| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SBX201C-L-TB-EDIODE ARRAY SCHOTTKY 2V 50MA 3CP |
3,714 | 0.37 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Schottky | 2 V | 50mA | 320 mV @ 1 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 µA @ 2 V | 150°C (Max) | Surface Mount |
|
SBAT54ALT3GDIODE ARRAY SCHOTTKY 30V SOT23-3 |
2,855 | 0.38 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Schottky | 30 V | 200mA (DC) | 800 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 25 V | -55°C ~ 150°C | Surface Mount |
|
M1MA151WAT1GDIODE ARRAY GP 40V 100MA SC59 |
3,119 | 0.03 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 40 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 10 ns | 100 nA @ 35 V | 150°C (Max) | Surface Mount |
|
|
BAW56LT3GDIODE ARRAY GP 70V 200MA SOT23-3 |
2,952 | 0.14 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 70 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 6 ns | 2.5 µA @ 70 V | -55°C ~ 150°C | Surface Mount |
|
M1MA142WAT1GDIODE ARRAY GP 80V 100MA SC70-3 |
3,585 | 0.17 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 80 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 10 ns | 100 nA @ 75 V | 150°C (Max) | Surface Mount |
|
BAV70TT1GDIODE ARRAY GP 100V 200MA SC75 |
3,723 | 0.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 100 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 6 ns | 5 µA @ 70 V | -55°C ~ 150°C | Surface Mount |
|
|
DAN222T1GDIODE ARRAY GP 80V 100MA SC75 |
2,276 | 0.19 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Active | 1 Pair Common Cathode | Standard | 80 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 70 V | 150°C (Max) | Surface Mount |
|
|
DAN222GDIODE ARRAY GP 80V 100MA SC75 |
3,033 | 0.18 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 80 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 70 V | 150°C (Max) | Surface Mount |
|
|
MMBD2835LT1GDIODE ARRAY GP 35V 100MA SOT23-3 |
2,166 | 0.39 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 35 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 30 V | -55°C ~ 150°C | Surface Mount |
|
MMBD1505ADIODE ARRAY GP 200V 200MA SOT23 |
3,979 | 0.42 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 200 V | 200mA | 1.1 V @ 200 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 nA @ 180 V | 150°C (Max) | Surface Mount |
|
BAS16DXV6T1GDIODE ARRAY GP 75V 200MA SOT563 |
3,755 | 0.45 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 Independent | Standard | 75 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 6 ns | 1 µA @ 75 V | -55°C ~ 150°C | Surface Mount |
|
NSR0115CQP6T5GDIODE ARRAY SCHOTTKY 15V SOT963 |
3,084 | 0.47 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 2 Pair Common Cathode | Schottky | 15 V | 100mA (DC) | 180 mV @ 10 µA | Fast Recovery =< 500ns, > 200mA (Io) | 5 ns | 15 µA @ 10 V | -55°C ~ 150°C | Surface Mount |
|
SNRVUD620CTT4GDIODE ARRAY GP 200V 3A DPAK |
3,288 | 0.67 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, SWITCHMODE™ | Active | 1 Pair Common Cathode | Standard | 200 V | 3A | 1 V @ 3 A | Fast Recovery =< 500ns, > 200mA (Io) | 35 ns | 5 µA @ 200 V | -65°C ~ 175°C | Surface Mount |
|
MBR1535CTGDIODE ARRAY SCHOTTKY 35V TO220AB |
2,353 | 1.34 |
RFQ |
Datasheet |
Tube | SWITCHMODE™ | Obsolete | 1 Pair Common Cathode | Schottky | 35 V | 7.5A | 840 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 35 V | -65°C ~ 175°C | Through Hole |
|
|
NRVBD640VCTT4GDIODE ARRAY SCHOTTKY 40V 3A DPAK |
3,529 | 1.41 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | SWITCHMODE™ | Obsolete | 1 Pair Common Cathode | Schottky | 40 V | 3A | 700 mV @ 3 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 40 V | -65°C ~ 175°C | Surface Mount |
|
FYPF2004DNTUDIODE ARRAY SCHOTTKY 40V TO220F |
3,972 | 1.56 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 40 V | 20A | 670 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 40 V | -40°C ~ 150°C | Through Hole |
|
SM1MA151WKT1GSM1MA151 - 40 V COMMON CATHODE S |
2,931 | 0.03 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
SBE805-S-TL-WSBE805 - SBD PARALLEL, 0.5A, 30V |
2,315 | 0.21 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
FFAF30UA60S30 A, 600 V, UITRAFAST II SINGLE |
2,883 | 1.09 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
|
FFSH2065BDN-F085AUTOMOTIVE SILICON CARBIDE (SIC) |
2,549 | 3.96 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
