| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Packaging | Series | ProductStatus | NumberofBits | NumberofD/AConverters | SettlingTime | OutputType | DifferentialOutput | DataInterface | ReferenceType | Voltage-SupplyAnalog | Voltage-SupplyDigital | INL/DNL(LSB) | Architecture | OperatingTemperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AD9720TE/883BDAC, PARALLEL, WORD INPUT |
3,772 | 125.99 |
RFQ |
Datasheet |
28-CLCC | Bulk | AD9720 | Active | 10 | 1 | 4.5ns (Typ) | Current - Unbuffered | No | - | External, Internal | 4.75V ~ 5.25V | 4.75V ~ 5.25V | ±0.7LSB, ±0.6LSB | Current Source | -55°C ~ 125°C |
|
AD563SD/BCD12-BIT D/A CONVERTER |
3,404 | 135.52 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk | AD563 | Active | 12 | 1 | 1.5µs (Typ) | Current - Unbuffered | No | - | Internal | 4.75V ~ 15.8V | 4.75V ~ 15.8V | ±0.5 (Max), ±0.5 (Max) | Multiplying DAC | -55°C ~ 125°C |
|
|
5962-8965702LADUAL MARKED (AD7547TQ/883B) |
3,429 | 137.69 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk | - | Active | 12 | 2 | 1.5µs | Current - Unbuffered | No | Parallel | External | 10.8V ~ 16.5V | 10.8V ~ 16.5V | ±0.5 (Max), ±1 (Max) | Multiplying DAC, R-2R | -55°C ~ 125°C |
|
AD558TD/883BIC DAC 8BIT V-OUT 16CDIP |
3,779 | 156.00 |
RFQ |
Datasheet |
16-CDIP (0.300, 7.62mm) | Tube | - | Active | 8 | 1 | 3µs | Voltage - Buffered | No | Parallel | Internal | 4.5V ~ 16.5V, 11.4V ~ 16.5V | 4.5V ~ 16.5V, 11.4V ~ 16.5V | ±0.25 | R-2R | -55°C ~ 125°C |
|
|
AD563TD/BCD12-BIT D/A CONVERTER |
2,736 | 220.78 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk | AD563 | Active | 12 | 1 | 1.5µs (Typ) | Current - Unbuffered | No | - | Internal | 4.75V ~ 15.8V | 4.75V ~ 15.8V | ±0.5 (Max), ±0.5 (Max) | Multiplying DAC | -55°C ~ 125°C |
|
|
5962-87763033XDUAL CHANNEL DAC, 8 BITS |
3,902 | 299.59 |
RFQ |
Datasheet |
20-CLCC | Bulk | AD7537 | Active | 12 | 2 | 1.5µs | Current - Unbuffered | No | Parallel | External | 10.8V ~ 16.5V | 10.8V ~ 16.5V | ±0.5 (Max), ±1 (Max) | R-2R | -55°C ~ 125°C |
|
|
AD563TD/BIN/883B12-BIT D/A CONVERTER |
2,280 | 358.39 |
RFQ |
Datasheet |
24-CDIP (0.300, 7.62mm) | Bulk | AD563 | Obsolete | 12 | 1 | 1.5µs (Typ) | Current - Unbuffered | No | - | Internal | 4.75V ~ 15.8V | 4.75V ~ 15.8V | ±0.5 (Max), ±0.5 (Max) | Multiplying DAC | -55°C ~ 125°C |
|
5962-88659013AIC DAC 12BIT W/BUFF LATCH 28CLCC |
2,737 | 510.28 |
RFQ |
Datasheet |
28-LCC | Tube | Military, MIL-STD-883 | Active | 12 | 1 | 4µs | Voltage - Buffered | No | Parallel | External, Internal | ±11.4V ~ 16.5V | - | ±0.125, ±0.25 | R-2R | -55°C ~ 125°C |
|
5962-8851001XCQUAD CHANNEL 12-BIT (AD394SD) |
3,175 | 606.54 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Bulk | AD394 | Active | 12 | 4 | 15µs | Voltage - Buffered | No | Parallel | External | ±13.5V ~ 16.5V | ±13.5V ~ 16.5V | ±0.25LSB (Max), ±0.5 | Multiplying DAC | -55°C ~ 125°C |
|
5962-8851001XAQUAD CHANNEL 12-BIT (AD394S) |
3,773 | 1213.09 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Bulk | AD394 | Active | 12 | 4 | 15µs | Voltage - Buffered | No | Parallel | External | ±13.5V ~ 16.5V | ±13.5V ~ 16.5V | ±0.25LSB (Max), ±0.5 | Multiplying DAC | -55°C ~ 125°C |
|
|
5962-8850901XAQUAD CHANNEL 12-BIT (AD390SD) |
3,309 | 1373.85 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Bulk | - | Active | 12 | 4 | 8µs | Voltage - Buffered | No | Parallel | External, Internal | ±13.5V ~ 16.5V | ±13.5V ~ 16.5V | ±0.25, ±0.5 | - | -55°C ~ 125°C |
|
|
5962-8850901XCQUAD CHANNEL 12-BIT (AD390S) |
2,688 | 2060.79 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Bulk | - | Active | 12 | 4 | 8µs | Voltage - Buffered | No | Parallel | External, Internal | ±13.5V ~ 16.5V | ±13.5V ~ 16.5V | ±0.25, ±0.5 | - | -55°C ~ 125°C |
|
AD390TDIC DAC 12BIT V-OUT 28CDIP |
2,822 | 3601.41 |
RFQ |
Datasheet |
28-CDIP (0.600, 15.24mm) | Tube | - | Active | 12 | 4 | 8µs | Voltage - Buffered | No | Parallel | External, Internal | ±13.5V ~ 16.5V | - | ±0.25, ±0.5 | - | -55°C ~ 125°C |
|
AD5821BCBZ-REEL7IC DAC 10BIT A-OUT 9WLCSP |
100 | 2.43 |
RFQ |
Datasheet |
9-UFBGA, WLCSP | Tape & Reel (TR),Cut Tape (CT) | - | Obsolete | 10 | 1 | 250µs (Typ) | Current - Buffered | No | I²C | Internal | 2.7V ~ 5.5V | 2.7V ~ 5.5V | ±1.5, ±1 (Max) | Current Sink | -40°C ~ 85°C |
|
LTC2630ISC6-HM8#TRMPBFIC DAC 8BIT V-OUT SC70-6 |
2,171 | 3.60 |
RFQ |
Datasheet |
6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR),Cut Tape (CT) | - | Active | 8 | 1 | 3.7µs (Typ) | Voltage - Buffered | No | SPI | Internal, Supply | 5V | 5V | ±0.05, ±0.5 (Max) | - | -40°C ~ 85°C |
|
|
LTC2630CSC6-HM10#TRMPBFIC DAC 10BIT V-OUT SC70-6 |
2,898 | 4.27 |
RFQ |
Datasheet |
6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR),Cut Tape (CT) | - | Active | 10 | 1 | 4.4µs (Typ) | Voltage - Buffered | No | SPI | Internal, Supply | 5V | 5V | ±0.2, ±0.5 (Max) | - | 0°C ~ 70°C |
|
LTC2640CTS8-LZ10#TRMPBFIC DAC 10BIT V-OUT TSOT23-8 |
3,675 | 4.41 |
RFQ |
Datasheet |
SOT-23-8 Thin, TSOT-23-8 | Tape & Reel (TR),Cut Tape (CT) | - | Active | 10 | 1 | 3.8µs (Typ) | Voltage - Buffered | No | SPI | External, Internal | 2.7V ~ 5.5V | 2.7V ~ 5.5V | ±0.2, ±0.5 (Max) | - | 0°C ~ 70°C |
|
|
LTC2630HSC6-HM12#TRMPBFIC DAC 12BIT V-OUT SC70-6 |
2,467 | 5.27 |
RFQ |
Datasheet |
6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR),Cut Tape (CT) | - | Active | 12 | 1 | 4.8µs (Typ) | Voltage - Buffered | No | SPI | Internal, Supply | 5V | 5V | ±1, ±1 (Max) | - | -40°C ~ 125°C |
|
|
LTC2633CTS8-HZ10#TRMPBFIC DAC 10BIT V-OUT TSOT23-8 |
3,135 | 6.23 |
RFQ |
Datasheet |
SOT-23-8 Thin, TSOT-23-8 | Tape & Reel (TR),Cut Tape (CT) | - | Active | 10 | 2 | 4µs (Typ) | Voltage - Buffered | No | I²C | External, Internal | 5V | 5V | ±0.2, ±0.5 (Max) | - | 0°C ~ 70°C |
|
AD5425YRMZ-REEL7IC DAC 8BIT A-OUT 10MSOP |
3,564 | 6.63 |
RFQ |
Datasheet |
10-TFSOP, 10-MSOP (0.118, 3.00mm Width) | Tape & Reel (TR),Cut Tape (CT) | - | Active | 8 | 1 | 160ns | Current - Unbuffered | Yes | SPI, DSP | External | 2.5V ~ 5.5V | 2.5V ~ 5.5V | ±0.25 (Max), ±0.5 (Max) | R-2R | -40°C ~ 125°C |
