| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | DiodeConfiguration | DiodeType | Voltage-DCReverse(Vr)(Max) | Current-AverageRectified(Io)(perDiode) | Voltage-Forward(Vf)(Max)@If | Speed | ReverseRecoveryTime(trr) | Current-ReverseLeakage@Vr | OperatingTemperature-Junction | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RBQ10B65ATLDIODE ARRAY SCHOTTKY 65V 5A CPD |
3,162 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 1 Pair Common Cathode | Schottky | 65 V | 5A | 690 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 150 µA @ 65 V | 150°C (Max) | Surface Mount |
|
RB085BM-30TLDIODE ARRAY SCHOTTKY 30V TO252 |
3,293 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 30 V | 5A | 480 mV @ 4 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 300 µA @ 30 V | 150°C (Max) | Surface Mount |
|
|
RB088BM150TLDIODE ARRAY SCHOTTKY 150V TO252 |
3,870 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 150 V | 10A | 880 mV @ 5 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 15 µA @ 150 V | 150°C (Max) | Surface Mount |
|
|
RB095BM-40TLDIODE ARRAY SCHOTTKY 45V TO252 |
3,149 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Schottky | 45 V | 6A | 550 mV @ 3 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 100 µA @ 40 V | 150°C (Max) | Surface Mount |
|
RFN6B2DTLDIODE GEN PURPOSE TO252 |
2,135 | 0.00 |
RFQ |
Tape & Reel (TR) | * | Obsolete | - | - | - | - | - | - | - | - | - | - | |
|
RB481Y-40FHT2RSCHOTTKY BARRIER DIODES (CORRESP |
2,370 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Obsolete | 2 Independent | Schottky | 40 V | 200mA | 450 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 90 µA @ 40 V | 150°C (Max) | Surface Mount |
|
BAS40-04HMFHT116DIODE ARRAY SCHOT 40V 120MA SSD3 |
3,691 | 0.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Not For New Designs | 1 Pair Series Connection | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 µA @ 40 V | 150°C (Max) | Surface Mount |
|
|
BAS40-05HMFHT116DIODE ARRAY SCHOT 40V 120MA SSD3 |
3,343 | 0.22 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Not For New Designs | 1 Pair Common Cathode | Schottky | 40 V | 120mA (DC) | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 µA @ 40 V | 150°C (Max) | Surface Mount |
|
|
BAT54AHMFHT116DIODE ARRAY SCHOT 30V 200MA SSD3 |
3,643 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Not For New Designs | 1 Pair Common Anode | Schottky | 30 V | 200mA (DC) | 800 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 50 ns | 2 µA @ 25 V | 150°C (Max) | Surface Mount |
|
|
RB480Y-90FHT2RDIODE (RECTIFIER FRD) 90V-VRM 90 |
2,188 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Obsolete | 2 Independent | Schottky | 90 V | 100mA | 690 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 5 µA @ 90 V | 150°C (Max) | Surface Mount |
|
|
BAV99HMFHT116DIODE ARRAY GP 80V 215MA SSD3 |
3,738 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 1 Pair Series Connection | Standard | 80 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 100 nA @ 80 V | 150°C (Max) | Surface Mount |
|
|
RBR20BM40AFHTLDIODE ARRAY SCHOTT 40V 20A TO252 |
2,678 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 1 Pair Common Cathode | Schottky | 40 V | 20A | 580 mV @ 10 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 360 µA @ 40 V | 150°C (Max) | Surface Mount |
|
|
BAV99HMT116PMDU RECTIFYING DIODE |
3,382 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Series Connection | Standard | 80 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 100 nA @ 80 V | 150°C (Max) | Surface Mount |
|
|
BAV70HMT116BAV70HM IS HIGH RELIABILITY AND |
3,712 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | - | Active | 1 Pair Common Cathode | Standard | 80 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 500 nA @ 80 V | 150°C (Max) | Surface Mount |
|
UMP1NFHTRSWITCHING DIODES (CORRESPONDS TO |
3,250 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 2 Pair Common Anode | Standard | 80 V | 25mA | 900 mV @ 5 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 70 V | 150°C (Max) | Surface Mount |
|
UMN11NFHTNSWITCHING DIODES (CORRESPONDS TO |
2,950 | 0.00 |
RFQ |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | Automotive, AEC-Q101 | Active | 2 Pair Common Cathode | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 4 ns | 100 nA @ 70 V | 150°C (Max) | Surface Mount |
|
|
DAP202CT116DIODE GENERAL PURPOSE SMD |
3,718 | 0.00 |
RFQ |
Tape & Reel (TR) | - | Obsolete | - | - | - | - | - | - | - | - | - | - | |
|
|
BAV99GT116DIODE GENERAL PURPOSE SMD |
3,370 | 0.00 |
RFQ |
Tape & Reel (TR) | - | Obsolete | 1 Pair Series Connection | Standard | 75 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 1 µA @ 75 V | 150°C (Max) | Surface Mount | |
|
|
BAV70T216DIODE GENERAL PURPOSE SMD |
3,695 | 0.00 |
RFQ |
Tape & Reel (TR) | - | Obsolete | 1 Pair Common Cathode | Standard | 70 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 2.5 µA @ 70 V | 150°C (Max) | Surface Mount | |
|
|
BAV99LT116DIODE GENERAL PURPOSE SMD |
2,367 | 0.00 |
RFQ |
Tape & Reel (TR) | - | Obsolete | 1 Pair Series Connection | Standard | 75 V | 215mA (DC) | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 1 µA @ 75 V | 150°C (Max) | Surface Mount |
