| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
S10MCRECTIFIER DIODE 1KV 10A SMC |
156,000 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMC | RoHS | - | Standard | Active | Surface Mount | 100pF @ 4V, 1MHz | - | - | 1000 V | 10A | -55°C ~ 150°C | 1.1 V @ 10 A |
|
|
S6MCRECTIFIER DIODE 1KV 6A SMC |
3,000 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMC | RoHS | - | Standard | Active | Surface Mount | 100pF @ 4V, 1MHz | - | - | 1000 V | 6A | -55°C ~ 150°C | 1.15 V @ 6 A |
|
SS310CSCHOTTKY DIODE SMC 100V 3A |
1,260,000 | 0.25 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMC | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 350pF @ 4V, 1MHz | - | 300 µA @ 100 V | 100 V | 3A | - | 850 mV @ 3 A |
|
1N4148WSWITCHING SOD-123, 100V |
3,327 | 0.03 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123 | RoHS | - | Standard | Active | Surface Mount | 2pF @ 0V, 1MHz | 4 ns | 1 µA @ 75 V | 75 V | 150mA | -65°C ~ 150°C | 720 mV @ 10 µA |
|
|
SS34CSCHOTTKY DIODE SMC 40V 3A |
3,000 | 0.23 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMC | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 450pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 3A | - | 550 mV @ 3 A |
|
|
SS320CSCHOTTKY DIODE SMC 200V 3A |
2,036 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMC | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 350pF @ 4V, 1MHz | - | 300 µA @ 200 V | 200 V | 3A | - | 950 mV @ 3 A |
|
SS38SCHOTTKY DIODE SMA 80V 3A |
2,578 | 0.19 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMA | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 300pF @ 4V, 1MHz | - | 500 µA @ 80 V | 80 V | 3A | -55°C ~ 150°C | - |
|
1N5399GEN PURP 1KV 1.5A DO-15 |
2,954 | 0.08 |
RFQ |
Datasheet |
Tape & Box (TB) | DO-15 | RoHS | - | Standard | Active | Through Hole | 20pF @ 4V, 1MHz | - | - | 1000 V | 1.5A | -50°C ~ 150°C | 1.4 V @ 1.5 A |
.jpg)
|
S3MBRECTIFIER DIODE 1KV 3A SMB |
19,800 | 0.12 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMB | RoHS | - | Standard | Active | Surface Mount | 35pF @ 4V, 1MHz | - | - | 1000 V | 3A | -55°C ~ 150°C | 1.1 V @ 3 A |
|
SS24FSCHOTTKY DIODE SMAF 40V 2A |
1,896,000 | 0.12 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMAF | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 160pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 2A | -55°C ~ 125°C | - |
|
DSK110SCHOTTKY DIODE SOD-123FL 100V 1A |
492,000 | 0.12 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 0.2 mA @ 100 V | 100 V | 1A | -55°C ~ 125°C | 850 mV @ 1 A |
|
|
DSK22SCHOTTKY DIODE SOD-123FL 20V 2A |
276,000 | 0.13 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 0.5 mA @ 20 V | 20 V | 2A | -55°C ~ 125°C | 550 mV @ 2 A |
|
|
DSK26SCHOTTKY DIODE SOD-123FL 60V 2A |
177,000 | 0.13 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 0.5 mA @ 60 V | 60 V | 2A | -55°C ~ 125°C | 700 mV @ 2 A |
|
|
SS210SCHOTTKY DIODE SMA 100V 2A |
15,000 | 0.13 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMA | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 300 µA @ 100 V | 100 V | 2A | -55°C ~ 150°C | - |
|
|
DSK210SCHOTTKY DIODE SOD-123FL 100V 2A |
381,000 | 0.13 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 0.5 mA @ 100 V | 100 V | 2A | -55°C ~ 125°C | 850 mV @ 2 A |
|
|
DSK120SCHOTTKY DIODE SOD-123FL 200V 1A |
129,000 | 0.13 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 0.1 mA @ 200 V | 200 V | 1A | -55°C ~ 125°C | 950 mV @ 1 A |
|
SS24BSCHOTTKY DIODE SMB 40V 2A |
480,000 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMB | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 2A | -55°C ~ 125°C | 550 mV @ 2 A |
|
|
SS24SCHOTTKY DIODE SMA 40V 2A |
2,930,000 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMA | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 500 µA @ 40 V | 40 V | 2A | -55°C ~ 125°C | - |
|
|
SS26SCHOTTKY DIODE SMA 60V 2A |
1,475,000 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | SMA | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 500 µA @ 60 V | 60 V | 2A | -55°C ~ 150°C | - |
|
|
DSK24SCHOTTKY DIODE SOD-123FL 40V 2A |
1,173,000 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR) | SOD-123FL | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 220pF @ 4V, 1MHz | - | 0.5 mA @ 40 V | 40 V | 2A | -55°C ~ 125°C | 550 mV @ 2 A |
