| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | Type | NumberofOutputs | Voltage-Input(Min) | Voltage-Input(Max) | Voltage-Output1 | Voltage-Output2 | Voltage-Output3 | Voltage-Output4 | Current-Output(Max) | Power(Watts) | Voltage-Isolation | Applications | Features | OperatingTemperature | Efficiency | MountingType | Size/Dimension | ControlFeatures | ApprovalAgency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PESE2-S12-S24-MDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,430 | 6.78 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tube | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 24V | - | - | - | 83mA | 1.992 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 85% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S9-MDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,315 | 6.78 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tube | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 9V | - | - | - | 222mA | 1.998 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S12-S15-MDC-DC 3KV ISOLATED, 2 W, 10.8~13 |
2,285 | 6.78 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tube | PESE2-M (2W) | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 133mA | 1.995 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 84% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
|
PESE2-S15-S5-MDC-DC 3KV ISOLATED, 2 W, 13.5~16 |
2,479 | 6.80 |
RFQ |
Datasheet |
8-SMD Module, 5 Leads | Tube | PESE2-M (2W) | Active | Isolated Module | 1 | 13.5V | 16.5V | 5V | - | - | - | 400mA | 2 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Surface Mount | 0.52 L x 0.33 W x 0.29 H (13.2mm x 8.5mm x 7.3mm) | ||
|
PEME2-S24-D5-SDC-DC 3KV ISOLATED, 2 W, 21.6~26 |
3,099 | 6.96 |
RFQ |
Datasheet |
7-SIP Module, 5 Leads | Tube | PEME2-S (2W) | Active | Isolated Module | 2 | 21.6V | 26.4V | 5V | -5V | - | - | 200mA, 200mA | 2 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 80% | Through Hole | 0.77 L x 0.28 W x 0.40 H (19.7mm x 7.1mm x 10.2mm) | ||
|
|
PEME2-S24-D24-SDC-DC 3KV ISOLATED, 2 W, 21.6~26 |
3,871 | 6.96 |
RFQ |
Datasheet |
7-SIP Module, 5 Leads | Tube | PEME2-S (2W) | Active | Isolated Module | 2 | 21.6V | 26.4V | 24V | -24V | - | - | 42mA, 42mA | 2.016 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 83% | Through Hole | 0.77 L x 0.28 W x 0.40 H (19.7mm x 7.1mm x 10.2mm) | ||
|
PRM1W-E12-S12-SDC-DC ISOLATED, 1 W, 4.5~36 VDC |
3,031 | 8.94 |
RFQ |
Datasheet |
8-SIP Module, 7 Leads | Tube | PRM1W-S (1W) | Active | Isolated Module | 1 | 4.5V | 36V | 12V | - | - | - | 83mA | 996 mW | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 74% | Through Hole | 0.87 L x 0.37 W x 0.47 H (22.0mm x 9.5mm x 12.0mm) | ||
|
|
PRM1W-E12-D12-SDC-DC ISOLATED, 1 W, 4.5~36 VDC |
2,018 | 9.16 |
RFQ |
Datasheet |
8-SIP Module, 7 Leads | Tube | PRM1W-S (1W) | Active | Isolated Module | 2 | 4.5V | 36V | 12V | -12V | - | - | 42mA, 42mA | 1 W | 3 kV | ITE (Commercial) | Adjustable Output | -40°C ~ 105°C (With Derating) | 74% | Through Hole | 0.87 L x 0.37 W x 0.47 H (22.0mm x 9.5mm x 12.0mm) | ||
|
PRM3W-E12-D5-SDC-DC ISOLATED, 3 W, 4.5~36 VDC |
3,625 | 9.20 |
RFQ |
Datasheet |
8-SIP Module, 7 Leads | Tube | PRM3W-S (3W) | Active | Isolated Module | 2 | 4.5V | 36V | 5V | -5V | - | - | 300mA, 300mA | 3 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C (With Derating) | 77% | Through Hole | 0.87 L x 0.37 W x 0.47 H (22.0mm x 9.5mm x 12.0mm) | ||
|
PQDE6W-Q110-S24-DDC DC CONVERTER 24V 6W |
2,206 | 16.01 |
RFQ |
Datasheet |
6-DIP Module, 4 Leads | Tube | PQDE6W-Q110 (6W) | Active | Isolated Module | 1 | 40V | 160V | 24V | - | - | - | 250mA | 6 W | 2.25 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 86% | Through Hole | 1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm) | ||
