| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ES1GRECTIFIER DIODE, 1A, 400V, DO-21 |
3,959 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 10pF @ 4V, 1MHz | 35 ns | 5 µA @ 400 V | 400 V | 1A | -55°C ~ 150°C | 1.3 V @ 1 A | |
|
PMEG3010BEANOW NEXPERIA PMEG3010BEA - RECTI |
2,934 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
GF1ARECTIFIER DIODE, 1A, 50V, DO-214 |
3,397 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 2 µs | 5 µA @ 50 V | 50 V | 1A | -65°C ~ 175°C | 1 V @ 1 A | |
|
|
PMEG2015EA115NOW NEXPERIA PMEG2015EA RECTIFIE |
3,271 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 25pF @ 5V, 1MHz | - | 50 µA @ 15 V | 20 V | 1.5A (DC) | -65°C ~ 125°C | 660 mV @ 1.5 A | |
|
US1KFARECTIFIER DIODE, 1A, 800V |
2,420 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 75 ns | 5 µA @ 800 V | 800 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | |
|
PMEG6010ERPMEG6010ER - 1 A LOW VF MEGA SCH |
2,244 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 120pF @ 1V, 1MHz | - | 60 µA @ 60 V | 60 V | 1A | 150°C (Max) | 530 mV @ 1 A | |
|
|
S2BRECTIFIER DIODE, 2A, 100V, DO-21 |
2,886 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 100 V | 100 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
|
US1AFARECTIFIER DIODE, 1A, 50V |
2,665 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 20pF @ 4V, 1MHz | 50 ns | 5 µA @ 50 V | 50 V | 1A | -55°C ~ 150°C | 950 mV @ 1 A | |
|
|
ES1JDIODE GEN PURP 600V 1A SMA |
3,877 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8pF @ 4V, 1MHz | 35 ns | 5 µA @ 600 V | 600 V | 1A | -55°C ~ 150°C | 1.7 V @ 1 A | |
|
|
S2KRECTIFIER DIODE, 2A, 800V, DO-21 |
2,887 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 800 V | 800 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
|
PMEG2015EA115NOW NEXPERIA PMEG2015EA RECTIFIE |
3,388 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 25pF @ 5V, 1MHz | - | 50 µA @ 15 V | 20 V | 1.5A (DC) | -65°C ~ 125°C | 660 mV @ 1.5 A | |
|
|
S2DRECTIFIER DIODE, 2A, 200V, DO-21 |
3,351 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | - | 1.5 µs | 5 µA @ 200 V | 200 V | 2A | -50°C ~ 150°C | 1.15 V @ 2 A | |
|
PMEG6010CPA115NOW NEXPERIA PMEG6010CPA RECTIFI |
3,440 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
PMEG2010EAZPMEG2010EA - 20 V, 1 A LOW VF (M |
2,884 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 19pF @ 5V, 1MHz | - | 50 µA @ 15 V | 20 V | 1A (DC) | 125°C (Max) | 550 mV @ 1 A | |
|
MR854RLGRECTIFIER DIODE, 3A, 400V, DO-20 |
3,296 | 0.08 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 300 ns | 10 µA @ 400 V | 400 V | 3A | -65°C ~ 125°C | 1.25 V @ 3 A | |
|
BAT721C,215BAT721C - 40 V, 200 MA, DUAL SCH |
3,778 | 0.08 |
RFQ |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | ||
|
|
S3GBRECTIFIER DIODE, 3A, 400V, DO-21 |
3,497 | 0.11 |
RFQ |
Datasheet |
Bulk | Automotive, AEC-Q101 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 18pF @ 0V, 1MHz | 1.5 µs | 10 µA @ 400 V | 400 V | 3A | -55°C ~ 150°C | 1.15 V @ 3 A |
|
|
RGF1DRECTIFIER DIODE, 1A, 200V, DO-21 |
3,136 | 0.11 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8.5pF @ 4V, 1MHz | 150 ns | 5 µA @ 200 V | 200 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | |
|
|
PMEG060V050EPD139NOW NEXPERIA PMEG060V050EPD |
2,372 | 0.12 |
RFQ |
Datasheet |
Bulk | RoHS | - | - | Active | - | - | - | - | - | - | - | - | |
|
SB330RECTIFIER DIODE, SCHOTTKY, 3A, 3 |
2,390 | 0.12 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Through Hole | - | - | 500 µA @ 30 V | 30 V | 3A | -50°C ~ 150°C | 490 mV @ 3 A |
