| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MUR210RLGDIODE GEN PURP 100V 2A AXIAL |
1,256 | 0.52 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | SWITCHMODE™ | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 30 ns | 2 µA @ 100 V | 100 V | 2A | -65°C ~ 175°C | 940 mV @ 2 A |
|
FDLL3595DIODE GEN PURP 125V 200MA SOD80 |
6,563 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 8pF @ 0V, 1MHz | 3 µs | 1 nA @ 125 V | 125 V | 200mA | -65°C ~ 200°C | 1 V @ 200 mA | |
|
1N457TRDIODE GEN PURP 70V 200MA DO35 |
3,810 | 0.32 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Through Hole | 8pF @ 0V, 1MHz | - | 25 nA @ 60 V | 70 V | 200mA | 175°C (Max) | 1 V @ 20 mA | |
|
SS15DIODE SCHOTTKY 50V 1A SMA |
6,009 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 200 µA @ 50 V | 50 V | 1A | -65°C ~ 125°C | 700 mV @ 1 A | |
|
|
SSA36DIODE SCHOTTKY 3A 60V SMA |
4,430 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | 10.74 ns | 100 µA @ 60 V | 60 V | 3A | -55°C ~ 150°C | 750 mV @ 3 A | |
|
MBR350RLGDIODE SCHOTTKY 50V 3A DO201AD |
1,818 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Through Hole | - | - | 600 µA @ 50 V | 50 V | 3A | -65°C ~ 150°C | 740 mV @ 3 A | |
|
S3JBDIODE GP 600V 3A SMB |
869 | 0.56 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Surface Mount | 18pF @ 0V, 1MHz | 1.5 µs | 10 µA @ 600 V | 600 V | 3A | -55°C ~ 150°C | 1.15 V @ 3 A |
|
NRVB440MFSWFT1GDIODE SCHOTTKY 40V 4A 5DFN |
1,229 | 0.56 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 800 µA @ 40 V | 40 V | 4A | -55°C ~ 175°C | 650 mV @ 4 A | |
|
|
RGF1MDIODE GEN PURP 1000V 1A SMA |
16,586 | 0.53 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 8.5pF @ 4V, 1MHz | 500 ns | 5 µA @ 1000 V | 1000 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | |
|
SB3003CH-TL-WDIODE SCHOTTKY 30V 3A 6CPH |
2,681 | 0.57 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | 90pF @ 10V, 1MHz | 20 ns | 42 µA @ 15 V | 30 V | 3A | -55°C ~ 125°C | 520 mV @ 3 A | |
|
SBRS8190NT3GDIODE SCHOTTKY 90V 1A 1202-SMB2 |
1,715 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 500 µA @ 500 µV | 90 V | 2A | -65°C ~ 175°C | 750 mV @ 1 A |
|
|
MUR405GDIODE GEN PURP 50V 4A DO201AD |
2,117 | 0.58 |
RFQ |
Datasheet |
Bulk | SWITCHMODE™ | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Obsolete | Through Hole | - | 35 ns | 5 µA @ 50 V | 50 V | 4A | -65°C ~ 175°C | 890 mV @ 4 A |
|
|
RGP10JDIODE GEN PURP 600V 1A DO204AL |
3,515 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 15pF @ 4V, 1MHz | 250 ns | 5 µA @ 600 V | 600 V | 1A | -65°C ~ 175°C | 1.3 V @ 1 A | |
|
|
EGF1DDIODE GEN PURP 200V 1A SMA |
4,962 | 0.59 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Surface Mount | 15pF @ 4V, 1MHz | 50 ns | 10 µA @ 200 V | 200 V | 1A | -65°C ~ 175°C | 1 V @ 1 A | |
|
|
EGP10KDIODE GEN PURP 800V 1A DO204AL |
5,000 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 75 ns | 5 µA @ 800 V | 800 V | 1A | -65°C ~ 150°C | 1.7 V @ 1 A | |
|
|
EGP10GDIODE GEN PURP 400V 1A DO204AL |
3,148 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 50 ns | 5 µA @ 400 V | 400 V | 1A | -65°C ~ 150°C | 1.25 V @ 1 A | |
|
SB07-03C-TB-EDIODE SCHOTTKY 30V 700MA 3CP |
1,446 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 25pF @ 10V, 1MHz | 10 ns | 80 µA @ 15 V | 30 V | 700mA | -55°C ~ 125°C | 550 mV @ 700 mA | |
|
SB2003M-TL-WDIODE SCHOTTKY 30V 2A 6MCPH |
2,980 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Obsolete | Surface Mount | 75pF @ 10V, 1MHz | 20 ns | 30 µA @ 15 V | 30 V | 2A | -55°C ~ 125°C | 500 mV @ 2 A | |
|
NRVBA1H100NT3GDIODE SCHOTTKY 1A 100V 1201 SMA2 |
1,830 | 0.55 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 40 µA @ 100 V | 100 V | 1A | -65°C ~ 175°C | 760 mV @ 1 A |
|
SS12FPDIODE SCHOTTKY 20V 1A SOD123HE |
1,972 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | 80pF @ 4V, 1MHz | - | 400 µA @ 20 V | 20 V | 1A | -55°C ~ 150°C | 450 mV @ 1 A |
