Ferrite Cores(5020)

Mfr. Part #	Availability	Price	Quantity	Datasheet	Packaging	Series	ProductStatus	CoreType	Material	Diameter	InductanceFactor(Al)	Tolerance	Gap	EffectivePermeability(µe)	InitialPermeability(µi)	CoreFactor(ΣI/A)mm^-1	EffectiveLength(le)mm	EffectiveArea(Ae)mm²	MinimumCoreCrossSection(Amin)mm²	EffectiveMagneticVolume(Ve)mm³	Finish	Height	Length
B66361G0200X187 FERRITE CORE ETD N87 1PC EPCOS - TDK Electronics	634	2.19	RFQ	PDF	Box	ETD34/17/11	Active	ETD	ETD 34 x 17 x 11	N87	-	-	-	Gapped	-	-	-	-	-	-	-	Uncoated	0.689 (17.50mm)
B66283K0000X149 FERRITE CORE I N49 EPCOS - TDK Electronics	838	2.21	RFQ	PDF	Tray	I18/2/10	Active	I	I 18 x 2 x 10	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.079 (2.00mm)
B66482K0000X187 FERRITE CORE I N87 1PC EPCOS - TDK Electronics	2,201	2.21	RFQ	PDF	Box	I23/2/13	Active	I	I 23 x 2 x 13	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.083 (2.10mm)
B66453G0000X197 FERRITE CORE ELP N97 1PC EPCOS - TDK Electronics	167	2.21	RFQ	PDF	Box	ELP18/4/10	Active	ELP	ELP 18 x 4 x 10	N97	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.157 (4.00mm)
B66389G0000X187 FERRITE CORE E N87 1PC EPCOS - TDK Electronics	2,408	2.21	RFQ	PDF	Box	E36/18/11	Active	E	E 36 x 18 x 11	N87	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.709 (18.00mm)
B65803J0000R030 FERRITE CORE RM 1.9UH N30 2PCS EPCOS - TDK Electronics	2,878	2.32	RFQ	PDF	Box	RM4	Active	RM	RM 4	N30	-	1.9 µH	-20%, +30%	Ungapped	2560	4300	1.7	22	13	11.3	286	Uncoated	0.207 (5.25mm)
B66482G0000X608 ER23/5/13-PC200 EPCOS - TDK Electronics	210	2.37	RFQ	PDF	Bulk	ER23/5/13	Active	-	-	PC200	-	-	-	-	-	-	-	-	-	-	-	-	-
B66484G0000X149 FERRITE CORE ER N49 1PC EPCOS - TDK Electronics	245	2.39	RFQ	PDF	Box	ER25/6/15	Active	ER	ER 25 x 6 x 15	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.216 (5.50mm)
B65531D0160A048 FERRITE CORE P 160NH N48 2PCS EPCOS - TDK Electronics	2,607	2.55	RFQ	PDF	Box	P11/7	Active	P (Pot Core)	P 11 x 7	N48	0.445 (11.30mm)	160 nH	±3%	Gapped	127	-	1	15.9	15.9	-	253	Uncoated	0.130 (3.30mm)
B66455G0000X608 ELP22/6/16-PC200 EPCOS - TDK Electronics	735	2.66	RFQ	PDF	Box	ELP22/6/16	Active	ELP	ELP 22 x 6 x 16	PC200	-	2100 nH	±25%	Ungapped	640	800	0.41	32.5	78.3	77.9	2540	Uncoated	0.224 (5.70mm)
B66285G0000X192 FERRITE CORE ELP N92 1PC EPCOS - TDK Electronics	117	2.73	RFQ	PDF	Box	ELP22/6/16	Active	ELP	ELP 22 x 6 x 16	N92	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
B66285G0000X197 FERRITE CORE ELP N97 1PC EPCOS - TDK Electronics	418	2.76	RFQ	PDF	Box	ELP22/6/16	Active	ELP	ELP 22 x 6 x 16	N97	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
B65807J0000R041 FERRITE CORE RM 3.1UH N41 2PCS EPCOS - TDK Electronics	513	2.77	RFQ	PDF	Box	RM6	Active	RM	RM 6	N41	-	3.1 µH	-20%, +30%	Ungapped	1930	2800	0.78	28.6	36.6	31	1050	Uncoated	0.246 (6.25mm)
B66482K0000X197 FERRITE CORE I N97 1PC EPCOS - TDK Electronics	853	2.79	RFQ	PDF	Tray	I23/2/13	Active	I	I 23 x 2 x 13	N97	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.083 (2.10mm)
B66482K0000X149 FERRITE CORE I N49 1PC EPCOS - TDK Electronics	811	2.79	RFQ	PDF	Box	I23/2/13	Active	I	I 23 x 2 x 13	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.083 (2.10mm)
B66483G0000X192 FERRITE CORE EQ N92 1PC EPCOS - TDK Electronics	232	2.80	RFQ	PDF	Box	EQ20/6.3/14	Active	EQ	EQ 20 x 6	N92	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.248 (6.30mm)
B66455G0000X149 FERRITE CORE ELP N49 1PC EPCOS - TDK Electronics	334	2.82	RFQ	PDF	Box	ELP22/6/16	Active	ELP	ELP 22 x 6 x 16	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.224 (5.70mm)
B66285K0000X149 FERRITE CORE I N49 EPCOS - TDK Electronics	734	2.85	RFQ	PDF	Tray	I22/2.5/16	Active	I	I 22 x 2.5 x 16	N49	-	-	-	Ungapped	-	-	-	-	-	-	-	Uncoated	0.098 (2.50mm)
B65811D0630J048 FERRITE CORE RM 630NH N48 2PCS EPCOS - TDK Electronics	250	5.15	RFQ	PDF	Cut Tape (CT),Tape & Box (TB)	RM8	Active	RM	RM 8	N48	-	630 nH	±5%	Gapped	338	-	0.68	35.1	52	-	1825	Uncoated	0.324 (8.25mm)
B65807J0250A041 FERRITE CORE RM 250NH N41 2PCS EPCOS - TDK Electronics	104	2.89	RFQ	PDF	Box	RM6	Active	RM	RM 6	N41	-	250 nH	±3%	Gapped	155	2800	0.78	28.6	36.6	31	1050	Uncoated	0.246 (6.25mm)
