | SPDT (1 Form C) | 20 A | 277VAC - Max | 66.7 mA | Non Latching | - | PC Pin | Sealed - Fully | Class F | 9 VDC | 1.2 VDC | 20 ms | 10 ms | -55°C ~ 85°C | Silver Tin Oxide (AgSnO) |
|
ALZ51B18RELAY GEN PURPOSE SPST 16A 18V |
2,053 | 3.40 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 22.2 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class B | 12.6 VDC | 1.8 VDC | 15 ms | 5 ms | -40°C ~ 85°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ51F48TWRELAY GEN PURPOSE SPST 16A 48V |
3,746 | 3.42 |
RFQ |
Datasheet |
Box | ALZ | Active | Through Hole | 48VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 8.3 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 33.6 VDC | 4.8 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ52F48TWRELAY GEN PURPOSE SPST 16A 48V |
2,572 | 3.42 |
RFQ |
Datasheet |
Box | ALZ | Active | Through Hole | 48VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 8.3 mA | Non Latching | - | PC Pin | Sealed - Fully | Class F | 33.6 VDC | 4.8 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ12F05TWRELAY GEN PURPOSE SPDT 16A 5V |
2,387 | 3.44 |
RFQ |
Datasheet |
Box | ALZ | Active | Through Hole | 5VDC | SPDT (1 Form C) | 16 A | 440VAC - Max | 80 mA | Non Latching | - | PC Pin | Sealed - Fully | Class F | 3.5 VDC | 0.5 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ51F06RELAY GEN PURPOSE SPST 16A 6V |
2,203 | 3.50 |
RFQ |
Box | ALZ | Active | Through Hole | 6VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | - | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | - | - | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) | |
|
ALF1T06RELAY GEN PURPOSE SPST 20A 6V |
3,795 | 3.51 |
RFQ |
Datasheet |
Bulk | ALF | Active | Through Hole | 6VDC | SPST-NO (1 Form A) | 20 A | 250VAC - Max | 150 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | - | 4.2 VDC | 0.6 VDC | 20 ms | 15 ms | -40°C ~ 60°C | Silver Tin Oxide (AgSnO) |
|
|
ALZ51F18RELAY GEN PURPOSE SPST 16A 18V |
2,457 | 3.52 |
RFQ |
Datasheet |
Tube | ALZ | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 16 A | 440VAC - Max | 22.2 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 12.6 VDC | 1.8 VDC | 15 ms | 5 ms | -40°C ~ 105°C | Silver Tin Oxide (AgSnO) |
|
ALF1P18RELAY GEN PURPOSE SPST 20A 18V |
3,178 | 3.55 |
RFQ |
Datasheet |
Box | ALF | Active | Through Hole | 18VDC | SPST-NO (1 Form A) | 20 A | 250VAC - Max | 50 mA | Non Latching | - | PC Pin | - | - | 12.6 VDC | 1.8 VDC | 20 ms | 15 ms | -40°C ~ 60°C | Silver Tin Oxide (AgSnO) |
|
JW2HN-DC12VRELAY GEN PURPOSE DPDT 5A 12V |
3,059 | 3.58 |
RFQ |
Datasheet |
Bulk | JW | Active | Through Hole | 12VDC | DPDT (2 Form C) | 5 A | 250VAC, 30VDC - Max | 44 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class E | 8.4 VDC | 1.2 VDC | 15 ms | 5 ms | -40°C ~ 60°C | Silver Nickel (AgNi) |
|
TS2SA-LT-6V-TH-ZTX SIGNAL RELAY |
3,739 | 3.58 |
RFQ |
Tape & Reel (TR) | - | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
TX2-4.5V-THRELAY GEN PURPOSE DPDT 7.5A 4.5V |
3,517 | 3.59 |
RFQ |
Datasheet |
Tube | TX-TH | Active | Through Hole | 4.5VDC | DPDT (2 Form C) | 7.5 A | 250VAC, 220VDC - Max | 31 mA | Non Latching | - | PC Pin | - | - | 3.15 VDC | 0.45 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) |
|
ALF1P06RELAY GEN PURPOSE SPST 20A 6V |
2,368 | 3.67 |
RFQ |
Datasheet |
Box | ALF | Active | Through Hole | 6VDC | SPST-NO (1 Form A) | 20 A | 250VAC - Max | 150 mA | Non Latching | - | PC Pin | - | - | 4.2 VDC | 0.6 VDC | 20 ms | 15 ms | -40°C ~ 60°C | Silver Tin Oxide (AgSnO) |
|
JVN1A-5V-FRELAY GEN PURPOSE SPST 16A 5V |
3,291 | 3.67 |
RFQ |
Datasheet |
Bulk | JV-N | Active | Through Hole | 5VDC | SPST-NO (1 Form A) | 16 A | 277VAC, 30VDC - Max | 40 mA | Non Latching | - | PC Pin | Sealed - Fully | - | 3.75 VDC | 0.25 VDC | 12 ms | 5 ms | -40°C ~ 70°C | Silver Tin Oxide (AgSnO) |
|
JW1FSN-B-DC48VRELAY GEN PURPOSE SPDT 10A 48V |
2,340 | 3.71 |
RFQ |
Datasheet |
Tray | JW | Active | Through Hole | 48VDC | SPDT (1 Form C) | 10 A | 250VAC, 30VDC - Max | 11 mA | Non Latching | - | PC Pin | Sealed - Fully | Class B | 33.6 VDC | 4.8 VDC | 15 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) |
|
|
JW1SN-DC12VRELAY GEN PURPOSE SPDT 5A 12V |
3,064 | 3.71 |
RFQ |
Datasheet |
Bulk | JW | Active | Through Hole | 12VDC | SPDT (1 Form C) | 5 A | 250VAC, 30VDC - Max | 44 mA | Non Latching | - | PC Pin | Sealed - Fully | Class E | 8.4 VDC | 1.2 VDC | 15 ms | 5 ms | -40°C ~ 60°C | Silver Nickel (AgNi) |
