| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RURG3060CCDIODE ARRAY GP 600V 30A TO247 |
484 | 4.10 |
RFQ |
Tube | - | Active | 1 Pair Common Cathode | Standard | 600 V | 30A | 1.5 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | 60 ns | 250 µA @ 600 V | -65°C ~ 175°C | Through Hole | |
|
BAW56TT1GDIODE ARRAY GP 70V 200MA SC75 |
2,643 | 0.18 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 70 V | 200mA (DC) | 1.25 V @ 150 mA | Small Signal =< 200mA (Io), Any Speed | 6 ns | 2.5 µA @ 70 V | -55°C ~ 150°C | Surface Mount |
|
M1MA152WAT1GDIODE ARRAY GP 80V 100MA SC59 |
3,398 | 0.26 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 80 V | 100mA (DC) | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 10 ns | 100 nA @ 75 V | 150°C (Max) | Surface Mount |
|
BAS35DIODE ARRAY GP 120V 200MA SOT23 |
2,929 | 0.41 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Anode | Standard | 120 V | 200mA | 1 V @ 200 mA | Small Signal =< 200mA (Io), Any Speed | 50 ns | 100 nA @ 90 V | 150°C (Max) | Surface Mount |
|
BAT54CXV3T1GDIODE ARRAY SCHOTTKY 30V SC89-3 |
3,085 | 0.48 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 30 V | 200mA (DC) | 800 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 25 V | -55°C ~ 125°C | Surface Mount |
|
NRVHP8H200MFDWFT1GDIODE ARRAY GP 200V 4A 8DFN |
2,523 | 1.51 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101, SWITCHMODE™ | Active | 2 Independent | Standard | 200 V | 4A | 910 mV @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | 500 nA @ 200 V | -55°C ~ 175°C | Surface Mount |
|
SBRB20200CTT4GDIODE ARRAY SCHOTTKY 200V D2PAK |
897 | 2.06 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | SWITCHMODE™ | Active | 1 Pair Common Cathode | Schottky | 200 V | 10A | 900 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 200 V | -65°C ~ 150°C | Surface Mount |
|
|
NRVUB1660CTT4GDIODE ARRAY GP 600V 8A D2PAK |
2,925 | 3.72 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | SWITCHMODE™ | Active | 1 Pair Common Cathode | Standard | 600 V | 8A | 1.5 V @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 60 ns | 10 µA @ 600 V | -65°C ~ 175°C | Surface Mount |
|
MUR3040WTGDIODE ARRAY GP 400V 15A TO247 |
963 | 4.25 |
RFQ |
Datasheet |
Tube | SWITCHMODE™ | Last Time Buy | 1 Pair Common Cathode | Standard | 400 V | 15A | 1.25 V @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | 60 ns | 10 µA @ 400 V | -65°C ~ 175°C | Through Hole |
|
NSR0230P2T5HSCHOTTKY DIODE SOD923 |
3,898 | 0.07 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
SB02-03Q-TL-ESCHOTTKY DIODE 0.2A 30V |
2,047 | 0.07 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
|
SCR22-6RLRPTHY SI CONNTROLLED RECTIF |
2,538 | 0.07 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
|
ISL9K3060G3DIODE ARRAY GP 600V 30A TO247 |
444 | 3.48 |
RFQ |
Datasheet |
Tube | Stealth™ | Active | 1 Pair Common Cathode | Standard | 600 V | 30A | 2.4 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | 45 ns | 100 µA @ 600 V | -55°C ~ 175°C | Through Hole |
|
|
RE0208DA-TR-E800 V, 200 MILLIAMP FAST RECOVER |
2,891 | 0.02 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
BAW56WT1HSS SC-70 SWCH DIO 70V T |
3,828 | 0.02 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
SSV1BAW56LT1SS SOT23 SWTCH DIO SPCL |
3,801 | 0.02 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
SBAV70WT1DIODE ARRAY GP 100V 200MA SC70-3 |
2,194 | 0.02 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
SMBD1472LT3SS SOT23 DUAL DIO SPCL |
2,413 | 0.02 |
RFQ |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | |
|
|
BAV74LT3RECTIFIER DIODE |
2,181 | 0.02 |
RFQ |
Datasheet |
Bulk | - | Active | 1 Pair Common Cathode | Standard | 50 V | 200mA (DC) | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 50 V | -55°C ~ 150°C | Surface Mount |
|
|
BAT54ALT1HSS SOT23 SHKY DIO 30V TR |
3,244 | 0.02 |
RFQ |
Datasheet |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - |
