| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NTSB40200CTGDIODE SCHOTTKY 200V 20A D2PAK |
3,266 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 200 V | 20A | 1.45 V @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 200 V | -55°C ~ 150°C | Surface Mount |
|
NTST40H120CTGDIODE SCHOTTKY 120V 40A TO220 |
2,603 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 120 V | 20A | 910 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 65 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
RHRG1560CC-F085DIODE ARRAY GP 600V 15A TO247-3 |
2,180 | 0.00 |
RFQ |
Datasheet |
Tube | Automotive, AEC-Q101 | Obsolete | 1 Pair Common Cathode | Standard | 600 V | 15A | 2.3 V @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | 55 ns | 100 µA @ 600 V | -55°C ~ 175°C | Through Hole |
|
DCA010-TB-EDIODE ARRAY GP 80V 150MA 3CP |
2,533 | 0.07 |
RFQ |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | 1 Pair Common Anode | Standard | 80 V | 150mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 500 nA @ 80 V | 125°C (Max) | Surface Mount | |
|
|
DCB010-TB-EDIODE ARRAY GP 80V 100MA 3CP |
3,096 | 0.07 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 80 V | 125°C (Max) | Surface Mount |
|
DCC010-TB-EDIODE ARRAY GP 80V 100MA 3CP |
3,993 | 1.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | 1 Pair Series Connection | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 500 nA @ 80 V | 125°C (Max) | Surface Mount |
|
|
NTSB40200CTT4GDIODE SCHOTTKY 200V 40A D2PAK |
2,167 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | - | Obsolete | 1 Pair Common Cathode | Schottky | 200 V | 20A | 1.45 V @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 200 V | -40°C ~ 150°C | Surface Mount |
|
|
NTST40120CTHDIODE ARRAY SCHOTTKY 120V TO220 |
2,796 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 120 V | 20A | 910 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 500 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
|
NTST60100CTGDIODE ARRAY SCHOTTKY 100V TO220 |
3,475 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 100 V | 30A | 840 mV @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 A @ 8100 V | -40°C ~ 150°C | Through Hole |
|
|
NTSV20H120CTGDIODE ARRAY SCHOTTKY 120V TO220 |
2,990 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 120 V | 10A | 1.03 V @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 35 µA @ 120 V | -40°C ~ 150°C | Through Hole |
|
|
NTSV30H100ECTGDIODE ARRAY SCHOTTKY 100V TO220 |
3,881 | 0.60 |
RFQ |
Datasheet |
Bulk,Tube,Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 100 V | 15A | 900 mV @ 15 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 85 µA @ 100 V | -40°C ~ 175°C | Through Hole |
|
|
NTSW60200CTGDIODE SCHOTTKY 60A 200V TO-247 |
2,522 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 200 V | 30A | 1.9 V @ 30 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 100 V | -55°C ~ 150°C | Through Hole |
|
SBRD81035CTLGDIODE SCHOTTKY 35V 10A DPAK |
2,117 | 0.87 |
RFQ |
Datasheet |
Bulk,Tube,Tube | Automotive, AEC-Q101 | Active | 1 Pair Common Cathode | Schottky | 35 V | 5A | 470 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 2 mA @ 35 V | -55°C ~ 150°C | Surface Mount |
|
NHP620MFDT3GDIODE GEN PURP 200V 3A SO-8FL |
2,459 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR) | Automotive, AEC-Q101 | Obsolete | 2 Independent | Standard | 200 V | 3A | 1 V @ 3 A | Fast Recovery =< 500ns, > 200mA (Io) | 25 ns | 500 nA @ 200 V | -55°C ~ 175°C | Surface Mount |
|
SBT700-06RH-1EDIODE ARRAY SCHOTTKY 60V TO220ML |
2,498 | 0.00 |
RFQ |
Datasheet |
Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 60 V | 70A | 660 mV @ 30 A | Standard Recovery >500ns, > 200mA (Io) | - | 1 mA @ 30 V | 150°C (Max) | Through Hole |
|
BAT54STDIODE SCHOTTKY 30V 100MA SOT523 |
3,809 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 Pair Series Connection | Schottky | 30 V | 100mA | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 2 µA @ 25 V | 125°C (Max) | Surface Mount |
|
|
BAV99TDIODE DUAL 85V 75MA SOT-523 |
2,755 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 Pair Series Connection | Standard | 85 V | 75mA | 1 V @ 50 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 2 µA @ 75 V | 125°C (Max) | Surface Mount |
|
|
BAW56TDIODE DUAL 85V 75MA SOT-523 |
2,348 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 Pair Common Anode | Standard | 85 V | 75mA | 1 V @ 50 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 2 µA @ 75 V | 125°C (Max) | Surface Mount |
|
DCG010-TL-EDIODE ARRAY GP 80V 100MA 3MCP |
2,944 | 0.08 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT),Bulk | - | Obsolete | 1 Pair Common Cathode | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 500 nA @ 80 V | 125°C (Max) | Surface Mount |
|
|
NRTST40H100CTGDIODE SCHOTTKY 100V 20A TO220AB |
248 | 1.05 |
RFQ |
Datasheet |
Tube,Tube | - | Obsolete | 1 Pair Common Cathode | Schottky | 100 V | 20A | 760 mV @ 20 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 50 µA @ 100 V | -55°C ~ 150°C | Through Hole |
