| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | RoHS | Speed | Diode Type | Part Status | Mounting Type | Capacitance @ Vr, F | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Operating Temperature | Voltage - Forward (Vf) (Max) @ If |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
1N4933GDIODE GEN PURP 50V 1A DO41 |
6,454 | 0.26 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 300 ns | 5 µA @ 50 V | 50 V | 1A | -65°C ~ 150°C | 1.2 V @ 1 A | |
|
|
1N4936RLGDIODE GEN PURP 400V 1A DO41 |
9,515 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 300 ns | 5 µA @ 400 V | 400 V | 1A | -65°C ~ 150°C | 1.2 V @ 1 A | |
|
SB01-15C-TB-EDIODE SCHOTTKY 150V 100MA 3CP |
8,314 | 0.47 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 7pF @ 10V, 1MHz | 10 ns | 50 µA @ 75 V | 150 V | 100mA | -55°C ~ 125°C | 750 mV @ 100 mA | |
|
FFSB1065B-F085650V 10A SIC SBD GEN1.5 |
1,031 | 5.93 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Surface Mount | 421pF @ 1V, 100kHz | 0 ns | 40 µA @ 650 V | 650 V | 27A (DC) | -55°C ~ 175°C | 1.7 V @ 10 A |
|
FFSH1265BDN-F085650V 12A SIC SBD GEN1.5 |
397 | 3.15 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101 | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 259pF @ 1V, 100kHz | 0 ns | 40 µA @ 650 V | 650 V | 7.2A (DC) | -55°C ~ 175°C | 1.7 V @ 6 A |
|
SMMBD914LT3GDIODE GEN PURP 100V 200MA SOT23 |
28,840 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 4pF @ 0V, 1MHz | 4 ns | 5 µA @ 75 V | 100 V | 200mA (DC) | -55°C ~ 150°C | 1 V @ 10 mA | |
|
1N5404RLGDIODE GEN PURP 400V 3A DO201AD |
31,051 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 400 V | 400 V | 3A | -65°C ~ 150°C | 1 V @ 3 A | |
|
|
1N4934GDIODE GEN PURP 100V 1A DO41 |
1,811 | 0.28 |
RFQ |
Datasheet |
Bulk | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | - | 300 ns | 5 µA @ 100 V | 100 V | 1A | -65°C ~ 150°C | 1.2 V @ 1 A | |
|
|
1N5400RLGDIODE GEN PURP 50V 3A DO201AD |
14,519 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 50 V | 50 V | 3A | -65°C ~ 150°C | 1 V @ 3 A | |
|
NSR0230P2T5GDIODE SCHOTTKY 30V 200MA SOD923 |
30,918 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | - | - | 10 µA @ 10 V | 30 V | 200mA (DC) | -55°C ~ 125°C | 500 mV @ 200 mA | |
|
|
1N5407RLGDIODE GEN PURP 800V 3A AXIAL |
4,921 | 0.44 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 800 V | 800 V | 3A | -65°C ~ 150°C | 1 V @ 3 A | |
|
EGP20JDIODE GEN PURP 600V 2A DO15 |
6,485 | 0.65 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Standard | Active | Through Hole | 45pF @ 4V, 1MHz | 75 ns | 5 µA @ 600 V | 600 V | 2A | -65°C ~ 150°C | 1.7 V @ 2 A | |
|
NSR10F40NXT5GDIODE SCHOTTKY 40V 1A 2DSN |
6,874 | 0.49 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Fast Recovery =< 500ns, > 200mA (Io) | Schottky | Active | Surface Mount | - | - | 100 µA @ 40 V | 40 V | 1A (DC) | 150°C (Max) | 490 mV @ 1 A | |
|
|
1N4006GDIODE GEN PURP 800V 1A AXIAL |
6,013 | 0.30 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 800 V | 800 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A | |
|
SMMSD701T1GDIODE SCHOTTKY 70V 200MA SOD123 |
11,716 | 0.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Schottky | Active | Surface Mount | 1pF @ 0V, 1MHz | - | 200 nA @ 35 V | 70 V | 200mA (DC) | -55°C ~ 125°C | 1 V @ 10 mA | |
|
|
1N4005GDIODE GEN PURP 600V 1A DO41 |
28,154 | 0.31 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 600 V | 600 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A | |
|
|
1N4003GDIODE GEN PURP 200V 1A DO41 |
21,903 | 0.31 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 200 V | 200 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A | |
|
FFSH1665A650V 16A SIC SBD |
296 | 6.82 |
RFQ |
Datasheet |
Tube | RoHS | No Recovery Time > 500mA (Io) | Silicon Carbide Schottky | Active | Through Hole | 887pF @ 1V, 100kHz | 0 ns | 200 µA @ 650 V | 650 V | 23A (DC) | -55°C ~ 150°C | - | |
|
|
NSVBAS19LT1GDIODE GP 120V 200MA SOT23-3 |
172,053 | 0.35 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | RoHS | Small Signal =< 200mA (Io), Any Speed | Standard | Active | Surface Mount | 5pF @ 0V, 1MHz | 50 ns | 100 nA @ 100 V | 120 V | 200mA (DC) | -55°C ~ 150°C | 1.25 V @ 200 mA | |
|
|
1N4001GDIODE GEN PURP 50V 1A DO41 |
18,117 | 0.31 |
RFQ |
Datasheet |
Bulk | RoHS | Standard Recovery >500ns, > 200mA (Io) | Standard | Active | Through Hole | - | - | 10 µA @ 50 V | 50 V | 1A | -65°C ~ 175°C | 1.1 V @ 1 A |