|
PQDE6W-Q48-D5-DDC DC CONVERTER +/-5V 6W |
3,405 | 15.75 |
RFQ |
Datasheet |
5-DIP Module | Tube | PQDE6W-D (6W) | Active | Isolated Module | 2 | 18V | 75V | 5V | -5V | - | - | 600mA, 600mA | 6 W | 1.5 kV | ITE (Commercial) | OCP, OVP, SCP, UVLO | -40°C ~ 85°C (With Derating) | 83% | Through Hole | 1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm) | ||
|
|
PQDE6W-Q110-D15-DDC DC CONVERTER +/-15V 6W |
3,475 | 19.21 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQDE6W-Q110 (6W) | Active | Isolated Module | 2 | 40V | 160V | 15V | -15V | - | - | 200mA, 200mA | 6 W | 2.25 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 85% | Through Hole | 1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm) | ||
|
|
PQDE6W-Q110-D5-DDC DC CONVERTER +/-5V 6W |
3,368 | 19.21 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQDE6W-Q110 (6W) | Active | Isolated Module | 2 | 40V | 160V | 5V | -5V | - | - | 600mA, 600mA | 6 W | 2.25 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 80% | Through Hole | 1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm) | ||
|
|
PQDE6W-Q110-D12-DDC DC CONVERTER +/-12V 6W |
3,467 | 19.21 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQDE6W-Q110 (6W) | Active | Isolated Module | 2 | 40V | 160V | 12V | -12V | - | - | 250mA, 250mA | 6 W | 2.25 kV | ITE (Commercial) | - | -40°C ~ 85°C (With Derating) | 84% | Through Hole | 1.00 L x 1.00 W x 0.46 H (25.4mm x 25.4mm x 11.7mm) | ||
|
PYBE20-Q48-S3DC DC CONVERTER 3.3V 17W |
2,500 | 27.42 |
RFQ |
Datasheet |
6-DIP Module | Tube | PYBE20 (20W) | Active | Isolated Module | 1 | 18V | 75V | 3.3V | - | - | - | 5A | 17 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OVP, SCP | -40°C ~ 85°C (With Derating) | 86% | Through Hole | 2.00 L x 1.00 W x 0.46 H (50.8mm x 25.4mm x 11.8mm) | ||
|
PQAE50-D24-S15-DDC-DC ISOLATED, 50 W, 18~36 VDC |
3,523 | 37.59 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQAE50 (50W) | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 3.333A | 50 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 91% | Through Hole | 2.00 L x 1.00 W x 0.46 H (50.8mm x 25.4mm x 11.8mm) | ||
|
PQAE50-D48-S15-DDC-DC ISOLATED, 50 W, 36~75 VDC |
2,408 | 37.88 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQAE50 (50W) | Active | Isolated Module | 1 | 36V | 75V | 15V | - | - | - | 3.333A | 50 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 92% | Through Hole | 2.00 L x 1.00 W x 0.46 H (50.8mm x 25.4mm x 11.8mm) | ||
|
PQAE50-D48-S24-DHDC-DC ISOLATED, 50 W, 36~75 VDC |
2,729 | 38.66 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQAE50 (50W) | Active | Isolated Module | 1 | 36V | 75V | 24V | - | - | - | 2.083A | 50 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Heat Sink, Remote On/Off | -40°C ~ 105°C (With Derating) | 92% | Through Hole | 2.00 L x 1.00 W x 0.65 H (50.8mm x 25.4mm x 16.5mm) | ||
|
|
PQAE50-D24-S3-DDC-DC ISOLATED, 50 W, 18~36 VDC |
3,953 | 39.40 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQAE50 (50W) | Active | Isolated Module | 1 | 18V | 36V | 3.3V | - | - | - | 10A | 33 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 91% | Through Hole | 2.00 L x 1.00 W x 0.46 H (50.8mm x 25.4mm x 11.8mm) | ||
|
|
PQAE50-D48-S3-DDC-DC ISOLATED, 50 W, 36~75 VDC |
2,173 | 39.69 |
RFQ |
Datasheet |
6-DIP Module | Tube | PQAE50 (50W) | Active | Isolated Module | 1 | 36V | 75V | 3.3V | - | - | - | 10A | 33 W | 1.5 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 105°C (With Derating) | 91% | Through Hole | 2.00 L x 1.00 W x 0.46 H (50.8mm x 25.4mm x 11.8mm) |
